  • Page 2 Grid-connected inverter 3PH 3.3K – 12K TL-V3 User Manual Zucchetti Centro Sistemi S.p.A. - Green Innovation Division Via Lungarno, 248 - 52028 Terranuova Bracciolini - Arezzo, Italy tel. +39 055 91971 - fax. +39 055 9197515 innovation@zcscompany.com - zcs@pec.it – www.zcsazzurro.com Reg.

  • Page 3: Table Of Contents

    Table of Contents Preliminary safety instructions ................................8 1.1. Safety instructions ..................................8 1.2. Symbols and icons .................................. 11 Product features ......................................13 2.1. Product presentation ................................13 2.2. Description of functions ..............................16 2.3. Module protection .................................. 17 2.4. Efficiency curve ..................................18 Installation ........................................
  • Page 4 6.4. Updating Inverter Software ............................... 61 Troubleshooting and maintenance ..............................63 7.1. Troubleshooting ..................................63 7.2. Maintenance ..................................... 71 Uninstalling ........................................72 8.1. Uninstallation steps ................................72 8.2. Packaging ....................................72 8.3. Storage ......................................72 8.4. Disposal ...................................... 72 Technical specifications ..................................73 Monitoring systems ..................................
  • Page 5 10.4.7.1. Mechanical description and Datalogger interface ..................118 10.4.7.2. Connecting the Datalogger to the inverters....................118 10.4.7.3. Internet connection via Ethernet cable ......................119 10.4.7.4. Connecting the power supply and battery pack to the Datalogger ............119 10.4.7.5. Connecting the LM2-485 PRO cell irradiance and temperature sensor to the datalogger ..120 10.4.8.
  • Page 6 Copyright statement Copyright of this manual belongs to Zucchetti Centro Sistemi S.p.A. No part of this manual (including the software, etc.) may be copied, reproduced or distributed in any form or by any means without the permission of Zucchetti Centro Sistemi S.p.A.
  • Page 7 Preface General information Please read this manual carefully before installation, use or maintenance. This manual contains important safety instructions that must be followed during installation and maintenance of the system. Scope This manual describes the assembly, installation, electrical connections, commissioning, maintenance and troubleshooting of the following inverters: 3PH 3.3K TL-V3/ 3PH 4.4K TL-V3/ 3PH 5.5K TL-V3 / 3PH 6.6K TL-V3/ 3PH 8.8K TL-V3 / 3PH 11K TL- V3 / 3PH 12K TL-V3...
  • Page 8 Caution: indicates a hazardous situation which, if not resolved or avoided, could result in minor or moderate personal injury. Caution Attention: indicates a potentially hazardous situation which, if not resolved or avoided, could result in damage to the system or other property. Attention Note: provides important tips on the correct and optimal operation of the product.

  • Page 9: Preliminary Safety Instructions

    For safety reasons, this inverter can only be installed by a qualified electrician with the necessary training and/or skills and knowledge. Zucchetti Centro Sistemi S.p.A. declines all responsibility for damage to property or personal injury caused by incorrect use of the device.
  • Page 10 If necessary, request assistance from an installer of photovoltaic systems or from Zucchetti Centro Sistemi SpA. Transport of the equipment, especially by road, must be carried out with vehicles suitable to protect the components (in particular, electronic components) against violent knocks, humidity, vibrations, etc.
  • Page 11 All installation operations must be carried out by a professional electrician, who must:  be prepared. Warning  Carefully read this manual and understand its contents. Before connecting the inverter to the grid, make sure that all the necessary permits have been obtained from the local grid operator and that all the electrical connections are made by a professional electrician.

  • Page 12: Symbols And Icons

     Do not disassemble the internal components of the inverter without permission. This will void the warranty. Zucchetti Centro Sistemi S.p.A. shall not be responsible for any damage or loss caused by these actions. Attention 1.2.
  • Page 13 installing the inverter. Residual voltage may be present on the inverter! Before opening the inverter, wait 5 minutes to ensure that the capacitors are completely discharged. Beware of high voltage Beware of high temperatures Complies with the European Standards (CE) Ground connection point Read this manual before installing the inverter.

  • Page 14: Product Features

    2. Product features General information in this chapter Product overview The field of use and overall dimensions of the 3PH 3.3K-12K TL-V3 inverters are indicated in this section. Description of functions It describes how the 3PH 3.3K-12K TL-V3 inverters and their internal operating modules work. Efficiency curve It describes the efficiency curves of the inverter.
  • Page 15 Figure 3 – Wiring diagrams of grid types on which the 3PH 3.3K-12K TL-V3 inverters can be installed Inverter components 1. DC switch 2. DC positive pole connectors 3. DC negative pole connectors 4. USB Port (for Wi-Fi / Ethernet / 4G communication) 5.
  • Page 16  The inverter model must be chosen by a qualified technician who knows the installation conditions, the devices that will be installed outdoors and the possible integration with existing systems.  Optional components of the inverter should be chosen by a qualified technician who is familiar with the installation conditions.

