Nuvo-4000 Series User's Manual

Neousys Technology Inc.

Nuvo-4000 Series

Intel® 3rd-Gen Core™ i7/i5 Fanless Box-PC

with 4x PCIe/PCI Expansion Slots

Nuvo-4022 / Nuvo-4040

User's Manual

Rev. A1

Published April 17

, 2014

Page 1 of 76

Table of Contents

Summary of Contents for Neousys Technology Nuvo-4022

Page 1 Neousys Technology Inc. Nuvo-4000 Series Intel® 3rd-Gen Core™ i7/i5 Fanless Box-PC with 4x PCIe/PCI Expansion Slots Nuvo-4022 / Nuvo-4040 User’s Manual Rev. A1 Published April 17 , 2014 Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 1 of 76...
Page 2: Table Of Contents
2.3.4 DDR3 SODIMM Socket ................22 2.3.5 SATA Connectors ..................23 2.3.6 PCI Slots ....................23 2.3.7 PCI Express Slots (Nuvo-4022 Only) ............24 2.3.8 Optional Isolated DIO ................26 2.4 Mechanical Dimension ..................28 2.4.1 Front View ....................28 2.4.2 Back View ....................
Page 3 Wiring for DIO ....................68 DIO Function Reference .................. 69 A.4 Using COS Function ..................... 72 Change-of-State DIO Function Reference ............72 Change-of-State DI Example ................74 Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 3 of 76...
Page 4: Declaimer
This manual is intended to be used as a practical and informative guide only and is subject to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys shall not be liable for direct, indirect, special, incidental, or consequential damages arising out of the use of the product or documentation, nor for any infringements upon the rights of third parties, which may result from such use.
Page 5: Chapter 1 Introduction
A notable 48W power budget is dedicatedly supplied to the x16 PCIe slot for powering a high-watt PCIe card (e.g. a graphics card). Nuvo-4022/4040 also has PCI slots to accommodate up to 4 PCI cards for general industrial automation and test &...
Page 6: Product Specification
1x 4-pin power connector for 8~25V DC input With i7-3610QE: 66.12W (3.48A@19V)* Power Consumption With i5-3610ME: 43.13W (2.27A@19V)* Mechanical Dimension 164 mm (W) x 178 mm (D) x 225 mm (H) Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 6 of 76...
Page 7 ** 100% CPU loading is applied using Intel® Thermal Analysis Tool. For detail testing criteria, please contact Neousys Technology *** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is required. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 7 of 76...
Page 8: Specification Of Nuvo-4040
4.0 kg (with one 2.5” HDD and DDR3 memory module) Mounting Wall-mounting (Standard) or DIN-Rail mounting (Optional) Environmental Operating -20°C ~ 60°C, 100% CPU loading **/*** Temperature Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 8 of 76...
Page 9 ** 100% CPU loading is applied using Intel® Thermal Analysis Tool. For detail testing criteria, please contact Neousys Technology *** For sub-zero operating temperature, a wide temperature HDD drive or Solid State Disk (SSD) is required. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 9 of 76...
Page 10: Specification Of Optional Isolated Dio
No. of Channel Sink Current 100 mA (sustained loading) (per channel) 250 mA (peak loading) Isolated Voltage 2500 Vrms Output Type Power MOSFET + Analog Device iCoupler® Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 10 of 76...
Page 11: Chapter 2 Getting To Know Your Nuvo-4000
When you receive the package of Nuvo-4000 series, please check immediately if the package contains all the items listed in the following table. If any item is missing or damaged, please contact your local dealer or Neousys Technology Inc. for further assistance.
Page 12: Front Panel I/O Functions
To avoid unexpected operation, the reset button is hidden behind the front panel. You need to use a pin-like object to push the reset button. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 12 of 76...
Page 13: Led Indicators
