Neousys Technology Inc.
Nuvo-261xRL Series
User Manual
Revision 1.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nuvo-261 RL Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Neousys Technology Nuvo-261 RL Series

Summary of Contents for Neousys Technology Nuvo-261 RL Series

  • Page 1 Neousys Technology Inc. Nuvo-261xRL Series User Manual Revision 1.2...

  • Page 2: Table Of Contents

    Table of Contents Table of Contents Table of Contents ........................2 Legal Information ........................5 Contact Information ....................... 6 Declaration of Conformity ..................... 6 Copyright Notice ........................7 Safety Precautions ......................... 8 Hot Surface Warning ......................8 Battery Warning........................8 Service and Maintenance ......................
  • Page 3 Table of Contents 2.3.6 Reset Button ..................... 39 2.3.7 COM Ports (COM2/ COM3/ COM4) ..............40 2.3.8 COM 1 Port ....................... 41 2.3.9 System Status LED ................... 42 2.3.10 DVI-I Port ......................43 Rear Panel I/O ......................44 2.4.1 3-pin Terminal Block DC Input ................45 2.4.2 M12 X-coded PoE Port ..................
  • Page 4 Safety Precautions StartWDT ..........................115 ResetWDT ........................... 115 StopWDT ..........................115 DIO Functions........................116 InitDIO ..........................116 DIReadLine .......................... 116 DIReadPort .......................... 116 DOWriteLine ......................... 117 DOWritePort ......................... 117 Appendix B PoE On/ Off Control GetStatusPoEPort ......................118 EnablePoEPort ........................119 DisablePoEPort ........................

  • Page 5: Legal Information

    For questions in regards to hardware/ software compatibility, customers should contact Neousys Technology Inc. sales representative or technical support. To the extent permitted by applicable laws, Neousys Technology Inc. shall NOT be responsible for any interoperability or compatibility issues that may arise when (1) products, software, or options not certified and supported;...

  • Page 6: Contact Information

    3384 Commercial Avenue, Northbrook, IL 60062, USA (Illinois, USA) Tel: +1-847-656-3298Email, Website China Neousys Technology China Co., Ltd. Room 429 /431, Building 32, Guiping Road 680, Shanghai, 200233, China Tel: +86-2161155366Email, Website Declaration of Conformity This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 7: Copyright Notice

    This manual is intended to be used as an informative guide only and is subject to change without prior notice. It does not represent commitment from Neousys Technology Inc. Neousys Technology Inc. shall not be liable for any direct, indirect, special, incidental, or consequential damages arising from the use of the product or documentation, nor for any infringement on third party rights.

  • Page 8: Safety Precautions

    43-160Vdc, 4A, Tma 70 degree C and 2000m altitude during operation. If further assistance is required, please contact Neousys Technology ⚫ If the system is not going to be used for a long time, disconnect it from mains (power socket) to avoid transient over-voltage ⚫...

  • Page 9: Service And Maintenance

    Service and Maintenance/ ESD Precautions Service and Maintenance ⚫ ONLY qualified personnel should service the system ⚫ Shutdown the system, disconnect the power cord and all other connections before servicing the system ⚫ When replacing/ installing additional components (expansion card, memory module, etc.), insert them as gently as possible while assuring proper connector engagement ESD Precautions...

  • Page 10: About This Manual

    About This Manual About This Manual This guide introduces Neousys Nuvo-261xRL series system, an Intel® Elkhart Lake Atom® fanless in-vehicle computer. The guide also demonstrates the system’s basic installation procedures. Revision History Version Date Description Mar. 2023 Initial release Feb. 2024 Updated LED status definition Nov.

  • Page 11: Introduction

    Nuvo-261xRL Series Introduction The Nuvo-261xRL series is a rugged Intel® Atom® -based in-vehicle computer that incorporates four M12 Gigabit PoE+ connectors and one front-accessible 2.5" HDD tray, supporting up to 15mm height HDD/SSD. It is designed to fulfill multi-purpose railway applications from mobile gateways, data loggers, to network video recorders (NVR).

  • Page 12: Product Specifications

    Nuvo-261xRL Series Product Specifications 1.1.1 Nuvo-2610RL System Core Processor Intel® Elkhart Lake Atom® x6425E quad-core 2.0GHz/3.0GHz 12W processor Graphics Integrated Intel® UHD Graphics Memory Up to 32GB DDR4-3200 SDRAM by one SODIMM socket Supports fTPM 2.0 I/O Interface Ethernet Port 4x Gigabit Ethernet ports via M12 x-coded connectors by Intel®...
  • Page 13 Nuvo-261xRL Series Weight 2.1kg Mounting Damping bracket (standard) Wall-mount (optional) Environmental Operating Temperature -40°C to 70°C*, compliant with EN50155 Class OT4 Storage Temperature -40°C to 85°C* Humidity 10% to 90%, non-condensing Vibration IEC61373:2010, Category 1, Class B Body Mounted (part of EN 50155) Shock IEC61373:2010, Category 1, Class B Body Mounted (part of EN 50155) EN 50155:2017, Clause 13.4.8...