  • Page 17: Description Of Functions

     Labels on the inverter Figure 5 – Do not remove the label on the side of the inverter 2.2. Description of functions The DC voltage generated by the PV modules is filtered through the input board before entering the power board.

  • Page 18: Module Protection

    Inverter functions A. Energy management unit A.1 Feeding reactive power into the grid The inverter is capable of generating reactive power and can then feed it into the grid by setting the Power Factor. The feed-in management can be controlled directly by the grid operator via a dedicated RS485 serial interface.

  • Page 19: Efficiency Curve

    C. Grid monitoring Continuous monitoring of the grid voltage to ensure that the voltage and frequency values stay within the operating limits. D. Internal protection of the inverter device The inverter has all kinds of internal protections to protect the device and internal components when abnormal situations occur on the grid or DC input line.

  • Page 20: Installation

    3. Installation General information in this chapter This chapter describes how to install the 3PH 3.3K-12K TL-V3 inverter. Installation notes:  DO NOT install 3.3K-12K TL-V3 inverters near flammable materials.  DO NOT install 3.3K-12K TL-V3 inverters in an area where flammable or explosive materials are stored.

  • Page 21: Installation Process

    F. Installing the inverter This section describes the steps for installing the inverter on the wall 3.1. Installation process Figure 7 - Installation steps 3.2. Checks before installation Checking the outer packaging Packaging materials and components may be damaged during transport. Therefore, please check the materials of the outer packaging before installing the inverter.
  • Page 22 Pictures Description Quantity 3PH 3.3K-12K TL-V3 1 PCS Rear Panel 1 PCS M6*80 Hexagon screws 3 PCS 3.3KTL-V3 2 PCS 4.4KTL-V3 2 PCS 5.5KTL-V3 2 PCS PV+ input connector 6.6KTL-V3 2 PCS 8.8KTL-V3 2 PCS 11KTL-V3 2 PCS 12KTL-V3 3 PCS 3.3KTL-V3 2 PCS 4.4KTL-V3...
  • Page 23 3.3KTL-V3 2 PCS 4.4KTL-V3 2 PCS 5.5KTL-V3 2 PCS PV+ metal pin 6.6KTL-V3 2 PCS 8.8KTL-V3 2 PCS 11KTL-V3 2 PCS 12KTL-V3 3 PCS 3.3KTL-V3 2 PCS 4.4KTL-V3 2 PCS 5.5KTL-V3 2 PCS PV- metal pin 6.6KTL-V3 2 PCS 8.8KTL-V3 2 PCS 11KTL-V3 2 PCS...

  • Page 24: Installation Tools

    Communication 1 PCS Terminal Manual 1 PCS Warranty card 1 PCS Quality Certificate 1 PCS 3.3. Installation tools The following tools are required for installation of the inverter and electrical connections; therefore, they must be prepared before installation. 23 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.
  • Page 25 Tool Function Drill To drill holes in the wall for fixing the bracket Recommended drill bit: 8mm To screw and unscrew screws for Screwdriver the various connections Wire stripper To prepare the cables for wiring Adjustable spanner (opening To tighten the bolts greater than 32 mm) To crimp the RJ45 connectors for RJ45 crimping tool...

  • Page 26: Installation Position

    To mark the wall for better fixing Marker pen precision Measuring tape To measure distances Level To make sure the bracket is level ESD gloves Protective clothing Safety goggles Protective clothing Protection mask Protective clothing 3.4. Installation position Choose an appropriate installation location for the inverter. Follow the requirements below to determine the installation position.
  • Page 27 Figure 8 - Requirements or installing a single inverter 26 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...

  • Page 28: Moving The 3Ph 3.3K-12K Tl-V3 Inverter

    Figure 9 - Requirements for installing multiple inverters Note: For safety reasons, ZCS Spa and/or its partners may not carry out any technical repairs or maintenance work, or move the inverter from and to the ground if it is installed at a height of more than 180 cm from the ground.

  • Page 29: Installing The 3Ph 3.3K-12K Tl-V3 Inverter

    3.6. Installing the 3PH 3.3K-12K TL-V3 inverter 1) Correctly position the mounting bracket on the wall using a level to ensure that it is straight; mark the 3 holes using a suitable marker pen. Keeping the hammer drill perpendicular to the wall and avoiding any sudden movements when drilling, drill the 3 holes at the points marked on the wall using an 8 mm drill bit.

  • Page 30: Electrical Connections

    4. Electrical connections General information in this chapter This chapter describes the electrical connections of the 3PH 3.3K-12K TL-V3 inverter. Carefully read this section before connecting the cables. NOTE: Before making any electrical connections, ensure that the DC and AC circuit breakers are open. Remember that the accumulated electrical charge remains in the inverter capacitor after the DC and AC circuit breakers have been switched off.

