Z700SPOT ATTENZIONE! Prima di effettuare qualsiasi operazione con l’unità, leggere con attenzione questo manuale e conservarlo accuratamente per riferimenti futuri. Contiene informazioni importanti riguardo l’installazione, l’uso e la manutenzione dell’unità. SICUREZZA Avvertenze generali I prodotti a cui questo manuale si riferisce sono conformi alle Direttive della Comunità Europea e pertanto recano la sigla .
Z700SPOT La distanza minima tra il proiettore e le pareti circostanti deve essere superiore a 50 cm e non devono essere ostruite, in nessun caso, le aperture d’aerazione. L’unità deve essere posizionata in modo tale che gli oggetti colpiti dal fascio luminoso siano distanti alme- no 2,5 m da essa.
Z700SPOT - 1 - DESCRIZIONE E SPECIFICHE TECNICHE 1.1 Elementi di comando e collegamenti Fig.2 Fig.1 POWER FUSE Vista A Vista B...
Page 7
Z700SPOT 1. TESTA MOBILE; 11.PORTAFUSIBILE: sostituire un fusibile difettoso solo con uno dello stesso tipo; 2. BRACCIO GIREVOLE; 12.CAVO DI ALIMENTAZIONE con spina Shuko 3. LEVA di blocco e sblocco braccio pieghevole (200-240V~/50-60Hz); (movimento PAN); 13.DISPLAY LCD; 4. PULSANTI per blocco e sblocco testa mobile 14.Tasto MENU per chiamare il menu d’imposta- (movimento TILT);...
Z700SPOT 1.2 DESCRIZIONE Zenith 700 Spot è il nuovo proiettore a testa mobile Prolights sviluppato con contenuti tecnologici all’avan- guardia e soluzioni meccaniche ricercate. L’elevata potenza luminosa, la qualità costruttiva e la sezione ef- fetti rendono questo proiettore particolarmente indicato per l’utilizzo in concerti, spettacoli, studi televisivi, teatri ed allestimenti ampi e di spessore.
Page 9
Z700SPOT Check-up e test elettronico per diagnostica. Timer ore di vita della lampada. Sensore termico per il monitoraggio della temperatura ottimale di lavoro della lampada. Raffreddamento ad aria filtrata forzata con ventole silenziate a velocità regolabile. Struttura e corpo mobile Struttura in alluminio con coperture in policarbonato ad alta resistenza, colore nero.
Z700SPOT - 2 - INSTALLAZIONE 2.1 LAMPADA Si raccomanda l’uso di lampade MSRGold Philips da 700W Fastfit ad innesto rapido (cod. 800188). Assicu- rarsi che la lampada sia compatibile con il voltaggio dell’impianto elettrico usato. Se lampada viene fatta operare con un voltaggio superiore al suo voltaggio nominale potrebbe essere danneggiata o la sua durata notevolmente ridotta.
Z700SPOT 2.3 MONTAGGIO Lo Z700SPOT può essere collocato su un piano solido. Inoltre, grazie ai fori di fissaggio, l’unità può essere montata anche a testa in giù, su una traversa (fig.4). Per il fissaggio occorrono dei supporti robusti per il montaggio.
Z700SPOT - 3 - FUNZIONI E IMPOSTAZIONI 3.1 FUNZIONAMENTO Inserire la spina del cavo di alimentazione in una presa di rete (200-240V~/50-60 Hz) e accendere lo Z700SPOT con l’interruttore ON/OFF(16) solo dopo aver effettuato lo sblocco del movimento PAN (3) e TILT (4).
Z700SPOT 3.3 STRUTTURA DEL MENU I riquadri in grigio rappresentano DMX Address il preset settings Mode 1 (22) DMX Functions DMX Channel Mode Mode 2 (22) Mode 3 (29) View DMX Value Pan Inverse Tilt Inverse BI.o. P/T Moving Fixture Settings BI.o.
Page 14
Z700SPOT Display Inverse Backlight Auto Off Display Setting Backlight Intensity °C Temperature Unit °F Auto Test Fixture Test Manual Test Fixture use time Exit Fixture Information Lamp On time Reset Time Firmware Version MENU Pan/Tilt Color/CMY Gobo Reset Function Shutter/Dimmer Focus/Zoom/Prism/Frost Iris/Flatb Interval...