  • Page 14: Nuvo-2615Rl

    Nuvo-261xRL Series 1.1.2 Nuvo-2615RL System Core Processor Intel® Elkhart Lake Atom® x6425E quad-core 2.0GHz/3.0GHz 12W processor Graphics Integrated Intel® UHD Graphics Memory Up to 32GB DDR4-3200 SDRAM by one SODIMM socket Supports fTPM 2.0 I/O Interface Ethernet Port 4x Gigabit Ethernet ports via M12 x-coded connectors by Intel® I210 PoE Capability In compliant with IEEE 802.3at PoE+ PSE, maximum 25.5W output on single PoE+ port.
  • Page 15 Nuvo-261xRL Series Weight 2.7kg Mounting Damping bracket (standard) Wall-mount (optional) Environmental Operating Temperature -40°C to 70°C*, compliant with EN50155 Class OT4 Storage Temperature -40°C to 85°C* Humidity 10% to 90%, non-condensing Vibration IEC61373:2010, Category 1, Class B Body Mounted (part of EN 50155) Shock IEC61373:2010, Category 1, Class B Body Mounted (part of EN 50155) EN 50155:2017, Clause 13.4.8...

  • Page 16: Nuvo-2610Rl Dimensions

    Nuvo-261xRL Series Nuvo-2610RL Dimensions NOTE All measurements are in millimeters (mm). 1.2.1 Nuvo-2610RL Top View...

  • Page 17: Nuvo-2610Rl Front View

    Nuvo-261xRL Series 1.2.2 Nuvo-2610RL Front View 1.2.3 Nuvo-2610RL Rear View...

  • Page 18: Nuvo-2610Rl Side View

    Nuvo-261xRL Series 1.2.4 Nuvo-2610RL Side View...

  • Page 19: Nuvo-2615Rl Dimensions

    Nuvo-261xRL Series Nuvo-2615RL Dimensions NOTE All measurements are in millimeters (mm). 1.3.1 Nuvo-2615RL Top View...

  • Page 20: Nuvo-2615Rl Front View

    Nuvo-261xRL Series 1.3.2 Nuvo-2615RL Front View 1.3.3 Nuvo-2615RL Rear View...

  • Page 21: Nuvo-2615Rl Side View

    Nuvo-261xRL Series 1.3.4 Nuvo-2615RL Side View...

  • Page 22: Nuvo-2610Rl Damping Bracket Dimensions

    Nuvo-261xRL Series Nuvo-2610RL Damping Bracket Dimensions NOTE All measurements are in millimeters (mm). 1.4.1 Nuvo-2610RL Top View with Damping Bracket Installed...

  • Page 23: Nuvo-2610Rl I/O Panel View With Damping Bracket Installed

    Nuvo-261xRL Series 1.4.2 Nuvo-2610RL I/O Panel View with Damping Bracket Installed 1.4.3 Nuvo-2610RL Side View with Damping Bracket Installed...

  • Page 24: Nuvo-2610Rl Bottom View With Damping Bracket Installed

    Nuvo-261xRL Series 1.4.4 Nuvo-2610RL Bottom View with Damping Bracket Installed...

  • Page 25: Nuvo-2610Rl Wall Mount Bracket Dimensions

    Nuvo-261xRL Series Nuvo-2610RL Wall Mount Bracket Dimensions NOTE All measurements are in millimeters (mm). 1.5.1 Nuvo-2610RL Top View with Wall Mount Bracket Installed...

  • Page 26: Nuvo-2610Rl I/O Panel View With Wall Mount Installed

    Nuvo-261xRL Series 1.5.2 Nuvo-2610RL I/O Panel View with Wall Mount Installed 1.5.3 Nuvo-2610RL Side View with Wall Mount Bracket Installed...

  • Page 27: Nuvo-2610Rl Bottom View With Wall Mount Installed

    Nuvo-261xRL Series 1.5.4 Nuvo-2610RL Bottom View with Wall Mount Installed...

  • Page 28: Nuvo-2615Rl Damping Bracket Dimensions

    Nuvo-261xRL Series Nuvo-2615RL Damping Bracket Dimensions NOTE All measurements are in millimeters (mm). The wall-mount bracket is an optional accessory. 1.6.1 Nuvo-2615RL Top View with Damping Bracket Installed...

  • Page 29: Nuvo-2615Rl I/O Panel View With Damping Bracket Installed

    Nuvo-261xRL Series 1.6.2 Nuvo-2615RL I/O Panel View with Damping Bracket Installed 1.6.3 Nuvo-2615RL Side View with Damping Bracket Installed...

  • Page 30: Nuvo-2615Rl Bottom View With Damping Bracket Installed

    Nuvo-261xRL Series 1.6.4 Nuvo-2615RL Bottom View with Damping Bracket Installed...