  • Page 31: Electrical Connections

    4.1. Electrical connections Figure 11 – Steps for connecting the cables 4.2. Connecting PNGD cables (grounding) Connect the 3PH 3.3K-12K TL-V3 inverter to the ground electrode using ground protection cables (PGND). The inverter does not have a transformer, therefore the positive and negative polarities of the photovoltaic string do NOT need to be grounded.
  • Page 32 Figure 12 - Connecting the ground terminal Prerequisites: Prepare the PGND cables to be connected (outdoor power cables with a cross-section of 8 mm recommended for grounding purposes); it is recommended to use yellow-green cables for better identification. Procedure: 1) Remove an adequate length of the external insulation layer using a wire stripper, as shown in Figure Note: L2 is approximately 2-3 mm longer than L1 Figure 13 –...

  • Page 33: Connecting The Dc Input Power Cables

    Note 2: The cavity formed after the conductor has been crimped must completely wrap the conductor wires. The core of the wire must be in close contact with the terminal. Figure 14 – Preparing the ground cable (2) 3) Install the crimped OT terminal and flat washer using the M6 screw in the hole located on the inverter heatsink, as shown in the figure;...
  • Page 34 The positive and negative polarities of the panels on the inverter must be connected separately. The power cable must be suitable for photovoltaic applications. Note: Both MPPT inputs of the inverter should be populated, even if the system only has one string. If the strings are arranged in parallel, it is recommended to use a Y or T connection cable to double the input currents from the PV field and to populate both MPPT inputs of the inverter, as shown in the figure.
  • Page 35  Before connecting the power supply, be sure to disconnect the generator’s DC switch. When exposed to the sun, the photovoltaic generator produces a voltage that can be dangerous!  Before connecting the power supply, make sure that the voltage of the DC cables Danger is within the permissible operating range, and that the DC circuit breaker switch is open.
  • Page 36 Figure 16 – Positive (1) and Negative (2) MC4 connectors Note The positive and negative metal terminals are packed together with the positive and negative connectors respectively. Separate the positive and negative metal terminals after unpacking the inverter so as to avoid confusing the polarities.
  • Page 37 Figure 18 - Connecting the DC input power cables (2) 5) Insert the crimped power cables in the corresponding seats until you hear a “click” sound. At that point, the power cables will snap into place. 6) Replace the cable glands on the positive and negative connectors and rotate them against the insulation covers.

  • Page 38: Connecting The Ac Output Power Cables

    Warning inverter’s circuit breaker is switched off. If not, the direct current may cause an electric arc that could result in a fire Figure 20 – Removing the DC connector 4.4. Connecting the AC output power cables Connect the inverter to the AC power distribution network or power grid using AC power cables. ...
  • Page 39 Figure 21 - Do not connect loads between the inverter and circuit breaker Multi-core copper cables The cross-section of the power line must be sized in order to prevent unwanted disconnections of the inverter from the grid due to high impedance of the cable connecting the inverter to the point of supply.
  • Page 40 The 3.3K-12K TL-V3 inverters are three-phase output inverters that comply fully with the local grid connection requirements and safety standards. The inverters are equipped with AC output connectors with IP66 protection suitable for photovoltaic use; customers must provide their own AC output cable connections. Cable connection procedure 1) Identify the suitable cable section as shown in the table and remove an appropriate length of the protective sheath, as shown in the figure (A: 30~50 mm B: 3~5 mm).
  • Page 41 Figure 24 - Connecting the AC output cables (3) Figure 25 - Connecting the AC output cables (4) 40 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...

  • Page 42: Connecting The Communication Cables

    4.5. Connecting the communication cables The 3PH 3.3K-12K TL-V3 inverters have two communication interfaces, the USB interface and the port COM, as shown in the figure below. Figure 26 – Bottom view of the inverter with RS485 (1) and COM port (2) USB port USB flash disk access Use for updating the software...
  • Page 43 Procedure Figure 27 – USB port connector Figure 28 – USB stick mounting (1) Figure 29 – USB stick mounting (2) 42 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...
  • Page 44 COM port Recommended cable size for the COM port. Name Type Outer diameter (mm) Area (mm²) RS485 Outdoor shielded twisted pair 2 or 3core: 4~8 0.25~1 meets local standards Communication Wire COM port description. Define Function Note RS485A RS485 signal+ RS485A RS485 signal+ Wire connection monitoring or...
  • Page 45 Figure 30 – COM connector Figure 31 – COM connector installation 44 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...

  • Page 46: Commissioning The Inverter

    5. Commissioning the inverter 5.1. Safety inspection before commissioning Make sure that the DC and AC voltages fall within the range permitted by the inverter. Attention  Photovoltaic strings Before turning on the inverter, the photovoltaic string must be examined. Check the open-circuit voltage of each photovoltaic panel and compare it with the data in the technical datasheet.

  • Page 47: Starting The Inverter

    If in doubt, consult the system engineer or a qualified electrician. Zucchetti Centro Sistemi S.p.A. shall not be held responsible for any consequences resulting from the incorrect selection of the country code. If the inverter indicates the presence of any faults, refer to related chapter of this manual or contact the Zucchetti Centro Sistemi S.p.A.

