Enttec ODE Configuration Manual

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

The Enttec ODE is a Art-Net node which can be connected to a WiFi and compatible network
with the Art-Net mode of the application Run The Show DMX.
 Download and install on your computer the Node Managment Utility (NMU) by following
the link:
http://www.enttec.com/?main_menu=Products&pn=79001
 Connect the Enttec ODE to a Ethernet
PORT of the computer on which the
NMU software was installed.
 Deactivate the WIFI of the computer
to which the ODE is connected
(note previously the parameters of
connection: IP address and mask of
network). For example, it will be: IP
192.168.1.1 and mask 255.255.255.0.
TNF Concept - 62 rue de Paris - 77240 Champs sur Marne - France
www.tnfconcept.com
Configure Enttec ODE
Configure Enttec ODE on OsX
 Open the network preferences.
contact@tnfconcept.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ODE and is the answer not in the manual?

Questions and answers

Related Manuals for Enttec ODE

Summary of Contents for Enttec ODE

  • Page 1 Configure Enttec ODE Configure Enttec ODE on OsX The Enttec ODE is a Art-Net node which can be connected to a WiFi and compatible network with the Art-Net mode of the application Run The Show DMX.  Download and install on your computer the Node Managment Utility (NMU) by following the link: http://www.enttec.com/?main_menu=Products&pn=79001...
  • Page 2  Configure the Ethernet port of the computer on the same network as the Enttec ODE (the factory settings of the box is an address such as 10.7.127.162, that is a class A network): - Choose manual configuration. - Seize an IP address in the same network as the ODE.
  • Page 3  The main window of the NMU software opens and, by clicking the button "Discovery", the Enttec ODE appears.  To select the ODE and click then the button "Configures …"  Choose an IP address which belongs to the WIFI network of your installation.
  • Page 4  Wait that the case is restarted and that the main screen of NMU shows the ODE with the new IP address.  Reactivate the WIFI on your computer. If it is configured to connect automatically, there is nothing to make otherwise, to fix in manual...
  • Page 5 IP address and the software is not able of finding the ODE.  Disconnect the ODE of the Ethernet port of your computer and connect it to the WIFI router of your installation. Wait for a few seconds before going farther. It is possible that it is necessary to switch off and then to switch on the ODE.
