Explanation of the symbols on the device
Symbols are used in this manual to draw your attention to potential hazards. The safety symbols and the accompa-
nying explanations must be fully understood. The warnings themselves will not rectify a hazard and cannot replace
proper accident prevention measures.
Read the operating and safety instructions before start-up and follow them!
EN 60974-1 European standard for welding machines for manual arc welding with limited duty cycle.
Single-phase, static frequency, converter transformer rectifier
f
1~
1
f
2
Symbol for manual arc welding with coated rod electrodes (MMA)
Symbol for tungsten inert gas welding (LIFT TIG)
Direct current
Suitable for welding under increased electrical risk
Mains input; Number of phases as well as alternating current symbol and rated value of the
frequency
U
Rated idle voltage
0
U
Mains voltage
1
X
Duty cycle
l
Welding current
2