  • Page 48: Operating Interface

    6. Operating interface General information in this chapter This section describes the display and its operation, as well as the buttons and LED indicators of the 3PH 3.3K-12K TL-V3 inverters. 6.1. Operating panel and display Buttons and LED indicators Figure 32 - LCD display with buttons and LED indicators Main buttons: ...

  • Page 49: Main Interface

    6.2. Main interface LCD interface indicated inverter status, alarm information, communication connection, PV input current and voltage, grid voltage, current and frequency, today generation, total generation. Inverter working status, PV 1 input voltage and current. Inverter working status, PV 2 input voltage and current. Inverter working status, PV generated power.
  • Page 50 Inverter working status, total generated electricity. Inverter working status, grid voltage and current. Inverter working status, grid voltage and frequency. Inverter working status, USB status. 49 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...
  • Page 51 Inverter faulty alarm. When control board successfully connected with communication board, the LCD display the current state of the inverter, display as shown in the figure below. 50 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev.
  • Page 52 Inverter states includes: wait, check, normal and fault. Inverter statuses include: Wait: the inverter is waiting for the control status at the end of the reconnection time. In this state, the PV voltage must be higher than 250 V, the grid voltage value must be between the minimum and maximum permissible limits, as should the other grid parameters;...

  • Page 53: Main Menu

    6.3. Main menu Long press the down button under standard interface to enter into main interface, Main interface including below information: ---------Long press DOWN Normal button 1.Enter Setting 2.Event List 3.SystemInfo 4.Display Time 5.Software Update Enter setting Interface as below --------Long press DOWN 1.Enter Setting button...
  • Page 54 Long press the button to Enter the main interface of "1. Enter Setting" and long press to enter the setting menu. You can select the content you want to set by short pressing the button. Note1: Some settings need to enter the password (the default password is 0001), when entering the password, short press to change the number, long press to confirm the current number, and long press after entering the correct password.
  • Page 55 Code Country Code Country Germany VDE4105 EU EN50438 Germany BDEW EU EN50549 Germany VDE0126 IEC EN61727 Italia CEI-021 Internal Korea Italia CEI-016 Italia Sweden Italia CEI-021 External Europe General Italia CEI0-21 In Areti Cyprus Australia India Australia AU-WA Philippines Australia AU-SA New Zealand Australia AU-VIC Brazil...
  • Page 56 Netherland Thailand PEA Belgium Thailand MEA UK G59/G99 LV-Range-50Hz UK G83/G98 South Africa China Dubai DEWG China Taiwan Dubai DEWG MV France Croatia France FAR Arrete23 Lithuania Poland  Contr On-Off Inverter on-off local control.  Set Energy Set the total power generation. You can modify the total power generation through this option. ...
  • Page 57  Logic interface Enable or disable logical interfaces. It is use for below standard Australia (AS4777), Europe General (50549), German (4105).  Set Power Ratio. Set generation ratio.  Autotest Fast 56 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.
  • Page 58 57 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...
  • Page 59  Autotest STD The test procedure is same as Autotest Fast, but it’s much more time consuming. 58 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...
  • Page 60 Event list Event List is used to display the real-time event records, including the total number of events and each specific ID No. and happening time. User can enter Event List interface through main interface to check details of real-time event records, Event will be listed by the happening time, and recent events will be listed in the front.
  • Page 61  Inverter type Use the “Up” and “Down” keys in the “System Info” menu to move, and the “OK” key to enter menu “1. Inverter type.” Here you can see the power of the inverter model  Serial number Use the “Up” and “Down” keys in the “System Info” menu to move, and the “OK” key to enter menu “2. Serial number.”...

  • Page 62: Updating Inverter Software

    Software Update User can update software by USB flash disk, Zucchetti Centro Sistemi S.p.a. will provide the new update software called firmware for user if it is necessary, the user needs to copy the upgrade file to the USB flash disk.
  • Page 63 Step 8：System update main DSP, slave DSP and ARM in turns. If main DSP update success, the LCD will display “Update DSP1 Success", otherwise display "Update DSP1 Fail"; If slave DSP update success, the LCD will display"Update DSP2 Success", otherwise display "UpdateDSP2 Fail". Step 9：After the update is completed, turn off the DC breaker, wait for the LCD screen extinguish, then recover the communication waterproof and then turn on the DC breaker and AC breaker again, the inverter will enter the running state.

