GXP 1625 / 1620 / 1610
USER MANUAL_Ver2.0.4
Thank you for purchasing Grandstream GXP1625/GXP1620/GXP1610.
Make sure and acknowledge that you have read this manual before using GXP1620 and GXP1610.
Package Contents:
Main Case
Handset
Phone Cord
AC Power Adaptor
Ethernet Cable
Phone Stand
Quick Start Guide
Copyright © cloudippbx.com
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Grandstream Networks GXP1625
Summary of Contents for Grandstream Networks GXP1625
- Page 1 GXP 1625 / 1620 / 1610 USER MANUAL_Ver2.0.4 Thank you for purchasing Grandstream GXP1625/GXP1620/GXP1610. Make sure and acknowledge that you have read this manual before using GXP1620 and GXP1610. Package Contents: Main Case Handset Phone Cord AC Power Adaptor Ethernet Cable...
- Page 2 * The company assumes no responsibility when it was used outside Japan. * As for GXP1625 and GXP1620 and GXP1610 regular server maintenance, you may experience temporarily service stops without prior notice. * The company assumes no responsibility for the damages of customer caused by the phone malfunction or breakdown.
- Page 3 GXP1625 / GXP1620 / GXP1610 GXP1625 and GXP1620 and GXP1610 are a phone device that can be used with our service. It cannot be used as a typical phone. The customer must subscribe to an Internet Service Provider to be able to use the device.
-
Page 4: Keypad Buttons
Keypad Buttons Line1/Line2 Switch between LINE1 and LINE2 If the intercom number has set, call this number directly Page/Intercom If the intercom number has not set, press this key will have no effect Hold Place active call on hold, resume the call on hold. Press to enable/disable record feature in an active call or an Record conference. - Page 5 Phone Configuration Setting Grandstream GXP1625 and GXP1620 and GXP1610 1.Verify device’s IP address. Press soft key [NextScr] twice to view device’s IP address. 2. Open a web browser and enter the device’s IP address on the URL field Format: [http://IP Address] 3.
- Page 6 Phone Configuration 4. Hover cursor over [Accounts]. Select [Account 1] and click [General Settings]. SIP Server and Outbound Proxy Login: Enter Login Server. Account Name, SIP User ID, Authenticate ID: Enter Unique ID (10 characters). Authenticate Password: Enter Registered Password (sent thru mail).
- Page 7 Phone Configuration 5. Hover cursor over [Accounts]. Select [Account 1] and click [Network Settings]. Nat Traversal: Select [Keep Alive]. Once done click [Save and Apply] 6. Hover cursor over [Accounts]. Select [Account 1] and click [SIP Settings>Security Settings]. Check SIP User ID for Incoming INVITE : [Yes] Copyright ©...
- Page 8 Phone Configuration 7. Hover cursor over [Accounts]. Select [Account 1] and click [Audio Settings]. Send DTMF: Check [via RTP]. *If you check [DTMF Inband] for [DTMF mode] on your Unique Management Page on our site, Check[in-audio]. Once done click [Save and Apply] Copyright ©...
- Page 9 Phone Configuration 8. Hover cursor over [Settings] and click [Call Features]. Disable Call Waiting: Select [Yes]. *This will ignore Call-waiting. Select [No], if you want to enable Call-waiting. Once done, click [Save and Apply] Copyright © cloudippbx.com...
- Page 10 Phone Configuration 9.Hover cursor over [Settings] and click [Date and Time]. NTP Server: Enter ntp.jst.mfeed.ad.jp Time Zone: Select the time zone where you are located. Once done, click [Save and Apply] 10. Hover cursor over [Maintenance] and click [Web Access]. *Set a new password for Admin Password for security purposes.
- Page 11 Phone Configuration 11. Hover cursor over [Maintenance] and click [Upgrade and Provisioning]. Firmware Upgrade and Provisioning: Select [Always Skip the Firmware Check]. Once done, click [Save and Apply] Copyright © cloudippbx.com...
- Page 12 Phone Configuration 12. Hover cursor over [Maintenance] and click [Upgrade and Provisioning] *Note: This step should only be done if you want to upgrade firmware. Firmware Upgrade and Provisioning: Select [Always Check for New Firmware] Upgrade via: Select [HTTP] Automatic Upgrade: Select [Yes, check for upgrade every () minutes] input 10080 on field provided.
-
Page 13: Safety Precautions
Safety Precautions This manual contains precautions to assure user’s safety while using this product. If the precautions are disregarded, the extent of consequences is presented below. *This indicates that ignoring or mishandling of this notice might result to death or serious injury to the person. - Page 14 Safety Precautions *Do not place near the kitchen table or humidifier, or near oil and moisture. The device may malfunction, cause electric shock and fire. *Do not place in humid and dusty area. The device may malfunction, cause electric shock and fire. *Do not place in extremely cold place or place with unstable temperature.
-
Page 15: Troubleshooting
Troubleshooting Please check the troubleshooting procedure before requesting a repair. If the problem doesn’t get resolved, please contact us. Problem Solution Plug and Unplug from the power source. (Do this for few times). General Failure Wait for at least one minute before plugging the device.
