Scan Optics SO-5000 User Manual

Ophthalmic microscope
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SO-5000 Ophthalmic Microscope
....................................................................................................................
....................................................................................................................
Binocular assistant microscope ................................................................................
Articulated arm ........................................................................................................
Panel controls ........................................................................................................
Care of the optical head ............................................................................................
Care of the main lamp ............................................................................................
Main lamp replacement ............................................................................................
Focus friction ........................................................................................................
Power focus and zoom ............................................................................................
....................................................................................................................
ISSUE NUMBER:
5.0
DATE:
11/04/02
CONTENTS
............................................................................................
........................................................................................................
........................................................................................................
................................................................................
........................................................................................................
............................................................................................
........................................................................................................
................................................................................
........................................................................................................
........................................................................................................
............................................................................................
................................................................................
........................................................................................................
.....................................................................................
................................................................................
................................................................................
................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
........................................................................................................
............................................................................................
........................................................................................................
............................................................................................
............................................................................................
SUPERSEDES:
4.0
DATE:
22/05/01
User Manual
........................................................
....................................................................
WRITTEN BY:
DATE:
22/08/97
Page 1 of 36
RJK
CHECKED BY:
DATE:
22/08/97
3
4
5
5
7
10
11
11
12
13
13
15
16
17
18
19
20
20
20
21
22
23
24
24
25
27
27
29
29
31
33
33
33
34
34
34
34
35
36
NW

Advertisement

Table of Contents
loading

Related Manuals for Scan Optics SO-5000

Summary of Contents for Scan Optics SO-5000

  • Page 1: Table Of Contents

    SO-5000 Ophthalmic Microscope User Manual Page 1 of 36 CONTENTS INTRODUCTION ........................PARTS LIST ........................ASSEMBLY INSTRUCTIONS .................... Floor stand ......................Microscope ......................Connecting to a power source ................Battery operation, maintenance and safety ............Foot controls ......................Binocular assistant microscope ................
  • Page 2 SO-5000 Ophthalmic Microscope User Manual Page 2 of 36 LIST OF FIGURES Figure 1 Assembling the floor stand ..............Figure 2 Fixing the floor stand ................Figure 3 Attaching the clamp to a mounting surface ......... Figure 4 Assembling the microscope ..............

  • Page 3: Introduction

    Apart from those instructions within this manual, there are no user-serviceable parts in this microscope. Scan Optics will retain the discretion to advise whether any repairs may be taken out by external qualified technical personnel, or whether part(s) of the microscope must be returned to the manufacturer’s premises for service or repairs to be carried out under warranty or otherwise.

  • Page 4: Parts List

    SO-5000 Ophthalmic Microscope User Manual Page 4 of 36 PARTS LIST MAIN ASSEMBLIES Clamp Assembly (includes power supply, clamp/pillar with pillar safety clamp) Articulated Arm Assembly (includes horizontal arm and adjustable pantograph arm) Microscope Assembly (includes tilt adjuster, microscope head, guide handle,...

  • Page 5: Assembly Instructions

    SO-5000 Ophthalmic Microscope User Manual Page 5 of 36 ASSEMBLY INSTRUCTIONS FLOOR STAND Remove the pillar, base and clamp mount from the case or carton. Insert the pillar into the hole. Tighten the two grubscrews using the 5mm socket key found in the tool kit to fix the pillar in place.

  • Page 6: Figure 2 Fixing The Floor Stand

    SO-5000 Ophthalmic Microscope User Manual Page 6 of 36 To fix the floor stand, screw the knobs down until the stops are resting evenly on the floor. Refer to figure 2. Screw the knurled discs down on to the floor stand base to lock the stops. Refer to figure 2.

  • Page 7: Microscope

    Note that in cases where the mounting surface is not rigid, over-tightening of the vertical clamp will not improve microscope stability. In this case, add a stiffening plate (such as Scan Optics Table Plate; Cat No. SO-291) beneath the mounting surface and apply the clamp over the stiffening plate and the original mounting surface..

  • Page 8: Figure 4 Assembling The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 8 of 36 Tighten the pillar safety clamp at a point midway up the vertical pillar. Refer to figure 4 (A). Remove the articulated arm assembly from the case, and place it on the vertical pillar. Make sure that the arm assembly rests against the pillar safety clamp.
  • Page 9 SO-5000 Ophthalmic Microscope User Manual Page 9 of 36 Remove the microscope eyepiece blanks and insert the eyepieces from the tool kit. Refer to figure 5. Retain the eyepiece blanks in the tool kit for repacking the microscope. Do not discard the eyepiece blanks.