  • Page 31: Nuvo-2615Rl Wall-Mount Dimensions

    Nuvo-261xRL Series Nuvo-2615RL Wall-mount Dimensions NOTE All measurements are in millimeters (mm). The wall-mount bracket is an optional accessory. Wall-mount bracket on Nuvo-2615RL is an optional accessory. 1.7.1 Top View with Wall-mount Installed...

  • Page 32: Panel View With Wall-Mount Installed

    Nuvo-261xRL Series 1.7.2 Panel View with Wall-mount Installed 1.7.3 Side View with Wall-mount Installed...

  • Page 33: Bottom View With Wall-Mount Installed

    Nuvo-261xRL Series 1.7.4 Bottom View with Wall-mount Installed...

  • Page 34: System Overview

    Upon receiving and unpacking your Nuvo-261xRL series, please check immediately if the package contains all the items listed in the following table. If any item(s) are missing or damaged, please contact your local dealer or Neousys Technology. Nuvo-2610RL Packing List...

  • Page 35: Front Panel I/O

    Nuvo-261xRL Series Front Panel I/O NOTE Both Nuvo-2610RL and Nuvo-2615RL systems share the same I/O, therefore Nuvo-2615RL will be used for illustration purposes. Item Description Power button Use this button to turn on or shutdown the system. 3.5mm 4-pole The 4-pole 3.5mm jack accepts microphone voice input and audio jack headphone speaker sound output.
  • Page 36 Nuvo-261xRL Series have DVI/VGA dual display output. They support resolutions up to 1920 x 1080. Front-accessible 2.5” HDD tray (supports up to 15mm in height), please refer to the 2.5” hard drive/ SSD installation section for details. Cassette enclosure for SuperCAP UPS power backup module (Nuvo-2615RL only)

  • Page 37: Power Button

    Nuvo-261xRL Series 2.3.1 Power Button The power button is a non-latched switch for ATX mode on/off operation. Press to turn on the system, PWR LED should light up and to turn off, you can either issue a shutdown command in the OS, or just press the power button. In case of system halts, you can press and hold the power button for 5 seconds to force-shutdown the system.

  • Page 38: Cmos Reset Button

    Nuvo-261xRL Series 2.3.3 CMOS Reset Button The CMOS Reset button is used to manually reset the motherboard BIOS in case of system halt or malfunction. To avoid unexpected operation, it is purposely placed behind the panel. To reset, please use the tip of a pen, press and hold for at least 5 seconds to reset the BIOS. 2.3.4 USB3.1 Gen1 Port The system offers one USB3.1 Gen1 (SuperSpeed USB) port on its front panel with...

  • Page 39: Usb2.0 Port

    Nuvo-261xRL Series 2.3.5 USB2.0 Port The system offers two USB2.0 ports on its front panel with screw-lock mechanism (indicated in red). They are backward-compatible with USB 1.1 and USB 1.0 devices. Legacy USB support is also provided so you can use USB keyboard/mouse in DOS environment. 2.3.6 Reset Button The reset button can be used to manually reset the system in case of abnormal condition.

  • Page 40: Com Ports (Com2/ Com3/ Com4)

    Nuvo-261xRL Series 2.3.7 COM Ports (COM2/ COM3/ COM4) Implemented using industrial-grade ITE8786 Super IO chip (-40 to 85°C) and provide up to 921600 bps baud rate, the second D-Sub male connector (COM2/ 3/ 4) can be configured in BIOS as single RS-422/ 485 port (COM2) or three 3-wire RS-232 ports (COM2/COM3/COM4).

  • Page 41: Com 1 Port

    Nuvo-261xRL Series 2.3.8 COM 1 Port Isolated with up to 15kV ESD protection, the port is implemented using industrial-grade ITE8786 Super IO chip (-40 to 85°C) and provides up to 921600 bps baud rate.COM1 is aRS-485 port via 9-pin D-Sub male connector. The following table describes the pin definition of COM ports.

  • Page 42: System Status Led

    Nuvo-261xRL Series 2.3.9 System Status LED There are four LED indicators on the I/O panel: PWR, WDT, HDD and IGN. The descriptions of these LEDs are listed in the following table. Indicator Color Description Reserved, not applicable. Yellow Watchdog timer LED, flashing when watchdog timer is started. Hard drive indicator, flashing when SATA HDD is active.

  • Page 43: 2.3.10 Dvi-I Port

    Nuvo-261xRL Series 2.3.10 DVI-I Port The system features a DVI-I connector on its front panel that is also compatible with VGA signals. The DVI and VGA outputs are directly driven by integrated Intel HD graphics engine and support up to 1920 x 1080 resolution. For VGA monitor, Neousys offers a specialized DVI-to-VGA adapter as an accessory shipped with the system.

  • Page 44: Rear Panel I/O

    Nuvo-261xRL Series Rear Panel I/O On the rear panel of the system, you will find a 3-pin terminal block for DC input, four M12 X-coded connectors, and a 15-pin DIO port. Item Description Compatible with DC power input from 43V – 160V 3-pin terminal block The M12 X-coded Power over Ethernet (PoE) ports provide both M12 X-coded PoE...