Z700SPOT 3.4 MODALITÀ DMX Per entrare nella modalità DMX procedere nel seguente modo: Premere il tasto MENU e selezionare attraverso i tasti direzionali la voce [DMX Functions], quindi premere il tasto ENTER per confermare la scelta. Selezionare nel menu la voce [DMX Address] e confermare la scelta premendo il tasto ENTER. Modificare il valore DMX nell’intervallo [1 - 512] servendosi dei tasti direzionali.
Z700SPOT 3.7 COLLEGAMENTI DELLA LINEA DMX La connessione DMX è realizzata con connettori standard XLR. Utilizzare cavi schermati, 2 poli ritorti, con impedenza 120Ω e bassa capacità. Per il collegamento fare riferimento allo schema di connessione riportato di seguito: DMX - INPUT DMX - OUTPUT Spina XLR Presa XLR...
Z700SPOT 3.9 FUNZIONE CANALI Mode Function in 22 channel Function in 22 channel Function in 29 channel Channel Mode 1 Mode 2 Mode 3 Shutter Pan Fine Dimmer Pan Fine Tilt Cyan Tilt Tilt Fine Magenta Tilt Fine Pan/Tilt Speed Yellow Pan/Tilt Speed Shutter...
Z700SPOT 3.10 TABELLA CANALI DMX Function in 22 channel Function in 22 channel Channel Channel Mode 1 value Mode 1 value Preset Color 000-255 White 000-021 Pan Fine 000-255 Color1 022-042 Color2 043-063 Color3 064-085 Tilt 000-255 Color4 086-106 Color5 107-127 Tilt Fine 000-255...
Page 19
Z700SPOT Function in 22 channel Function in 22 channel Channel Channel Mode 1 value Mode 1 value Gobo 2 Frost No Gobo 000-005 Normal 000-007 Gobo2-1 006-010 Frost 008.255 Gobo2-2 011-015 Gobo2-3 016-020 Gobo2-4 021-026 Zoom 000-255 Gobo2-5 027-031 Gobo2-6 032-036 Focus 000-255...
Page 20
Z700SPOT Function in 22 channel Function in 22 channel Channel Channel Mode 2 value Mode 2 value Gobo1-2 Shaking 058-067 Shutter Gobo1-3 Shaking 068-077 Gobo1-4 Shaking 078-087 Gobo1-5 Shaking 088-097 Shutter closed (blackout) 000-007 Shutter open 008-015 Gobo1-6 Shaking 108-117 Gobo1-7 Shaking 118-127 Stroboscope Slow to Fast...
Page 21
Z700SPOT Function in 22 channel Function in 22 channel Channel Channel Mode 2 value Mode 2 value Prism Rotation Frost Normal 000-007 No Function 000-007 Frost 008-255 Prism Effect 008-127 Function Prism Rotation Effect 128-255 No Function 000-009 Enable auto focus 010-019 Prism Rotation Disable auto focus...
Page 22
Z700SPOT Function in 29 channel Function in 29 channel Channel Channel Mode 3 value Mode 3 value 000-255 Focus/Zoom/Reset 180-189 Iris/Effect Reset 190-199 Reset All 200-209 Pan Fine 000-255 No Function 210-229 Lamp Off 230-239 Tilt 000-255 No Function 240-255 Tilt Fine 000-255 Effect/Preset Effect...
Page 23
Z700SPOT Function in 29 channel Function in 29 channel Channel Channel Mode 3 value Mode 3 value Color Color Macro White 000-007 008-015 Open 000-007 Orange 016-023 Macro1 008-028 3200K 024-031 Macro2 029-049 5600K 032-039 Macro3 050-069 Pink 040-047 Macro4 070-090 Green 048-055...
Page 24
Z700SPOT Function in 32 channel Function in 32 channel Channel Channel Mode 3 value Mode 3 value Gobo1 Rotation Rotation Prism Rotation angle of gobo 000-127 Position 000-127 Constant change of gobo Rotation Fast - Slow 128-191 Counter - clockwise rotation Rotation Slow - Fast 192-255 Fast - Slow...
Z700SPOT 3.11 IMPOSTAZIONI DISPOSITIVO È possibile modificare i parametri relativi al dispositivo procedendo nel seguente modo: Premere il tasto MENU e selezionare attraverso i tasti direzionali la voce [Fixture Setting], quindi premere il tasto ENTER per confermare la scelta. Selezionare il parametro che si desidera modificare fra [Pan Inverse], [Tilt Inverse], [BI.o. P/T Moving], [BI.o. Color Change], [BI.o.