7 or later version. For Windows XP, please refer to section 4.1.3 XHCI Support to disable XHCI mode to avoid possible issue of using USB3 devices in XP. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 13 of 76...
Page 14: Gigabit Ethernet Port
To utilize the GbE port, you need to install corresponding driver for Intel I210 GbE ® controller. Please refer to section 4.3 for information regarding driver installation. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 14 of 76...
Page 15: Dvi-I Connector
The feature of triple independent display outputs is only available in Windows XP/7/8 with corresponding graphics driver installed. Please refer to section 4.3 for information regarding driver installation. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 15 of 76...
Page 16: Com Ports
COM1 & COM2 COM3 RS-485 Mode Pin# RS-232 Mode RS-422 Mode RS-232 Mode (Two-wire 485) 422 TXD+ 485 TXD+/RXD+ 422 RXD+ 422 RXD- 422 TXD- 485 TXD-/RXD- Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 16 of 76...
Page 17: Speaker-Out Jack
Neousys. Caution Please make sure the voltage of DC power is correct before you connect it to Nuvo-4000. Supplying a voltage over 25V will damage the system. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 17 of 76...
Page 18 Neousys also offers an optional power cable for the deployment where DC is available. You can wire the cable to DC power source (red for V+, black for GND) and connect the power plug to the 4-pin mini-DIN connector on Nuvo-4000. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 18 of 76...
Page 20: Internal Usb2.0 Pin Header
The internal USB ports are designed to allow users attaching a protection dongle inside the chassis. To use the internal USB port, you need a dedicated box-header to USB cable. Please contact Neousys for further information Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 20 of 76...
Page 21: Cfast Socket
Pin Definition USB 5V Power, Max 500mA USB 5V Power, Max 500mA USB8 D- USB9 D- USB8 D+ USB9 D+ Ground Ground 9 ~ 16 2.3.3 CFast Socket Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 21 of 76...
Page 22: Ddr3 Sodimm Socket
16GB capacity by installing two 8GB DDR3 1600MHz SODIMM modules. For information of installing DDR3 memory modules, please refer to section 3.3 for detail. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 22 of 76...
Page 23: Sata Connectors
HDD bracket shipped with Nuvo-4000, you can directly mount two 2.5” HDDs/SSDs to these ports. For information of installing HDD/SSD to the SATA port, please refer to section 3.1 for detail. 2.3.6 PCI Slots Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 23 of 76...
Page 24: Pci Express Slots (Nuvo-4022 Only)
Neousys Technology for further information. 2.3.7 PCI Express Slots (Nuvo-4022 Only) Nuvo-4022 provides one x4 and one x16 PCI Express slot. As each PCI Express lane delivers 500 MB/s bandwidth, its x4 PCI Express slot delivers 2 GB/s bandwidth and x16 slot delivers 4 GB/s bandwidth*.
Page 25 (PCB size, excluding connector). For information of installing PCIe cards, please refer to section 3.4 for detail. *The x16 PCIe slot on Nuvo-4022 is implemented with 8-lanes, Gen2 PCI Express link and delivers 4GB/s bandwidth. You can install a x16, x8, x4 or x1 PCI Express add-on card to the x16 slot.
Page 26: Optional Isolated Dio
D_OUT_1 DO _GND D_OUT_2 D_OUT_5 D_OUT_4 D_OUT_7 D_OUT_6 DI_GND DO_GND D_IN_6 DI_GND D_IN_1 D_IN_5 DI_GND D_IN_3 D_IN_0 D_IN_7 D_IN_2 DI_GND D_IN_4 DIO Connector (box-header) on main board Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 26 of 76...
Page 27 Pin# Pin Definition ISO_5V DO_0 DO_GND DO_3 DO_1 DO_GND DO_2 DO_5 DO_4 DO_7 DO_6 DI_GND DO_GND DI_6 DI_GND DI_1 DI_5 DI_GND DI_3 DI_0 DI_7 DI_2 DI_GND DI_4 Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 27 of 76...
Page 34: Chapter 3 Getting Start
Loose 4 screws on the front, back and right side of the chassis. Simply open the chassis by pushing its side cover toward top, then remove the side cover and the SBC is exposed. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 34 of 76...