  • Page 45: 3-Pin Terminal Block Dc Input

    Nuvo-261xRL Series 2.4.1 3-pin Terminal Block DC Input The system accepts a wide range of DC power input from 43V to 160V via a 3-pin pluggable terminal block, which is fit for field usage where DC power is usually provided. The screw clamping mechanism on the terminal block offers connection reliability when wiring DC power.

  • Page 46: M12 X-Coded Poe Port

    Nuvo-261xRL Series 2.4.2 M12 X-coded PoE Port The system offers four PoE+ GbE ports via M12 X-coded connectors on the front panel. The ports are implemented using Intel ® I210 controller and the port indicated in green supports Wake-on-LAN. Power over Ethernet (PoE) supplies electrical power and data on a CAT-5/CAT-6 Ethernet cable.
  • Page 47 Nuvo-261xRL Series Connector Pin Definition Panel side Cable connector end Signal M12 panel side M12 cable connector end Wire color LAN P0 LAN N0 LAN P1 LAN N1 LAN P3 LAN N3 LAN N2 LAN P2...

  • Page 48: Isolated Digital Input/ Output

    Nuvo-261xRL Series 2.4.3 Isolated Digital Input/ Output The system provides 4x isolated digital input channels and 4x isolated digital output channels. The DIO functions support polling mode I/O access and DI change-of-state interrupt. Please refer to Watchdog Timer & Isolated DIO for information on wiring and programming the isolated DIO channels.

  • Page 49: Internal I/O Functions

    Nuvo-261xRL Series Internal I/O Functions In addition to I/O connectors on the front panel, the system also provides internal on-board expansion slots. In this section, we’ll illustrate these internal I/O functions. 2.5.1 M.2 2280 (SATA Signal Only) Slot for SSD The system has an M.2 2280 slot (SATA signal only) for you to install an M.2 SATA SSD for faster access over traditional hard disk drives.
  • Page 50 Nuvo-261xRL Series M.2 2280M Key Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 +3V3 +3V3 +3V3 +3V3 SATA-B+ SATA-B- SATA-A- SATA-A+ Mechanical Key SUSCLK PEDET +3V3 +3V3 +3V3...

  • Page 51: Dram So-Dimm Slot

    Nuvo-261xRL Series 2.5.2 DRAM SO-DIMM Slot The system motherboard supports a SODIMM socket for installing a DDR4-3200 memory module up to 32GB capacity.

  • Page 52: Mini-Pcie Slot (Usb2.0 Signal Only)

    Nuvo-261xRL Series 2.5.3 Mini-PCIe Slot (USB2.0 Signal Only) There is a full-size USB2.0 signal only mini-PCIe socket for better compatibility with off-the-shelf mini-PCIe wireless modules. For customers who want to install a mini-PCIe wireless module, please take advantage of the mini-PCIe socket and the antenna openings on the panels.
  • Page 53 Nuvo-261xRL Series mini-PCIe Pin Definition Pin # Signal Pin # Signal +3.3Vaux +1.5V Mechanical Key W_DISABLE# PERST# +3.3Vaux +1.5V Reserved Reserved USB_D- USB_D+ +3.3Vaux +3.3Vaux Reserved Reserved +1.5V Reserved Reserved +3.3Vaux...

  • Page 54: Mini-Pcie Slot (Pcie And Usb2.0 Signal)

    Nuvo-261xRL Series 2.5.4 Mini-PCIe Slot (PCIe and USB2.0 Signal) The mini-PCIe socket (in blue) accepts off-the-shelf mini-PCIe modules. You can add additional features to your system such as 5G/ 4G, WiFi, GPS, CAN bus, analog frame grabber, etc. The multiple antenna apertures can be located on the front and rear panel. Front panel antenna opening Rear panel antenna opening...
  • Page 55 Nuvo-261xRL Series mini-PCIe Pin Definition Pin # Signal Pin # Signal +3.3Vaux +1.5V REFCLK- REFCLK+ Mechanical Key W_DISABLE# PERST# PERn0 +3.3Vaux PERp0 +1.5V SMB_CLK PETn0 SMB_DATA PETp0 USB_D- USB_D+ +3.3Vaux +3.3Vaux Reserved Reserved +1.5V Reserved Reserved +3.3Vaux WARNING Some off-the-shelf mini-PCIe 4G modules are not compliant to standard mini-PCIe interface.

  • Page 56: 3042/ 3052 B Key Socket

    Nuvo-261xRL Series 2.5.5 M.2 3042/ 3052 B Key Socket The system has one M.2 3042/ 3052 B key socket (in blue) for 5G/4G module installation and dual SIM slots (in red). The M.2 slot features USB3.1 and USB 2.0 signal. For SMA antenna installation, there are antenna openings located on the front/ rear panels.
  • Page 57 Nuvo-261xRL Series M.2 3042/ 3052 B Key Pin Definition Pin # Signal Pin # Signal +3V3 +3V3 FULL_CARD_POWER_OFF_N USB_D+ W_DISABLE_N USB_D- Mechanical Key USB3.0-RX- USB3.0-RX+ UIM1-RESET UIM1-CLK USB3.0-TX- UIM1-DATA USB3.0-TX+ UIM1-PWR UIM2-DATA UIM2-CLK UIM2-RESET UIM2-PWR PERST_N +3V3 +3V3 +3V3...