Z700SPOT 3.12 IMPOSTAZIONI LAMPADA È possibile modificare i parametri relativi alla lampada del dispositivo procedendo nel seguente modo: Premere il tasto MENU e selezionare attraverso i tasti direzionali la voce [Lamp Setting], quindi premere il tasto ENTER per confermare la scelta. Selezionare il parametro che si desidera modificare fra [On/ Off], [State/ Power On], [Off via DMX], [On if DMX On], [Off if DMX Off], [Cooling Mode], [Ignition Delay], [Low Power Delay] e premere il tasto ENTER per confermare la scelta.
Z700SPOT 3.13 IMPOSTAZIONI DISPLAY È possibile modificare i parametri relativi al display procedendo nel seguente modo: Premere il tasto MENU e selezionare attraverso i tasti direzionali la voce [Display Setting], quindi premere il tasto ENTER per confermare la scelta. Selezionare il parametro che si desidera modificare fra [Display Inverse], [Backlight Auto Off], [Backlight Intensi- ty], [Temperature Unit] e premere il tasto ENTER per confermare la scelta.
Z700SPOT 3.15 INFORMAZIONI SUL DISPOSITIVO Premere il tasto MENU e selezionare attraverso i tasti direzionali la voce [Fixture Information]. Premere il tasto ENTER per confermare la scelta. È possibile visualizzare le seguenti informazioni: Fixture Use Time Permette di visualizzare le ore di funzionamento del dispositivo. Selezionare attraverso i tasti direzionali la voce [Fixture Use Time].
Page 29
Z700SPOT Factory Settings Permette di ripristinare l’unità alle impostazioni di fabbrica. Selezionare attraverso i tasti direzionali la voce [Factory setting]. Premere il tasto ENTER per confermare la scelta.
Z700SPOT 3.18 REGOLAZIONI HOME POSITION Per effettuare la preimpostazione dei valori correttivi (modalità offset): Premere il tasto MENU. Tenere premuto per circa 1 secondo il tasto ENTER. Selezionare la funzione desiderata attraverso i tasti direzionali, quindi premere ENTER per confermare la scelta.
Z700SPOT - 4 - MANUTENZIONE 4.1 PULIZIA SISTEMA OTTICO E MANUTENZIONE Durante gli interventi, assicurarsi che l’area sotto il luogo di installazione sia libera da personale non qualificato. Spegnere l’unità, scollegare il cavo di alimentazione ed aspettare finché l’unità non si sia raffreddata. Tutte le viti utilizzate per l’installazione dell’unità...
Z700SPOT 4.2 SOSTITUZIONE GOBOS I gobos rotanti, nelle ruote, possono essere cambiati e sostituiti, per esempio, con propri gobos: 1. Staccare la spina dalla presa di rete e fare raffreddare l’unità per 20 minuti circa. 2. Togliere la parte superiore della testa mobile dopo aver svitato le viti. 3.
Page 35
Z700SPOT INDEX Safety General instructions Warnings and installation precautions General information Description and technical specifications 1. 1 Operating elements and connections 1. 2 Description 1. 3 Technical specifications 2 Installation 2. 1 Lamp 2. 2 Inserting or replacing the lamp 2.
Page 36
Z700SPOT WARNING! Before carrying out any operations with the unit, carefully read this instruction manual and keep it with cure for future reference. It contains important information about the installation, usage and maintenance of the unit. SAFETY General instructions The products referred to in this manual conform to the European Community Directives and are therefore marked with .
Page 37
Z700SPOT The projector needs to be positioned so that the objects hit by the beam of light are at least 2,5 metres from the lens of the projector. Don’t lift the fixture holding it by the moving part (head). Keep any inflammable material at a safe distance from the fixture. The lamp shall be changed if it has become damaged or thermally deformed.
Page 38
Z700SPOT - 1 - DESCRIZIONE E SPECIFICHE TECNICHE 1.1 Elementi di comando e collegamenti Fig.2 Fig.1 POWER FUSE Vista A Vista B...
Page 39
Z700SPOT 1. MOVING HEAD; 11.MAIN FUSE HOLDER: replace a burnt-out fuse by one of the same type only; 2. ROTARY ARM; 12.CONNECTION CABLE with Shuko plug (200- 3. LEVEL for locking and unlocking the folding 240V~ / 50-60Hz); arms (PAN movement); 13.LCD DISPLAY;...
Page 40
Z700SPOT 1.2 DESCRIPTION Zenith 700SPOT is the new Prolights moving-head projector developed with cutting-edge technological contents and mechanical solutions. The high brightness, the component construction quality and the effect section make Z700SPOT the perfect tool for concerts, shows, TV studios, theatres and large venues. Z700 Spot, equipped with Philips MSR Gold 700W FastFit lamp with electronic ballast features linear CMY color mixing system, linear CTO, an additional colour wheel (7 dichroic filters + open), linear motorized zoom (15°-...