Page 35 Fasten the HDD(s) using M3 flat-head screws. Smoothly push the HDD bracket assembly into the SATA slot at the bottom of Nuvo-4000 case until SATA HDD(s) firmly attached to SATA connector(s). Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 35 of 76...
Page 37: Install A Cfast Card
Align your CFast card with the guide of the CFast socket. Note that you must have the obverse side toward the SBC. Push down your CFast card until it’s firmly contacted with pins of the CFast socket. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 37 of 76...
Page 38: Install The Ddr3 Sodimm Module
SODIMM module. Repeat step#2 and step#3 if you want install second DDR3 SODIMM module. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 38 of 76...
Page 39: Install The Pci/Pcie Add-On Card
3.4 Install the PCI/PCIe Add-on Card Nuvo-4000 provides PCI and PCIe slots on its backplane. Nuvo-4040 provides four PCI slots, as Nuvo-4022 provides two PCI slots plus two PCI Express slots. Nuvo-4000 supports 5V, 33MHz/32-bit PCI bus and can accommodate PCI cards with a maximal dimension of 205mm x 105mm (PCB size, excluding connector).
Page 40: Mount Your Nuvo-4000
3.5.1 Mount your Nuvo-4000 on the Wall Get one wall-mounting bracket and four M4 screws from the accessory box. Fix the mounting bracket to the back side of Nuvo-4000 using M4 screws. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 40 of 76...
Page 41 Fix Nuvo-4000 on the wall via the screw holes of the mounting bracket. You can also take advantage of the keyhole-shaped holes of the mounting bracket to suspend Nuvo-4000 on the Wall. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 41 of 76...
Page 42: Mount Your Nuvo-4000 On A Flat Surface
3.5.2 Mount your Nuvo-4000 on a Flat Surface Get two wall-mounting brackets and four M4 screws from the accessory box. Fix the mounting brackets to the bottom side of Nuvo-4000 using M4 screws. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 42 of 76...
Page 44: Mount Your Nuvo-4000 On The Din Rail
Nuvo-4000 using four M4 flat-head screws before mount it to a DIN rail. This option can be useful if you want to deploy Nuvo-4000 inside an equipment cabinet where DIN rail is available. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 44 of 76...
Page 45: Connect Dc Power To You Nuvo-4000
Insert the power plug of AC-DC adapter or power cable into the power connector and push it to the end. The power plug shall stay firmly with the 4-pin mini-DIN power connector. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 45 of 76...
Page 46: Power On Your Nuvo-4000
S4 (Hibernate) or S5 (system off with standby power) state via issuing Subnet Directed Broadcasts (SDB) or a magic packet. Nuvo-4000 implements the Wake-on-LAN function on its first GbE port. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 46 of 76...
Page 47 Wake-on-LAN function for Nuvo-4000. Please refer to section 4.1.8 for the instruction of configuring this option. In Windows system, identify the Local Area Connection of Intel® I210 Gigabit Controller and click the Configure button. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 47 of 76...
Page 48 There are some free tools available on Internet that can be used to send a magic packet. Please refer to the following link to understand more about Magic Packet. http://en.wikipedia.org/wiki/Wake-on-LAN Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 48 of 76...
Page 49 In Windows 7 system, identify the Local Area Connection of corresponding Intel® I210 Gigabit Controller and click the Configure button. Click the Power Management tag, and check the following two options accordingly Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 49 of 76...
Page 50: Chapter 4 Bios And Driver
Set the [Set COM1 as] to a proper mode for COM1 of your Nuvo-4000. Set the [Set COM2 as] to a proper mode for COM2 of your Nuvo-4000. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 50 of 76...