  • Page 58: System Installation

    Nuvo-261xRL Series System Installation Before disassembling the system enclosure and installing components and modules, please make sure you have done the following: ⚫ It is recommended that only qualified service personnel should install and service this product to avoid injury or damage to the system. ⚫...

  • Page 59: Disassembling The System

    Nuvo-261xRL Series Disassembling the System 3.1.1 Disassembling Nuvo-2610RL To access system internal components, the system needs to be disassembled. To disassemble the system enclosure, please refer to the procedures below: Turn the system upside-down on a steady surface. Remove the screws indicated. Remove the screw indicated on the panel.
  • Page 60 Nuvo-261xRL Series Remove the panel. Remove the screws on the M12 panel. Remove the screws from both sides of the chassis. Left side chassis screws Right side chassis screws...
  • Page 61 Nuvo-261xRL Series Slide open the bottom panel. With the bottom panel removed, you can access the system’s internal expansion slots.

  • Page 62: Disassembling Nuvo-2615Rl

    Nuvo-261xRL Series 3.1.2 Disassembling Nuvo-2615RL To access system internal components, the system needs to be disassembled. To disassemble the system enclosure, please refer to the procedures below: Turn the system upside-down on a steady surface. Remove the screws indicated and separate the Cassette module.
  • Page 63 Nuvo-261xRL Series Remove the screws (indicated in blue) and thumb screws (indicated in red) indicated on the front I/O panel, and remove the faceplate. Remove the screw indicated on the rear I/O panel and separate it from the enclosure.
  • Page 64 Nuvo-261xRL Series Use a small Phillips screwdriver to loosen the screws for 3-pin connector, and unplug it. Release screws on the 3-pin connector Remove the connector Remove the screws from both sides of the chassis. Left side chassis screws Right side chassis screws...
  • Page 65 Nuvo-261xRL Series Gently slide the bottom panel away from M12 panel (towards the panel with USB ports). Remove the U-shaped bottom panel to access internal expansion slots.

  • Page 66: Installing Internal Components

    Nuvo-261xRL Series Installing Internal Components 3.2.1 DDR4 SO-DIMM Installation There is a SO-DIMM memory slot on the motherboard that supports up to 32GB DDR4-3200. Please follow the procedures below to replace or install the memory modules. “Disassembling the 1. Please refer to the section System”.
  • Page 67 Nuvo-261xRL Series 3. To install the memory module, insert gold fingers of the module into the slot at 45 degree angle, push down on the edge of the module and the clips on the side should clip the module into position. 4.

  • Page 68: 2280 Ssd Installation

    Nuvo-261xRL Series 3.2.2 M.2 2280 SSD Installation The system has a SATA signal M.2 2280 slot for you to install an M.22280 SATA SSD. For installation, please refer to the following instructions. Please refer to the section “Disassembling the System”. Remove the screws indicated.
  • Page 69 Nuvo-261xRL Series Insert the module on a 45 degree angle. Gently press down and secure the module with an M3 P-head screw. Reinstall the system enclosure or the bottom panel when done. If you need to install other components, please refer to respective sections.

  • Page 70: 3042/ 3052 B Key Installation

    Nuvo-261xRL Series 3.2.3 M.2 3042/ 3052 B Key Installation The system has an M.2 3042/ 3052 B key slot (indicated in blue)with two corresponding micro-SIM card slots (indicated in red). The M.2 slot can be accessed by removing the bottom panel. Please refer to the section “Disassembling the System”.
  • Page 71 Nuvo-261xRL Series To install the micro-SIM SIM card, slide the metallic cover in the direction shown and lift it to expose the socket and gold fingers. Slide cover in direction shown Lift the cover with fingertip Gently place the micro-SIM SIM card in the orientation shown, lower the cover and slide the cover in the direction shown to secure the SIM card in place.
  • Page 72 Nuvo-261xRL Series To install the M.2 3042/ 3052 module into place, insert the module on a 45° angle into the slot and secure it using the screw provided. Reinstall the system enclosure or the bottom panel when done. If you need to install other components, please refer to respective sections.

  • Page 73: Minipice Installation

    Nuvo-261xRL Series 3.2.4 miniPICe Installation The system has two miniPCIe sockets, one offers both PCIe and USB2.0 signals (indicated in red), while the other offers only USB2.0 signal (indicated in blue) for WiFi module installation. The mini PCIe slots can be accessed by removing the bottom panel. Please refer to the section “Disassembling the System”.
  • Page 74 Nuvo-261xRL Series To install the antenna onto the system enclosure, clip on the IPEZ-to-SMA cable to the module and secure the antenna to the side panel (refer to the module’s manual for clip-on connection). Clip on the IPEZ-to-SMA cable Secure the connector body, coupling nut onto a antenna opening on a panel Reinstall the system enclosure, panel and external antenna.