  • Page 64: Troubleshooting And Maintenance

    7. Troubleshooting and maintenance 7.1. Troubleshooting This section contains information and procedures on how to troubleshoot any faults and errors that may occur during operation of the 3.3K-12K TL-V1 inverter. If you have any problems with the inverter, please follow these steps. ...
  • Page 65 If the alarm occurs frequently, check whether the grid voltage/frequency is The grid frequency is too ID03 GridOFP within the correct range. If not, contact high. technical support. If so, check the AC circuit breaker and the AC wiring of the inverter.
  • Page 66 mounted in series, making sure that it falls within the input voltage range of the inverter. The inverter automatically returns to its normal operating state after the correct adjustments. Check the configuration of the input The input current is not ID10 IpvUnbalance mode (parallel mode / independent...
  • Page 67 ID22 HwAuxPowerFault Auxiliary voltage error ID23 BusVoltZeroFault Current sampling error. The output current is not ID24 IacRmsUnbalance balanced. If the configuration of the PV string is correct (no ID05 fault present), the possible cause is that the solar radiation The bus voltage is too ID25 BusUVP is too low.
  • Page 68 wiring; if both are correct, contact Technical Support. ID33 Reserved Reserved Reserved The grid voltage sampling value between ID49 ConsistentFault_VGrid the master DSP and slave DSP is not suitable. The grid frequency sampling value between ID50 ConsistentFault_FGrid the master DSP and slave DSP is not suitable.
  • Page 69 The temperature of the ID57 OverTempFault_Inv Check that the installation position and inverter is too high the installation method meet the requirements of relative sectionof this user manual. The temperature of the ID58 OverTempFault inverter is too high. Check if the ambient temperature in the installation location exceeds the allowed limit.
  • Page 70 Check the configuration of the input mode (parallel mode / independent mode) of the inverter, as indicated in ID71 UnrecoverPvConfigSetWrong Incorrect input mode relative section (C) “6. Input Mode” of this user manual. If it is not correct, change it according to relative section (A).
  • Page 71 The inverter registers ID 84 in case of remote shutdown operation. Check the The inverter has shut off wiring of the remote input and the port ID84 RemoteOff the motor via remote of the output control signal on the control. communication board, according to relative section of this user manual.

  • Page 72: Maintenance

    ID100 Reserved Reserved 7.2. Maintenance Inverters generally do not require daily or routine maintenance. In any case, for proper long-term operation of the inverter, make sure that the heatsink for cooling the inverter has enough space to ensure adequate ventilation and that it is not obstructed by dust or other items. Cleaning the inverter Use an air compressor, a soft dry cloth or soft-bristled brush to clean the inverter.

  • Page 73: Uninstalling

    8.4. Disposal Zucchetti Centro Sistemi S.p.a. is not liable for the disposal of the equipment, or parts thereof, that does not take place according to the regulations and standards in force in the country of installation. The symbol of the crossed-out wheeled bin indicates that the equipment, at the end of its useful life, must be disposed of separately from household waste.

  • Page 74: Technical Specifications

    9. Technical specifications 73 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...

  • Page 75: Monitoring Systems

    10. Monitoring systems 10.1. External Wi-Fi adapter 10.1.1. Installation Unlike the internal Wi-Fi card, the external adapter must be installed for all compatible inverters. However, the procedure is quicker and easier as there is no need to open the front cover of the inverter. In order to monitor the inverter, the RS485 communication address must be set to 01 directly from the display.
  • Page 76 Figure 34 – Port for external Wi-Fi adapter 3) Connect the Wi-Fi adapter to the appropriate port, making sure to follow the direction of the connection and ensure correct contact between the two parts. Figure 35 – Inserting and securing the external Wi-Fi adapter 75 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.

  • Page 77: Configuration

    4) Switch on the inverter by following the procedure described in the manual. 10.1.2. Configuration Configuration of the Wi-Fi adapter requires the presence of a Wi-Fi network near the inverter in order to achieve stable transmission of data from the inverter adapter to the Wi-Fi modem. Tools required for configuration: ...
  • Page 78 Note: Disconnect from any Wi-Fi networks to which you are connected by removing automatic access. Figure 37 – Disabling automatic reconnection to a network 2) Connect to a Wi-Fi network generated by the inverter's Wi-Fi adapter (i.e. AP_*******, where ******* indicates the serial number of the Wi-Fi adapter shown on the label of the device), which operates as an access point.
  • Page 79 Figure 39 – Password of external Wi-Fi adapter Note: To ensure that the adapter is connected to the PC or smartphone during the configuration procedure, enable automatic reconnection of the AP_******* network. Figure 40 – Password entry prompt 78 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.
  • Page 80 Note: the Access Point is not able to provide internet access; confirm to maintain the Wi-Fi connection, even if the internet is not available Figure 41 – Screen indicating that the Internet cannot be accessed 4) Open a browser (Google Chrome, Safari, Firefox) and enter the IP address 10.10.100.254 in the address bar at the top of the screen.
  • Page 81 Figure 42 – Screen for accessing the web server to configure the Wi-Fi adapter 5) The status screen will open, showing the logger information such as the serial number and firmware version. Check that the Inverter Information fields are filled in with the inverter information. The language of the page can be changed using the command in the top right-hand corner.
  • Page 82 Figure 43 – Status screen 6) Click on the Wizard setup button in the left-hand column. 7) In the new screen that opens, select the Wi-Fi network to which you want to connect the Wi-Fi adapter, making sure that the Received Signal Strength Indicator (RSSI) is greater than 30%. If the network is not visible, press the Refresh button.
  • Page 83 Figure 44 – Screen for selecting the available wireless network (1) 8) Enter the password of the Wi-Fi network (Wi-Fi modem), clicking on Show Password to make sure it is correct; the password should not contain special characters (&, #, %) and spaces. Note: During this step, the system is not able to ensure that the password entered is the one actually requested by the modem, therefore please make sure you enter the correct password.
  • Page 84 Figure 45 – Screen for entering the password of the wireless network (2) 9) Click “Next” again without ticking any of the options relating to the system security. Figure 46 - Screen for setting the security options (3) 83 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.
  • Page 85 10) Click “OK”. Figure 47 – Final configuration screen (4) 11) At this point, if the configuration of the adapter is successful, the last configuration screen will appear, and the telephone or PC will unpair from the inverter’s Wi-Fi network. 12) Manually close the web page with the Close key on the PC por remove it from the background of the telephone.

