RJ45 Pin Out to DMX Input

The DIN PIXIE features two RJ45 ports for DMX Input.
Pin 1: Data +

Pin 2: Data –

Pin 7/8: Ground

Pi n n um b e ri n g i n accor dan ce w i th ANSI E 1. 27- 2
Note:
Label any RJ45 DMX connector and DO NOT connect it to non-DMX ports (i.e. Ethernet Switches).
Connecting incompatible systems could result in permanent damage to DIN PIXIE and similar
equipment.

LED Status Indicator

The DIN PIXIE comes with a LED indicator that display different status:
LED Colour
Red
White
Green
Yellow

Application Diagram

DMX Mode
DMX Consoles
DMX Nodes
USB Mode
Lighting Software
(Art-Net)
4
|
Status
Boot/Error
Idle
Data Receive
Standalone
DIN PIXIE
(SKU:73539)
Standalone Mode
Pre-recorded show file
ID: 5935565 Document Updated: Nov 2023
Visit the ENTTEC website for the latest version.
SPI Output
Pixel Dots
Pixel Tapes
Neon Flex
USER MANUAL

DIN PIXIE (73539)
..