  • Page 75: Installing The System Enclosure

    Nuvo-261xRL Series Installing the System Enclosure 3.3.1 Installing the Nuvo-2610RL Enclosure To install the enclosure, please follow the instructions below. Please make sure heatsinks for DRAM/ M.2 2280 slot and M.2 3042/ 3052 slot are installed (secured with screws indicated) regardless if a module is installed Place the bottom panel back onto the heatsink.
  • Page 76 Nuvo-261xRL Series Place the M12 connector panel back on, and secure with the screws where indicated. Secure the screws on both sides of the chassis. Left side chassis screws Right side chassis screws Reinstall the I/O panel.
  • Page 77 Nuvo-261xRL Series Secure the I/O panel with screws where indicated. Secure the bottom panel with screws where indicated to complete the enclosure installation process.

  • Page 78: Installing The Nuvo-2615Rl Enclosure

    Nuvo-261xRL Series 3.3.2 Installing the Nuvo-2615RL Enclosure To install the enclosure, please follow the instructions below. Please make sure heatsinks for DRAM/ M.2 2280 slot and M.2 3042/ 3052 slot are installed (secured with screws indicated) regardless if a module is installed. Slide bottom U-shape panel to align with the heatsink.
  • Page 79 Nuvo-261xRL Series Plug in the 3-pin connector and use a small Phillips screwdriver to secure the connector. Plug in the 3-pin connector Secure the 3-pin connector Secure the two screws on both sides of the enclosure. Left side chassis screws Right side chassis screws...
  • Page 80 Nuvo-261xRL Series Place and secure the USB panel with screws (indicated in blue), and insert the 2.5” tray and secure it by tightening the thumb screws (indicated in red). Secure the screws (indicated in blue) on the M12 connector panel. Turn the system upside-down, place the Cassette module onto the enclosure while ensuring the gold fingers are properly inserted.
  • Page 81 Nuvo-261xRL Series Secure the Cassette module with the screws indicated.

  • Page 82: Hard Drive/ Ssd Installation

    Nuvo-261xRL Series 2.5” Hard Drive/ SSD Installation To install a 2.5” HDD or SSD in the front accessible tray, please refer to the procedure below. Place the system on a flat sturdy surface, and turn the thumb screws indicated anti-clockwise. Gently pull out the 2.5”...
  • Page 83 Nuvo-261xRL Series Gently insert the tray back into the slot until you feel resistance, and secure the tray by tightening the thumb screws clockwise to complete the installation.

  • Page 84: Replacing The Supercapacitor Ups Module

    Nuvo-261xRL Series Replacing the Supercapacitor UPS Module The system comes with a supercapacitor UPS module in the Cassette module. If you need replace it, please refer to the following instructions. Place the system on a flat sturdy surface and turn the system upside-down. Remove the four screws indicated.
  • Page 85 Nuvo-261xRL Series Remove the screw indicated and gently lift and separate the L-shaped panel from the Cassette module.
  • Page 86 Nuvo-261xRL Series Unplug the power cable and remove the screw at the top. Unplug power cable Remove the screw...
  • Page 87 Nuvo-261xRL Series Gently slide the supercapacitor UPS module out of the enclosure. Remove the new supercapacitor UPS module out of the delivered enclosure/ static bag. Gently inserted it into the Cassette module. Make sure the PCIe gold fingers and panel are inserted properly.
  • Page 88 Nuvo-261xRL Series Connect the power cable onto the daughter board. Secure the module by securing its panel with a screw.
  • Page 89 Nuvo-261xRL Series Once the PCIe add-on card has been installed, place the L-shaped cover back onto the Cassette module and secure the screw indicated. 10. Gently lower the Cassette module back onto the system enclosure while ensuring the gold fingers are properly inserted.
  • Page 90 Nuvo-261xRL Series 11. Secure the screws indicated to complete the installation.

  • Page 91: Damping Bracket Installation

    Nuvo-261xRL Series Damping Bracket Installation Neousys provides a damping bracket as a standard accessory for the system. The damping bracket is ideal for use in in-vehicle deployments. To install the damping bracket, please refer to the instructions listed below. 3.6.1 Nuvo-2610RL Damping Bracket Installation Place the system on a flat sturdy surface and turn the system upside-down.
  • Page 92 Nuvo-261xRL Series Take the damping bracket out of the accessory box, insert four anti-vibration grommets into the location shown on the bracket, and secure the bracket onto the bottom of the enclosure using four screws. Referring to the illustration shown above, insert four anti-vibration grommets into locations on the side hinges indicated, secure the system using four...
  • Page 93 Nuvo-261xRL Series 3.6.2 Nuvo-2615RL Damping Bracket Installation Neousys provides a damping bracket as a standard accessory for the system. The damping bracket is ideal for use in in-vehicle deployments. To install the damping bracket onto Nuvo-2615RL, please refer to the instructions listed below. Place the system on a flat sturdy surface and turn the system upside-down.
  • Page 94 Nuvo-261xRL Series Take the damping bracket out of the accessory box, insert four anti-vibration grommets into the location shown on the bracket, and secure the bracket onto the bottom of the enclosure using four screws. Referring to the illustration shown above, insert four anti-vibration grommets into locations on the side hinges indicated, secure the system using four...

