Din Pixie - User Manual
SPI Pixel Strip/Dot controller: control 2 universe of LED pixels over two outputs
Content
Safety ............................................................................................................................................................................................................................ 2
Electrical safety ............................................................................................................................................................................................................................. 2
System Planning and Specification ................................................................................................................................................................................... 2
Protection from Injury During Installation ..................................................................................................................................................................... 2
Installation Safety Guidelines ............................................................................................................................................................................................... 2
Physical Dimensions ............................................................................................................................................................................................. 3
Wiring Diagrams ...................................................................................................................................................................................................... 3
Mounting Option ..................................................................................................................................................................................................... 3
Functional features ............................................................................................................................................................................................... 4
USB Mode ......................................................................................................................................................................................................................................... 4
DMX Mode ........................................................................................................................................................................................................................................ 4
Application example .................................................................................................................................................................................................................. 4
Standalone Mode ........................................................................................................................................................................................................................ 5
LED status indicator ................................................................................................................................................................................................................... 5
Out of the Box .......................................................................................................................................................................................................... 5
PRO-Manager ............................................................................................................................................................................................................ 5
Devices .............................................................................................................................................................................................................................................. 6
Firmware update .......................................................................................................................................................................................................................... 6
SEND ................................................................................................................................................................................................................................................... 6
Standalone mode ........................................................................................................................................................................................................................ 7
DMX ports .................................................................................................................................................................................................................. 8
Servicing, Inspection & Maintenance ........................................................................................................................................................... 9
Cleaning ............................................................................................................................................................................................................................................ 9
Package Contents ................................................................................................................................................................................................... 9
Ordering Information ........................................................................................................................................................................................... 9
1
|
ID: 5935565
Document Updated: Feb 2022
Visit the ENTTEC website for the latest version.
USER MANUAL
DIN PIXIE (73539)
..