Page 51: Sata Controller Mode
When Nuvo-4000 boots up, press F2 to enter BIOS setup utility. Go to [Advanced]  [HDC Configure As]. Set the [HDC Configure as] to a proper mode for your Nuvo-4000. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 51 of 76...
Page 52: Xhci Support
When Nuvo-4000 boots up, press F2 to enter BIOS setup utility. Go to [Advanced]  [USB Configuration]. Set the [XHCI] to a proper mode for your Nuvo-4000. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 52 of 76...
Page 53: Video Configuration
Select “PCI Graphics Card” if using a PCI graphics card  Select “Auto” will specify the following priority for primary display device PCIe Graphics (if installed)  PCI Graphics (if installed)  IGD Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 53 of 76...
Page 54: Vga Output Resolution
Go to [Advanced]  [Video Configuration]  [Integrated Graphics Device]. Set the [VGA Output Resolution] to a proper value according to the best resolution of your display device. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 54 of 76...
Page 55: Power On After Power Failure Option
When Nuvo-4000 boots up, press F2 to enter BIOS setup utility. Go to [Advanced]  [Chipset Configuration] Set the [Power On after Power Failure] to a proper value for your Nuvo-4000. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 55 of 76...
Page 56: Wake-On-Lan Option
To enable/disable “Wake on LAN” option: When Nuvo-4000 boots up, press F2 to enter BIOS setup utility. Go to [Power]. Enable/disable the [Wake on LAN] option according to your application. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 56 of 76...
Page 57: Watchdog Timer For Booting
Disable or select timeout value for [WDT for Booting] option. Once you specify a timeout value, the [WDT Stop Option] option appears. You can select “Automatically after POST” or “Manually after Entering OS”. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 57 of 76...
Page 58: Select A Boot Device
Nuvo-4000 according to device (Advanced mode) or device category (Normal mode). You can use F5/F6 or +/- to change the boot order of devices or device categories. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 58 of 76...
Page 59: Operating System Support
You can visit Intel website for further information. Neousys will keep this list updated as we continuously test other operating systems with Nuvo-4000. Please contact us for the latest OS support list. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 59 of 76...
Page 60: Driver Installation
Nuvo-4000 Series User’s Manual 4.3 Driver Installation Neousys Technology Inc. provides a very convenient utility in “Drivers & Utilities DVD” to allow the “One-Click” driver installation. This utility automatically detects your Windows operating system and installs all necessary drivers to your Nuvo-4000 with just one mouse click.
Page 61: Install Drivers Manually
Windows 7 32-bit The recommended driver installation sequence is Chipset driver (x:\Driver_Pool\Chipset_7_Series\Win7_8_ALL\SetupChipset.exe) Graphics driver (x:\Driver_Pool\Graphics_3rd_i7_Vlv\Win7_8_32\Setup.exe) Audio driver (x:\Driver_Pool\Audio_ALC262\Win7_8_ALL\Setup.exe) LAN driver (x:\Driver_Pool\GbE_I210\Win7_8_32\APPS\PROSETDX\Win32\DxSetup.exe) USB 3.0 driver (x:\\Driver_Pool\USB3_7_Series\Win7_ALL\Setup.exe) ME driver (x:\Driver_Pool\ME_7_Series\ALL\Setup.exe) Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 61 of 76...
Page 62 Windows 7 64-bit The recommended driver installation sequence is Chipset driver (x:\Driver_Pool\Chipset_7_Series\Win7_8_ALL\SetupChipset.exe) Graphics driver (x:\Driver_Pool\Graphics_3rd_i7_Vlv\Win7_8_64\Setup.exe) Audio driver (x:\Driver_Pool\Audio_ALC262\Win7_8_ALL\Setup.exe) LAN driver (x:\Driver_Pool\GbE_I210\Win7_8_64\APPS\PROSETDX\Winx64\DxSetup.exe) USB 3.0 driver (x:\Driver_Pool\USB3_7_Series\Win7_ALL\Setup.exe) ME driver (x:\Driver_Pool\ME_7_Series\ALL\Setup.exe) Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 62 of 76...
