- Page 1 Mosaico FX100 100W IP66 modular LED image projector with dual effect wheel and one gobo slot USER MANUAL English version REV.02-09/23...
- Page 2 PROLIGHTS product are trademarks OWNED or licensed by Music & Lights S.r.l., its affiliates, and subsidiaries. PROLIGHTS is a registered trademark by Music & Lights S.r.l. All right reserved. Music & Lights – Via A. Olivetti, snc - 04026 - Minturno (LT) ITALY.
-
Page 3: Table Of Contents
BRACKET FOR WALL MOUNTING AND SUSPENSION ON POLES (CODE MOSUNIBRACKJR) ......................37 20 - TEST OF IP66 RATING 21 - MAINTENANCE MAINTENANCE AND CLEANING THE PRODUCT............39 REPLACING THE FUSE ....................39 VISUAL CHECK OF PRODUCT HOUSING ..............39 TROUBLESHOOTING ..................... 40 PROLIGHTS - Mosaico FX100... -
Page 4: Safety Information
• Do not reapply power until repairs have been completed. • Refer any service operation not described in this manual to PROLIGHTS Service team or an authorized PROLIGHTS service center. - Page 5 • Warning! Disconnect the fixture from AC mains power and allow to cool for at least 10 minutes before handling. • Only technicians who are authorized by PROLIGHTS or Authorised service partners are permitted to open the fixture. • Users may carry out external cleaning, following the warnings and instructions pro- vided, but any service operation not described in this manual must be referred to a qualified service technician.
- Page 6 • 2014/35/EU - Safety of electrical equipment supplied at low voltage (LVD). • 2014/30/EU - Electromagnetic Compatibility (EMC). • 2011/65/EU - Restriction of the use of certain hazardous substances (RoHS). • 2014/53/EU - Radio Equipment Directive (RED). Other approvals PROLIGHTS - Mosaico FX100...
-
Page 7: Packaging
• MFX100FBRAKBK: Surface bracket for MOSAICOFX100, black • MOSUNIBRACKJR: Bracket for MOSAICOJR for wall mounting and suspension on poles • MFX100LWGN: 15° FLEX lens for Mosaico FX100 series, narrow beam angle for animation and gobo • MFX100LWTM: 30° lens for Mosaico FX100 series, medium beam angle for animation effects •... -
Page 8: Technical Drawing
• UPBOX2P5: Firmware uploader kit, USB IN, 5-pin XLR DMX OUT 2 - TECHNICAL DRAWING Ø48~56 mm Ø342 mm [1,9~2.3 in] [13.5 in] 246 mm 237~281 mm [9.7 in] [9.3~11,1 in] 195 mm [7.7 in] Weight: 5,7 kg - 12,56 lbs MOSAICOFX100 Fig. 01 PROLIGHTS - Mosaico FX100... -
Page 9: Installation
Warning! When clamping the fixture to a truss or other structure at any angle, use clamps of half-cou- pler type. Do not use any type of clamp that does not completely encircle the structure when fastened. RSR1235A/B C6002A/B Steel security cable clamp 13 mm 0,51 in 98 mm 3,85 in Fig. 02 PROLIGHTS - Mosaico FX100... -
Page 10: Connection To The Mains Supply
• Connect the power connector into the Mains input socket (100-240 VAC-50/60 Hz). • The product is then ready for its operations and can be controlled through the available input sig- nals on board. • To disconnect power from the product, disconnect the Mains from the socket. PROLIGHTS - Mosaico FX100... -
Page 11: Product Overview
7. DMX OUT (3-pole): 1 = GND, 2 = sign-, 3 = sign+. 8. POWER OUT: for connection to the Mains 100-240V~/50-60Hz. 9. MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only (T2A 250V). ). Fig. 03 PROLIGHTS - Mosaico FX100... -
Page 12: Connection To The Mains Supply
POWER POWER POWER POWER POWER POWER MAINS 230V NOTE: when not using the Power output connectors, you must seal the cable ends with the sup- plied caps. Fig. 05 - Example configuration (Output at 230 V) PROLIGHTS - Mosaico FX100... -
Page 13: Dmx Connection
... . DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX IN DMX OUT DMX512 Controller Fig. 07 - Example 6 DMX channels configuration PROLIGHTS - Mosaico FX100... -
Page 14: Connection Of The Control Signal: Dmx Line Adapters
DMX addressing is limited to make it impossible to set the DMX address so high that you are left without enough control channels for the product. Set the fixture’s DMX address by RDM with the DATAMASTER. PROLIGHTS - Mosaico FX100... -
Page 15: Operation As A Wireless Receiver
• Select the desired unit and press ENTER button; • Search for "Specific PID" item in the menu; • Select the "Description" function; • Scroll through the menu items until"CRMX TO DMX", and set value to 1. PROLIGHTS - Mosaico FX100... -
Page 16: Control With Push Rotatory Knob
Modify value of the STATE DISCONNECT POWER COUPER L’ALIMENTATION CURRENT STATE BEFORE SERVICING AVANT L’ENTRETIEN Indexing Rotation CW Rotation CCW 0-360° Speed slow to fast Speed slow to fast ANTENNA FUSE T3.15A 250V PROLIGHTS - Mosaico FX100 MAINS OUT MAINS IN: 100-240V MAX 0.95A... -
Page 17: Shortcut
Description Encoder 1 + Encoder 2 Triggers WDMX Reset - Flash 2 times current color long press (3s) Encoder 1 + Encoder 3 Enable/ Disable Key lock - Flash 2 times current color long press (10s) PROLIGHTS - Mosaico FX100... -
Page 18: Menu Structure
To see the unit temperature. CE TEMP, DRIVER PCB TEMP, LED PCB TEMP,… SOFTWARE VERSION View informations about software version. DEVICE INFO To see device info. DEVICE LABEL To see device label. RDM UID View ID for the RDM control. PROLIGHTS - Mosaico FX100... - Page 19 Select of the following predefined 0-255 combination and its Dimmer val- MOTOR 1 ue. After enabled this mode, the unit will be automatically assigned MOTOR 2 as Master. FACTORY To reset the unit to factory default DEFAULT settings. PROLIGHTS - Mosaico FX100...