Page 41
Z700SPOT Cooling: filtered forced ventilation with variable speed low-noise fans. Structure and moving body Aluminum structure with polycarbon cover, black colour. Ergonomic side handles for transportation. Motion Angle (3 phase motors): Pan = 540° Tilt = 270°. Pan/Tilt resolution: 8-bit or 16-bitPan = 2,10° Pan Fine = 0,008°Tilt = 1,05° Tilt Fine = 0,004°. Feedback automatic repositioning.
Page 42
Z700SPOT - 2 - INSTALLATION 2.1 LAMP We recommend using MSRGold Philips 700W Fastfit (cod. 800188). Make sure that the used lamp is compat- ible with local voltage. If the lamp is operated with a voltage surpassing its nominal operating voltage, it can be damaged or its service life reduced considerably.
Page 43
Z700SPOT 2.3 MOUNTING The Z700SPOT may be set up on a solid and even surface. By means of the fixing facilities of the base plate, the unit can also be mounted upside down to a cross arm. The base plate is shown in fig.4. For fixing, stable mounting clips are required.
Page 44
Z700SPOT - 3 - FUNCTION AND SETTINGS 3.1 OPERATION Connect the supplied main cable to a socket (200-240V~/50-60Hz). Unlock the PAN (3) and TILT (4) mecha- nism. Switch on the unit with the power switch (16) . Shortly after that the Z700SPOT is ready for operation. After operation, switch off the unit with the power switch.
Page 45
Z700SPOT 3.3 MENU STRUCTURE Boxes in gray represent DMX Address preset settings Mode 1 (22) DMX Functions DMX Channel Mode Mode 2 (22) Mode 3 (29) View DMX Value Pan Inverse Tilt Inverse BI.o. P/T Moving Fixture Settings BI.o. Color Change MENU BI.o.
Page 46
Z700SPOT Display Inverse Backlight Auto Off Display Setting Backlight Intensity °C Temperature Unit °F Auto Test Fixture Test Manual Test Fixture use time Exit Fixture Information Lamp On time Reset Time Firmware Version MENU Pan/Tilt Color/CMY Gobo Reset Function Shutter/Dimmer Focus/Zoom/Prism/Frost Iris/Flatb Interval...
Page 47
Z700SPOT 3.4 DMX MODE Press the MENU button and select, via the directional buttons, the [DMX Functions] menu choice, then press the ENTER button to confirm the choice. Select the [DMX Address] menu voice and confirm the choice by pressing the ENTER button. Edit the DMX address value into the [1 - 512] range using the UP and DOWN buttons.
Page 48
Z700SPOT 3.7 CONNECTION OF THE DMX LINE DMX connection employs standard XLR connectors. Use shielded pair-twisted cables with 120Ω impedance and low capacity. The following diagram shows the connection mode: DMX - INPUT DMX - OUTPUT XLR plug XLR socket Pin1 : GND - Shield Pin2 : - Negative Pin3 : + Positive...
Page 49
Z700SPOT 3.9 CHANNEL FUNCTION Mode Function in 22 channel Function in 22 channel Function in 29 channel Channel Mode 1 Mode 2 Mode 3 Shutter Pan Fine Dimmer Pan Fine Tilt Cyan Tilt Tilt Fine Magenta Tilt Fine Pan/Tilt Speed Yellow Pan/Tilt Speed Shutter...
Page 50
Z700SPOT 3.10 DMX CONTROL Function in 22 channel Function in 22 channel Channel Channel Mode 1 value Mode 1 value Preset Color 000-255 White 000-021 Pan Fine 000-255 Color1 022-042 Color2 043-063 Color3 064-085 Tilt 000-255 Color4 086-106 Color5 107-127 Tilt Fine 000-255 Color6...
Page 51
Z700SPOT Function in 22 channel Function in 22 channel Channel Channel Mode 1 value Mode 1 value Gobo 2 Frost No Gobo 000-005 Normal 000-007 Gobo2-1 006-010 Frost 008.255 Gobo2-2 011-015 Gobo2-3 016-020 Gobo2-4 021-026 Zoom 000-255 Gobo2-5 027-031 Gobo2-6 032-036 Focus 000-255...
