UCR-ST-B8
Front View
# Description
1
LAN Ethernet ports
2
WAN Ethernet port
3
LAN LEDs
4
WAN LED
5
RS485 connector
6
Power connector
7
RS232 connector
8
Input / Output connector
9
Power LED
10
Mobile connection status LED
11
Mobile signal strength indication LEDs
Back View
# Description
1
Mobile antenna connectors
2
GPS antenna connector
3
USB connector
4
WiFi antenna connectors
5
Reset button
6
SIM card slots
LED: Status Indication
Power LED
ACTION
LED turned ON
LED turned OFF
2
DESCRIPTION
Router is powered up
Router is not powered up