-
Page 20: Rdm Functions
Product BOOT_SOFTWARE_VERSION_ID 0x00C1 Information Product BOOT_SOFTWARE_VERSION_LABEL 0x00C2 Information DMX512 DMX_PERSONALITY 0x00E0 Setup DMX512 DMX_PERSONALITY_DESCRIPTION 0x00E1 Setup DMX512 DMX_START_ADDRESS 0x00F0 Setup DMX512 SLOT_INFO 0x0120 Setup DMX512 SLOT_DESCRIPTION 0x0121 Setup DMX512 DEFAULT_SLOT_VALUE 0x0122 Setup DMX512 DMX_BLOCK_ADDRESS 0x0140 Setup PROLIGHTS - Mosaico FX100... - Page 21 LAMP_HOURS Lamp 0x0401 Settings Power/ LAMP_STRIKES Lamp 0x0402 Settings Power/ LAMP_STATE Lamp 0x0403 Settings Power/ LAMP_ON_MODE Lamp 0x0404 Settings Power/ DEVICE_POWER_CYCLES Lamp 0x0405 Settings Display DISPLAY_INVERT 0x0500 NOT USED Settings Display DISPLAY_LEVEL 0x0501 NOT USED Settings PROLIGHTS - Mosaico FX100...
- Page 22 Standalone Manufac- STATIC MOTOR 1 0-255 Mode - Value turer PIDs shared with Encoder Setting Set Motor 2 behaviour on Standalone Manufac- STATIC MOTOR 2 0-255 Mode - Value turer PIDs shared with Encoder Setting PROLIGHTS - Mosaico FX100...
- Page 23 Manufac- 0:OFF CRMX TO DMX turer PIDs 1:ON Manufac- 0:OFF CRMX LINK RESET turer PIDs 1:ON Manufac- WIRELESS QUALITY turer PIDs Manufac- ERROR MESSAGE turer PIDs Manufac- POWER CONSUMPTION turer PIDs Manufac- CURRENT HOURS turer PIDs PROLIGHTS - Mosaico FX100...
-
Page 24: Dmx Charts
Motor 2 8 bit value 16 bit value Function Note From From Indexed 0 to 360° 32767 Default @ 0 Forward Spin (fast to slow) 32768 48895 Stop 48896 49407 Reverse spin (slow to fast) 49408 65535 PROLIGHTS - Mosaico FX100... - Page 25 STAND ALONE SLAVE Reserved Reserved Reserved Reserved Reserved INVERT ROTATION OFF INVERT ROTATION ON FAN MODE AUTO FAN MODE HIGH FAN MODE SILENT FAN MODE OFF KEY LOCK OFF KEY LOCK ON Reserved Reset all channel controlled Reserved PROLIGHTS - Mosaico FX100...
-
Page 26: Animation Wheel / Water Effect Replacement
Lift the top cover off the fixture. For ease of access, and if it is safe to do so, you can unclip the safety cable and remove the cover completely from the fixture (2). MOTOR 1 MOTOR 2 with short shaft with long shaft PROLIGHTS - Mosaico FX100... - Page 27 • MFX100WE2: Standard structured glass effect wheel, long shaft 2 (M2). The coupling between the surface washer of the animation wheel (A) and the seat face (B) is magnetic. Then simply detach the accessory from its seat and slide it out from above. Fig. 11 PROLIGHTS - Mosaico FX100...