  • Page 86: Verification

    Figure 48 - Successful configuration screen 10.1.3. Verification Wait two minutes after configuring the adapter and then go back to the Wi-Fi network selection screen to verify that the AP_******* network is no longer present. The absence of the Wi-Fi network in the list will confirm the successful configuration of the Wi-Fi adapter.
  • Page 87 If the Wi-Fi network is still present in the list, connect to it again and enter the status page. Check the following information: a. Wireless STA mode i. Router SSID > Router name ii. Signal Quality > other than 0% iii.
  • Page 88 Figure 51 - Initial status of LEDs 2) Final status: NET (left LED): steady on COM (central LED): steady on READY (right LED): flashing on Figure 52 - Final status of LEDs If the NET LED does not light up or if the Remote Server A option in the Status page still shows “Not Connected”, the configuration was not successful, i.e.

  • Page 89: Troubleshooting

    It is necessary to reset the adapter: Press the Reset button for 10 seconds and release After a few seconds, the LEDs will turn off and READY will start to flash quickly The adapter has now returned to its initial state. At this point, the configuration procedure can be repeated again.
  • Page 90 Figure 54 - Irregular communication status between inverter and Wi-Fi Check the Modbus address set on the inverter: Enter the main menu with the ESC key (first key on the left), go to System Info and press ENTER to enter the submenu. Scroll down to the Modbus address parameter and make sure it is set to 01 (and in any case, other than 00).
  • Page 91 2) Irregular communication with remote server NET (left LED ): off COM (central LED): on READY (right LED): flashing on Figure 56 - Irregular communication status between Wi-Fi and remote server Check that the configuration procedure has been carried out correctly and that the correct network password has been entered.
  • Page 92  Using an Android mobile phone as a modem a) Check that the 3G/LTE connection is active on your smartphone. Go to the Settings menu of the the phone), operating system (the gear icon on the screen with a list of all the apps installed on select “Other”...
  • Page 93 Figure 58 - Configuration of an iOS smartphone as a hotspot router At this point, it is necessary to re-configure the Wi-Fi adapter using a PC or smartphone other than the one used as a modem. During this procedure, when asked to select the Wi-Fi network, choose the one activated by the smartphone and then enter the password associated with it (which can be changed from the personal hotspot settings).

  • Page 94: Ethernet Adapter

    10.2. Ethernet adapter 10.2.1. Installation Installation must be carried out for all inverters compatible with the adapter. However, the procedure is quicker easier there need open front cover inverter. Proper operation of the device requires the presence of a modem correctly connected to the network and in operation in order to achieve stable data transmission from the inverter to the server.
  • Page 95 3) Remove the ring nut and the waterproof cable gland from the adapter to allow the network cable to pass through; then insert the network cable network into the appropriate port on the inside of the adapter and tighten the ring nut and cable gland to ensure a stable connection. Figure 60 –...

  • Page 96: Verification

    5) Connect the other end of the network cable to the ETH output (or equivalent) of the modem or a suitable data transmission device. Figure 62 – Connecting the network cable to the modem 6) Switch on the inverter by following the procedure described in the manual. 7) Unlike Wi-Fi cards, the Ethernet adapter does not need to be configured and starts transmitting data shortly after the inverter is switched on.
  • Page 97 Figure 63 - Initial status of LEDs 2) Final status: NET (left LED): steady on COM (central LED): steady on SER (right LED): flashing on Figure 64 - Final status of LEDs 96 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.

  • Page 98: Troubleshooting

    10.2.3. Troubleshooting Status of LEDs present on the adapter Irregular communication with inverter NET (left LED): steady on COM (central LED ): off SER (right LED): flashing on Figure 65 - Irregular communication status between the inverter and adapter Check the Modbus address set on the inverter: Enter the main menu with the ESC key (first key on the left), go to System Info and press ENTER to enter the submenu.