  • Page 95: Wall Mount Bracket Installation (Optional Accessory)

    Nuvo-261xRL Series Wall Mount Bracket Installation (Optional Accessory) Neousys provides versatile mounting methods for Nuvo-261xRL systems. You can use the optional wall-mount brackets to mount the system onto the wall. To install the wall-mount bracket, please refer to the instructions listed below. 3.7.1 Nuvo-2610RL Wall Mount Bracket Installation Place the system on a flat sturdy surface and turn the system upside-down.
  • Page 96 Nuvo-261xRL Series Take the two wall-mount brackets and four M4 screws out of the accessory box, secure the wall mount brackets onto the bottom of the enclosure according to the illustration shown below Place the system on a flat surface portion of the wall and secure it with four (4) M4 pan screws.
  • Page 97 Nuvo-261xRL Series 3.7.2 Nuvo-2615RL Wall Mount Bracket Installation Place the system on a flat sturdy surface and turn the system upside-down. Remove the four screws and rubber standoffs indicated.
  • Page 98 Nuvo-261xRL Series Take the two wall-mount brackets and four M4 screws out of the accessory box, secure the wall mount brackets onto the bottom of the enclosure according to the illustration shown below. Place the system on a flat surface portion of the wall and secure it with four (4) M4 pan screws.

  • Page 99: Powering On The System

    Nuvo-261xRL Series Powering On the System There are three methods to power on the system ⚫ Pressing the power button ⚫ Sending a LAN packet via Ethernet (Wake-on-LAN) 3.8.1 Powering On Using the Power Button This is the simplest way to turn on your system. The power button is a non-latched switch and behaves as the ATX-mode on/off control.

  • Page 100: Powering On Using Wake-On-Lan

    Nuvo-261xRL Series 3.8.2 Powering On Using Wake-on-LAN Wake-on-LAN (WOL) is a mechanism to wake up a computer system from a S5 (system off with standby power) state via issuing a magic packet. The system’s Wake-on-LAN compatible GbE port is shown below. NOTE Please make sure the Intel chipset and Ethernet driver has been properly installed prior to setting up WOL function.
  • Page 101 Nuvo-261xRL Series double-click on the adapter Intel® I210 Gigabit Network Connection, click on Configure. Click on the Power Management tab and check the following options. Click on OK when done. Magic Packet The magic packet is a broadcast frame containing anywhere within its payload 6 bytes of all 255 (FF FF FF FF FF FF in hexadecimal), followed by sixteen repetitions of the target computer's...

  • Page 102: System Configuration

    Nuvo-261xRL Series System Configuration 4.1 BIOS Settings The system is shipped with factory-default BIOS settings meticulously programmed for optimum performance and compatibility. In this section, we’ll illustrate some of BIOS settings you may need to modify. Please always make sure you understand the effect of change before you proceed with any modification.

  • Page 103: Com 1 Port Configuration

    Nuvo-261xRL Series 4.1.1 COM 1 Port Configuration The system’s COM 1 port is a RS-485 port. You can enable/ disable both COM ports via BIOS settings. To set COM port operating mode: Press F2 when the system boots up to enter the BIOS setup utility. Go to [Advanced] →...

  • Page 104: Com 2/ 3/ 4 Ports

    Nuvo-261xRL Series 4.1.2 COM 2/ 3/ 4 Ports The system’s COM2 port can act as a 3x 3-wire RS-232 port (being COM ports 2/ 3/ 4), or it can act as a RS-422/ 485 (being a COM2 port). You can configure the COM ports via BIOS settings.

  • Page 105: Com Port High Speed Mode

    Nuvo-261xRL Series 4.1.3 COM Port High Speed Mode The high speed mode of each COM port effectively allows for the port's baud rate generator to operate at 8x the speed with an effective baud rate of 921,600 bps (115,200 x 8). Please refer to the following instructions on how to enable the high speed mode for your COM port (COM1 used as an example).

  • Page 106: Power On After Power Failure Option

    Nuvo-261xRL Series 4.1.4 Power On After Power Failure Option This option defines the behavior of system when DC power is supplied. Value Description S0 – Power On System is powered on when DC power is supplied. S5 – Power Off System is kept in off state when DC power is supplied.