-
Page 28: Custom Animation Wheel
HOLE DIAMETER THICKNESS Below the drawing of metal ring for animation wheel: SP013109 Metal Ring 1.1~4 mm NOTE: The metal ring can be ordered from us as a spare part with code SP013109. [0.04~0.16 in] Fig. 12 PROLIGHTS - Mosaico FX100... -
Page 29: Color Filter And Gobo Mounting
(2). The coupling between the surface accessory (A) and the seat face (B) is magnetic. Then simply detach the accessory from its seat and slide it out from above. Please turn! PROLIGHTS - Mosaico FX100... - Page 30 Seat of the color holder Colors Metal ring for half color Spring Insert the colors filter, the metal ring for half color and the spring in sequence in the seat of the color holder accessory. Please turn! PROLIGHTS - Mosaico FX100...
- Page 31 The color and gobo holder accessory must be inserted from above and positioned in the marked pro- jector seat to hook to the fixture. The coupling will take place magnetically between the surface of the seat and of the accessory. Fig. 14 PROLIGHTS - Mosaico FX100...
-
Page 32: Gobo Size
17 - GOBO SIZE Colour Ø26.9 mm Ø26.9 mm ≤ 2.2 mm [1.1 in] [1.1 in] [0.1 in] ATTENTION! Insert gobos with mirror surface toward the light source. Fig. 15 PROLIGHTS - Mosaico FX100... -
Page 33: Error Messages
Air in blower for cooling the lamp failed, the lamp has been [LED AIR IN (LOWER) FAN ERROR] switched OFF. [LED AIR OUT (UPPER) FAN Air out blower for cooling the lamp failed, the lamp has been ERROR] switched OFF. [MOTOR PCB ERROR] Motor pcb not detected PROLIGHTS - Mosaico FX100... -
Page 34: Accessories Installation
IP rating is lost and water may enter in the fixture. To help yourself with lens installation, spread the supplied grease on the smooth part of the fixing hole to make the lens seal slide better. Fig. 16 PROLIGHTS - Mosaico FX100... -
Page 35: Snoot Accessory
The snoot is an accessory used to protect the lens from rain. To mount the snoot accessory, screw the screws through the four holes present. Can be ordered with the following codes: • MFX100SNOOTBK: Snoot for MOSAICOFX100BK series, black; • MFX100SNOOTGY: Snoot for MOSAICOFX100GY series, gray. Fig. 17 PROLIGHTS - Mosaico FX100... -
Page 36: Anti Tampering Full Snoot With Front Glass Accessory
Can be ordered with the following codes: • MFX100SNOOTPROTGY: Anti tampering full snoot with front glass, gray; • MFX100SNOOTPROTBK: Anti tampering full snoot with front glass, black. Fig. 18 PROLIGHTS - Mosaico FX100... -
Page 37: Wall Bracket
Then the projector bracket must be mounted on the accessory arm using the M8x20 and washer screw provided (C). Can be ordered with the following codes: • MFX100WBRAKGY: Wall bracket for MOSAICOFX100, gray; • MFX100WBRAKBK: Wall bracket for MOSAICOFX100, black. Fig. 19 PROLIGHTS - Mosaico FX100... -
Page 38: Surface Bracket
Then the projector bracket must be mounted on the accessory arm using the M8x20 and washer screw provided (C). Can be ordered with the following codes: • MFX100WBRAKGY: Wall bracket for MOSAICOFX100, gray; • MFX100WBRAKBK: Wall bracket for MOSAICOFX100, black. Fig. 20 PROLIGHTS - Mosaico FX100... -
Page 39: Bracket For Wall Mounting And Suspension On Poles (Code Mosunibrackjr)
Do not mount the bracket on a support whose surface shows deformations, injuries, crushing, etc. Both the bracket and the unit must be secured with a safety cable. Can be ordered with the following codes: • MOSUNIBRACKJR: Bracket for MOSAICOJR for wall mounting and suspension on poles. Fig. 21 PROLIGHTS - Mosaico FX100... -
Page 40: Test Of Ip66 Rating
Connect the air hose to the IPTESTBOX by inserting the quick-connect fitting into the coupler. Insert the threaded end into the threaded valve hole socket. For the operating procedure using the instrument, refer to the IPTESTBOX user manual. Fig. 22 PROLIGHTS - Mosaico FX100... -
Page 41: Maintenance
WARNING: the use of alcohol or any other detergent could damage the lenses. • All other service operations on the product must be carried out by PROLIGHTS, its approved service agents or trained and qualified personnel. -
Page 42: Troubleshooting
• Check if the Fuse is intact and eventually replace it if fault. necessary. • Contact the PROLIGHTS Service or authorized service partner. Do not remove parts and/or covers, or carry out any repairs or service that are not described in... - Page 43 Note...