Page 63: Appendix A Using Watchdog Timer & Isolated Dio
 Windows XP  Windows Vista (32-bit)  Windows 7 (32-bit & 64-bit) For other OS support, please contact Neousys Technology for further information. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 63 of 76...
Page 64: Install Wdt And Dio Library
WDT and DIO library. Execute WDT_DIO_Setup.exe. The following dialog appears. Click “Next >” and specify the directory of installing related files. The default directory is C:\Neousys\WDT_DIO. Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 64 of 76...
Page 65 4. When you programming your WDT or DIO program, the related files are located in  Header file: \Include  Lib file: \Lib  Function Reference: \Manual  Sample Code: \Sample Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 65 of 76...
Page 66: Using Wdt Function
If value of unit is correct (0 or 1), this function returns TRUE, otherwise FALSE. Usage WORD tick=255; BYTE unit=1; //unit is second. BOOL bRet = SetWDT(tick, unit); //timeout value is 255 seconds Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 66 of 76...
Page 67 Stop the countdown of WDT. When WDT is stopped, the WDT LED indicator stops blinking. Parameter None Return Value Always returns TRUE; Usage BOOL bRet = StopWDT() Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 67 of 76...
Page 68: Using Dio Function
GND return path is established. You should configure a sinking current connection for DO of Nuvo-4000. The following diagrams are the suggested wiring for DO: Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 68 of 76...
Page 69: Dio Function Reference
00b~11b Return Value The status (TRUE or FALSE) of the specified DI channel. Usage BYTE ch=3; //DI channel #3 BOOL DIChValue = DIReadLine(ch); //read DI channel #3 Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 69 of 76...
Page 70 BOOL value (TRUE or FALSE) specifies the status of DO channel. Return Value None Usage BYTE ch=3; //DI channel #3 BOOL DOChValue=TRUE; DOWriteLine(ch, DOChValue); //write DO channel #3 as TRUE Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 70 of 76...
Page 71 00000000b ~11111111b Nuvo-2000+ 00000000b ~11111111b Nuvo-3000 00000000b ~11111111b Nuvo-4000 00000000b ~11111111b POC-100 0000b~1111b POC-200 0000b~1111b Return Value None Usage WORD DOPortValue=0x3F; //00111111b DOWritePort(DOPortValue); //write DO port as 00111111b Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 71 of 76...
Page 72: Using Cos Function
Usage COS_INT_SETUP setup; memset(&setup, 0, sizeof(setup)); setup.portMask = 0xff; // enable ch.0~7 setup.edgeMode = 0; // level setup.edgeType = 0x00; // Lo/Hi BOOL bRet = SetupDICOS(&setup, sizeof(setup)); Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 72 of 76...
Page 73 BOOL StartDICOS(void); Description Start DI Change-of-State interrupt Parameter None Return Value Returns TRUE if start procedure successes, FALSE if start procedure failed. Usage BOOL bRet = StartDICOS(); Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 73 of 76...
Page 74: Change-Of-State Di Example
//Step 1, initialize DIO library by invoking InitDIO() if ( ! InitDIO() ) printf("InitDIO --> FAILED\n"); return -1; printf("InitDIO --> PASSED\n"); //Step 2, setup Change-of-State Interrupt mask and level/edge mode Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 74 of 76...
Page 75 --> PASSED\n"); printf("\npress any key to stop...\n"); system("pause >nul"); //Step 5, stop the DI Change-of-State Interrupt operation if ( ! StopDICOS() ) printf("StopDICOS --> FAILED\n"); return -5; Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 75 of 76...
Page 76 Nuvo-4000 Series User’s Manual printf("StopDICOS --> PASSED\n"); printf("\npress any key to exit...\n"); system("pause >nul"); return 0; Copyright © 2014 Neousys Technology Inc. All Right Reserved. Page 76 of 76...
