3.3
Graphics Card Installation
WARNING
To reduce the risk of damage, DO NOT remove the graphics card from the antistatic bag
before it is ready to be installed into the Cassette module!
NOTE
For installation compatibility, please consult with Neousys before purchasing a graphics
card.
3.3.1
Nuvo-8108GC Graphics Card Installation
The system can support an NVIDIA graphics card up to 250W. The placement of the rear
exhaust fan creates a sealed wind tunnel to bring in cold air to the graphics cards and expels
hot air to offer extreme system stability and reliability. To install a PCIe graphics card, please
refer to the following procedure:
To install a PCIe graphics card into the Cassette module, please refer to the following
procedure:
1.
Please refer to the section
2.
Locate the PCIe x16 slots on the daughter board (indicated in red).
Nuvo-8108GC Series
"Disassembling the
System".
84