  • Page 107: Wake On Lan Option

    Nuvo-261xRL Series 4.1.5 Wake on LAN Option Wake-on-LAN (WOL) is a mechanism which allows you to turn on your system via Ethernet connection. To utilize Wake-on-LAN function, you have to enable this option first in BIOS settings. Please refer to “Powering On Using Wake-on-LAN” to set up the system. To enable/disable “Wake on LAN”...

  • Page 108: Add Boot Options

    Nuvo-261xRL Series 4.1.6 Add Boot Options The Add Boot Options dedicates the boot sequence order of a newly added device (eg. USB flash drive). The setting allows you to set the newly added device to boot first or as the last device on the list.

  • Page 109: Watchdog Timer For Booting

    Nuvo-261xRL Series 4.1.7 Watchdog Timer for Booting The Watchdog timer setting in the BIOS ensures a successful system boot by specifying a timeout value. If the Watchdog timer is not stopped and expires, the BIOS will issues a reset command to initiate another boot process. There are two options in BIOS menu, “Automatically after POST”...

  • Page 110: Os Support And Driver Installation

    Due to Intel’s policy, the system only provides driver support for Windows 10 64-bit. For Linux support, please use Linux kernel versions no later than 5.8. The following list contains the operating systems which have been tested in Neousys Technology Inc. Microsoft Windows10 Professional 64-bit Microsoft Windows 10 IoT Enterprise 64-bit Ubuntu 20.04.2 LTS** (5.8 kernel)

  • Page 111: Appendix A Using Wdt & Dio

    In this section, we’ll illustrate how to use the function library provided by Neousys to program the WDT functions. Currently, WDT driver library supports Windows 10 32-bit and 64-bit versions. For other OS support, please contact Neousys Technology for further information. Installing WDT_DIO Library The WDT_DIO function library is delivered in the form of a setup package named WDT_DIO_Setup.exe.

  • Page 112: Wdt And Dio Library Installation

    Nuvo-261xRL Series WDT and DIO Library Installation To setup WDT & DIO Library, please follow instructions below. 1. Execute WDT_DIO_Setup.2.3.1.8.exe (or later) and the following dialog appears. 2. Click “Next >” and specify the directory of installing related files. The default directory is C:\Neousys\WDT_DIO.
  • Page 113 Nuvo-261xRL Series 3. Once the installation has finished, a dialog will appear to prompt you to reboot the system. The WDT & DIO library will take effect after the system has rebooted. 4. When programming your WDT or DIO program, the related files are located in Header File: \Include Library File:...

  • Page 114: Wdt Functions

    Nuvo-261xRL Series WDT Functions InitWDT BOOL InitWDT(void); Syntax Description: Initialize the WDT function. You should always invoke InitWDT() before set or start watchdog timer. Parameter None Return Value TRUE: Successfully initialized FALSE: Failed to initialize Usage BOOL bRet = InitWDT() SetWDT Syntax BOOL SetWDT(WORD tick, BYTE unit);...

  • Page 115: Startwdt

    Nuvo-261xRL Series StartWDT Syntax BOOL StartWDT(void); Description Starts WDT countdown. Once started, the WDT LED indicator will begin blinking. If ResetWDT() or StopWDT is not invoked before WDT countdowns to 0, the WDT expires and the system resets. Parameter None Return Value If the timeout value is given in correct format (WDT started), this function returns TRUE, otherwise FALSE...

  • Page 116: Dio Functions

    Nuvo-261xRL Series DIO Functions InitDIO Syntax BOOL InitDIO(void); Initialize the DIO function. You should always invoke InitDIO() Description before write/read anyDIO port/channel. Parameter None Return Value Returns TRUE if initialization successes, FALSE if initialization failed. Usage BOOL bRet = InitWDT() DIReadLine Syntax BOOL DIReadLine(BYTE ch);...

  • Page 117: Dowriteline

    Nuvo-261xRL Series DOWriteLine Syntax void DOWriteLine(BYTE ch, BOOL value); Write a single channel of isolated digital output. Description Parameter BYTE value specifies the DO channel to be written. Ch should be a value of 0 ~ 7. value BOOL value (TRUE or FALSE) specifies the status of DO channel.

  • Page 118: Appendix B Poe On/ Off Control

    Nuvo-261xRL Series Appendix B PoE On/ Off Control The system offers 802.3at PoE+ ports and users are allowed to manually turn on or off the power supply of each PoE port. This can be useful in power device (PD) fault-recovery or power reset.

  • Page 119: Enablepoeport

    Nuvo-261xRL Series EnablePoEPort Syntax BOOL EnablePoEPort (BYTE port); Description Turn on PoE power of designated PoE port. Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4 Return Value TRUE if enabled success FALSE if fail to enable.

  • Page 120: Disablepoeport

    Nuvo-261xRL Series DisablePoEPort Syntax BOOL DisablePoEPort (BYTE port); Description Turn off PoE power of designated PoE port Parameter port BYTE value specifies the index of PoE port. Please refer to the following illustration, port should be a value of 1 ~ 4 Return Value TRUE if disabled success FALSE if fail to disable...