  • Page 99: Adapter

    Figure 66 - Irregular communication status between the adapter and remote server Check that the router has access to the network and that the connection is stable; check that a PC can access the Internet Check that port 80 of the router is open and enabled to send data. It is advisable to check the brand and model of the home router you are trying to connect to the Ethernet adapter;...
  • Page 100 Installation tools:  Cross screwdriver  4G adapter 1) Switch off the inverter following the procedure described in this manual. 2) Remove the cover for accessing the Wi-Fi/ GPRS connector on the bottom of the inverter by unscrewing the two cross-head screws (a), or by unscrewing the cover (b), depending on the inverter model, as shown in the figure.
  • Page 101 Figure 68 – Inserting and securing the 4G adapter 4) Switch on the inverter by following the procedure described in the manual. 5) Unlike Wi-Fi cards, the 4G adapter does not need to be configured and starts transmitting data shortly after the inverter is switched on.

  • Page 102: Verification

    10.3.2. Verification After installing the adapter, within the next 3 minutes check the status of the LEDs on the device to ensure that the device is configured correctly. Status of LEDs present on the adapter 1) Initial status: NET (left LED ): off COM (central LED): flashing on SER (right LED): flashing on Figure 69 - Initial status of LEDs...
  • Page 103 Figure 70 - Final status of LEDs Status of LEDs present on the adapter 1) Irregular communication with inverter NET (left LED): on COM (central LED ): off SER (right LED): on Figure 71 - Irregular communication status between inverter and adapter Check the Modbus address set on the inverter: Enter the main menu with the ESC key (first key on the left), go to System Info and press ENTER to enter the submenu.
  • Page 104 Check that the 4G adapter is correctly and securely connected to the inverter, making sure to tighten the two cross-head screws provided. 2) Irregular communication with remote server: NET (left LED): flashing on COM (central LED): on SER (right LED): flashing on Figure 72 - Irregular communication status between the adapter and remote server Check that the 4G signal is present in the installation location (the adapter uses the Vodafone network for 4G transmission;...

  • Page 105: Datalogger

    10.4. Datalogger 10.4.1. Preliminary notes on how to configure the datalogger The AzzurroZCS inverters can be monitored via a datalogger connected to a Wi-Fi network present at the place of installation or via an ethernet cable connected to a modem. The inverters are connected in a daisy chain to the datalogger via a RS485 serial line.

  • Page 106: Electrical Connections And Configuration

    All these devices carry out the same function, i.e. they transmit data from the inverters to a web server to allow remote monitoring of the system either through the “Azzurro Monitoring” app or through the “www.zcsazzurroportal.com” website. All the Azzurro ZCS inverters can be monitored using the datalogger; different models or families of inverters can also be monitored.
  • Page 107 Figure 76 – Tightening the network cable to the RS485 terminal block Figure 77 – Connecting the serial line via the RS485 terminal block and via the RJ45 plug For the 3PH HYD5000-HYD20000-ZSS three-phase hybrid inverter, use only one positive and one negative of those shown in the figure below.
  • Page 108 c. Position the dip switches of the last inverter of the daisy chain as shown in the figure below for activating the 120 Ohm resistor and closing the communication chain. If there are no switches, physically connect a 120 Ohm resistor to terminate the bus. Figure 79 –...

  • Page 109: Zsm-Datalog-04 And Zsm-Datalog-10 Devices

    10.4.3. ZSM-DATALOG-04 AND ZSM-DATALOG-10 DEVICES The initial status of the LEDs on the datalogger will be:  POWER steady on  485 steady on  LINK off  STATUS steady on 10.4.4. WI-FI CONFIGURATION To configure the datalogger via Wi-Fi, please refer to the chapter on monitoring systems, as the configuration is similar to that of any type of Wi-Fi adapter.
  • Page 110 Figure 82 - Wi-Fi network search on iOS smartphone (left) and Android (right) Note: Disconnect from any Wi-Fi networks to which you are connected by removing automatic access. Figure 83 - Disabling automatic reconnection to a network Connect to a Wi-Fi network generated by the datalogger (i.e. AP_*******, where ******* indicates the serial number of the datalogger shown on the label of the device), which operates as an Access Point.
  • Page 111 Figure 84 - Password entry prompt Note: the Access Point is not able to provide internet access; confirm to maintain the Wi-Fi connection, even if internet is not available. Figure 85 - Screen showing that the Internet cannot be accessed Open a browser (Google Chrome, Safari, Firefox) and enter the IP address 10.10.100.254 in the address bar at the top of the screen.
  • Page 112 Figure 86 - Screen for logging into the web server to configure the datalogger The status screen will open, showing the datalogger information such as serial number and firmware version. Check that the fields relating to the Inverter Information are filled in with the information of all the inverters connected.
  • Page 113 Click on the Wizard setup button in the left-hand column. Now click on the Start button to start the configuration wizard. Figure 88 – Screen for starting (1) the Setup Wizard Check the “Cable Connection” option and then click “Next.” Figure 89 - Network cable connection selection screen 112 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3...
  • Page 114 Make sure that the “Enable” option is selected to automatically obtain the IP address from your router, then click Next. Figure 90 – Screen for automatically obtaining the IP address (5) Click on Next without making any changes. Figure 91 - Screen for setting the security options (6) 113 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev.
  • Page 115 Complete the configuration procedure by clicking OK, as shown in the following screen. Figure 92 – Final configuration screen (7) If the configuration procedure is successful, the following screen will appear. If this screen does not appear, try refreshing the browser page. The screen will prompt you to manually close the page;...