Page 52
Z700SPOT Function in 22 channel Function in 22 channel Channel Channel Mode 2 value Mode 2 value Gobo1-2 Shaking 058-067 Shutter Gobo1-3 Shaking 068-077 Gobo1-4 Shaking 078-087 Gobo1-5 Shaking 088-097 Shutter closed (blackout) 000-007 Shutter open 008-015 Gobo1-6 Shaking 108-117 Gobo1-7 Shaking 118-127 Stroboscope Slow to Fast...
Page 53
Z700SPOT Function in 22 channel Function in 22 channel Channel Channel Mode 2 value Mode 2 value Prism Rotation Frost Normal 000-007 No Function 000-007 Frost 008-255 Prism Effect 008-127 Function Prism Rotation Effect 128-255 No Function 000-009 Enable auto focus 010-019 Prism Rotation Disable auto focus...
Page 54
Z700SPOT Function in 29 channel Function in 29 channel Channel Channel Mode 3 value Mode 3 value 000-255 Focus/Zoom/Reset 180-189 Iris/Effect Reset 190-199 Reset All 200-209 Pan Fine 000-255 No Function 210-229 Lamp Off 230-239 Tilt 000-255 No Function 240-255 Tilt Fine 000-255 Effect/Preset Effect...
Page 55
Z700SPOT Function in 29 channel Function in 29 channel Channel Channel Mode 3 value Mode 3 value Color Color Macro White 000-007 008-015 Open 000-007 Orange 016-023 Macro1 008-028 3200K 024-031 Macro2 029-049 5600K 032-039 Macro3 050-069 Pink 040-047 Macro4 070-090 Green 048-055...
Page 56
Z700SPOT Function in 32 channel Function in 32 channel Channel Channel Mode 3 value Mode 3 value Gobo1 Rotation Rotation Prism Rotation angle of gobo 000-127 Position 000-127 Constant change of gobo Rotation Fast - Slow 128-191 Counter - clockwise rotation Rotation Slow - Fast 192-255 Fast - Slow...
Page 57
Z700SPOT 3.11 FIXTURE SETTINGS It is possible to change the device parameter values in the following way: Press the MENU button and select through the directional buttons the [Fixture Setting] menu voice, then press the ENTER button to confirm the choice. Select the parameter to be changed between [Pan Inverse, Tilt Inverse, BI.o.
Page 58
Z700SPOT 3.12 LAMP SETTINGS It is possible to change the device parameter values in the following way: Press the MENU button and select through the directional buttons the [Lamp Setting] menu voice, then press the ENTER button to confirm the choice. Select the parameter to be changed between [On/ Off], [State/ Power On], [Off via DMX], [On if DMX On], [Off if DMX Off], [Cooling Mode], [Ignition Delay], [Low Power Delay] and press the ENTER button to confirm the choice.
Page 59
Z700SPOT 3.13 DISPLAY SETTINGS It is possible to change the display parameter values in the following way: Press the MENU button and select through the directional buttons the [Display Setting] menu voice, then press the ENTER button to confirm the choice. Select the parameter to be changed between [Display Inverse], [Backlight Auto Off], [Backlight Intensity], [Tem- perature Unit] and press the ENTER button to confirm the choice.
Page 60
Z700SPOT 3.15 FIXTURE INFORMATION Press the MENU button and select through directional buttons the [Fixture Information] menu voice. Press the ENTER button to confirm the choice. It is possible to view the following information: Fixture Use Time Show the fixture working hours. Select through the directional buttons the [Fixture Use Time] menu voice.
Page 61
Z700SPOT 3.18 HOME POSITION ADJUSTMENT To set the corrective values (offset mode): Press the MENU button. Press and hold the ENTER button for about 1 second. Select the desired function through the directional buttons, then press the ENTER button to confirm the choice.
Page 62
Z700SPOT - 4 - MAINTENANCE 4.1 CLEANING THE UNIT AND MAINTENANCE Make sure the area below the installation place is free from unwanted persons during setup. Switch off the unit, unplug the main cable and wait until the unit has cooled down. All screws used for installing the device and any of its parts should be tightly fastened and should not be corroded.
Page 63
Z700SPOT 4.2 REPLACEMENT OF THE GOBOS The rotating gobos can be replaced and e. g. be exchanged for individual gobos. 1. Disconnect the main plug from the socket and let the unit cool down for 20 minutes. 2. Release the screws and remove the upper part of the housing of the pan head. 3.
Page 65
Place Stamp Here Affrancare Spett.le Music&Lights S.r.l. Via Appia Km 136.200 04020 Itri (LT) Italy...