  • Page 116: Checking That The Datalogger Has Been Configured Correctly

    10.4.6. Checking that the datalogger has been configured correctly Wait two minutes after completing the configuration of the device. First of all, check that the LINK LED on the device is on and steady. Figure 94 – LED indicating the correct configuration of the datalogger Enter the IP address 10.10.100.254 again, and the login credentials (“admin”...
  • Page 117 Figure 95 – Main status screen and checking of correct configuration Figure 96 - main status screen and checking of correct configuration If the Remote Server A item in the Status page is still “Unpingable”, the configuration was not successful, i.e. the incorrect router password was entered or the device was disconnected during connection.
  • Page 118 Figure 97 – Reset Screen 117 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev. 1.1 of 12/03/2021 - Application: GID...

  • Page 119: Zsm-Rms001/M200 And Zsm-Rms001/M1000 Devices

    10.4.7. ZSM-RMS001/M200 and ZSM-RMS001/M1000 Devices 10.4.7.1. Mechanical description and Datalogger interface Mechanical Dimensions: 127mm x 134 x 52 mm Protection rating: IP20 The usable ports are indicated below. LAN cable connection port RS485 cable connection port Battery pack Power supply connection port connection port Figure 98 - Datalogger rear panel...

  • Page 120: Internet Connection Via Ethernet Cable

    The GND cable does not need to be connected to the inverters. Follow the connections as shown in the table below. SENSOR SIDE Datalogger SIDE BUS Signal Inverter SIDE (ZSM-IRR-TEMP-LM2) RS485+IB terminal +Tx terminal D+ terminal RS485-IA terminal -Tx terminal D–...

  • Page 121: Connecting The Lm2-485 Pro Cell Irradiance And Temperature Sensor To The Datalogger

    10.4.7.5. Connecting the LM2-485 PRO cell irradiance and temperature sensor to the datalogger For proper installation, make sure to connect the sensor signal cable and the power cable. In particular, the sensor of the signal cables must be connected in a daisy chain configuration to the remaining devices on the RS485 bus, as shown in the table below.

  • Page 122: Configuring The Datalogger

    (12Vdc output voltage) Terminal GND terminal BLACK 0V Terminal (GND/RTN) V2 terminal (12Vdc driveable voltage) Table 4: Electrical connection of the sensor to the datalogger (power supply) A stable communication in terms of signal and power supply, up to 200m, is guaranteed by using the RS485 cable, type Te.Co.
  • Page 123 In the configuration page, you can search for any devices connected to the datalogger (inverter, meter or sensors) by clicking the + button, as shown in the figure. A window will open where you can search for each type of device connected to the Datalogger, after indicating the range of addresses associated with the relative devices.

  • Page 124: Configuring The Datalogger On The Zcs Azzurro Portal

    Once this operation has been completed, update the new configuration by clicking “Confirm,” which will allow you to register the devices associated with the datalogger. From this moment, the datalogger is correctly configured (all devices must be in the “saved” status) and therefore a new installation can be created on the ZCS Azzurro portal for associating the datalogger and the devices connected to it.

  • Page 125: Network Configuration

    Access the ZCS Azzurro portal (https://www.zcsazzurroportal.com). For new users, click “Sign up now” to register on the portal by entering your email, username and password. After logging into the portal, click “Configuration Panel”, and then select the option “Create field with Datalogger.” The “Create New Field” operation will be possible only if the user’s privileges allow acquiring new fields (at the time of registration the limit will be equal to 1, an upgrade is required to increase the limit).

  • Page 126: Local Monitoring

    By entering the credentials: username = admin and password = admin, you can change the configuration from dynamic to static by selecting the network window (see blue arrow) and then the “STATIC” option (see green arrow). To complete the operation, click “Apply” (see arrow).

  • Page 127: Requirements For Installation Of Local Monitoring

    10.4.9.1. Requirements for installation of local monitoring In order to install the local monitoring system on the datalogger, the customer must ensure that:  The datalogger is connected to the local network and to the internet (the internet connection is only required during installation and configuration of the local monitoring system).

  • Page 128: Warranty Terms And Conditions

    11. Warranty terms and conditions To view the “Warranty Terms and Conditions” offered by ZCS Azzurro, please refer to the documentation inside the product box and on the website www.zcsazzurro.com. 127 / 127 User’s Manual 3PH 3.3KTL -12K TL-V3 Rev. 1.1 12/03/2021 Identification: MD-AL-GI-00 Rev.

Table of Contents