  • Page 10: Connecting To A Power Source

    Page 10 of 36 CONNECTING TO A POWER SOURCE The Scan Optics Ophthalmic Microscope may be connected to either an earthed mains (90-260V) ac supply, or a 12V dc supply, or both. The power supply will automatically select the correct mains voltage.

  • Page 11: Battery Operation, Maintenance And Safety

    'beep' should be heard. BATTERY OPERATION, MAINTENANCE AND SAFETY Scan Optics recommend the use of sealed rechargeable lead-acid 12V batteries such as Scan Optics Cat Nos. SO-251 (small, light, lower (7Ah) capacity) and SO-9210 (large, heavy, higher (35Ah) capacity).

  • Page 12: Binocular Assistant Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 12 of 36 BINOCULAR ASSISTANT MICROSCOPE The optional assistant microscope allows an observer to view procedures under magnification within close proximity of the operating field. To attach the microscope, insert the mounting arm in to the mounting bracket and then insert the locking pin.

  • Page 13: Using The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 13 of 36 USING THE MICROSCOPE ARTICULATED ARM The articulated arm includes a number of features which enable the microscope to be adjusted in almost any position. Refer to figure 8. Figure 8 Adjusting the articulated arm The horizontal arm may rotate about the vertical pillar by unlocking the pillar lock knob (A).
  • Page 14 SO-5000 Ophthalmic Microscope User Manual Page 14 of 36 The knob (E) located on the underneath side of the end of the pantograph arm is used to lock the microscope assembly into place. To release the microscope assembly, simply unscrew the knob and lift the assembly carefully out of the collet The microscope head may be tilted up and down by rotating the knob (F).

  • Page 15: Panel Controls

    Page 15 of 36 PANEL CONTROLS The panel on the SO-5000 clamp/power supply unit controls the main (coaxial) and auxiliary lights, the powered focus and zoom speeds, and provides an interface for connections to the foot control and battery. Refer to figure 9.

  • Page 16: Lamphouse

    LAMPHOUSE The lamphouse on the SO-5000 ophthalmic microscope produces a coaxial light which provides a red fundus reflex from the back of the eye. The intensity of the light may be controlled from the top panel of the power supply or by using the optional foot controls.

  • Page 17: Positioning The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 17 of 36 POSITIONING THE MICROSCOPE Note that the equipment must be located more than 25 cm away from any medical gas system or disinfection or degreasing system containing flammable vapour. The power supply must also be protected from liquid splashes and spills.

  • Page 18: Foot Controls

    SO-5000 Ophthalmic Microscope User Manual Page 18 of 36 FOOT CONTROLS The foot control enables the surgeon to focus the microscope, change the magnification level and change the light intensity by depressing pedals, thus enabling both hands to be kept free for surgery.

  • Page 19: Sterilisation

    SO-5000 Ophthalmic Microscope User Manual Page 19 of 36 The microscope may be focused in the upward direction by depressing the pedal (C) and focused downwards using the pedal (F). The drive system will stop automatically when the focus has reached its upper or lower limit.

  • Page 20: Care And Maintenance

    SO-5000 Ophthalmic Microscope User Manual Page 20 of 36 CARE AND MAINTENANCE CARE OF THE OPTICAL HEAD Cleaning the optical components. The eyepieces should be checked for cleanliness each time the instrument is used. Surface dust should be removed with a clean, soft brush. Fingerprints or grease may be removed by lightly wiping with a cotton cloth or lens tissue moistened with a 70:30 mixture of absolute alcohol (either ethanol or methanol) and ether.

  • Page 21: Main Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 21 of 36 MAIN LAMP REPLACEMENT Always use protective gloves while replacing the lamp as lamp temperatures may be sufficiently high to burn skin should it come into contact with the glass capsule. Where possible, allow the lamp to cool before replacing it.

  • Page 22: Auxiliary Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 22 of 36 AUXILIARY LAMP REPLACEMENT NOTE: The auxiliary light assembly and lamp may be extreme ly hot after extended use. Use a cloth or protective glove to protect hands from the hot surfaces while undertaking lamp maintenance or replacement if the lamp has been on recently.

  • Page 23: Focus Friction

    Page 23 of 36 FOCUS FRICTION The SO-5000 microscope system relies on a friction device to allow the microscope head to stay in position when it is not being focussed, yet still allow the head to be focussed manually or by the motor drive.

  • Page 24: Power Supply

    In many countries the mains voltage fluctuates widely. Low voltage can greatly reduce the light output, and high voltage can greatly reduce lamp life. The Scan Optics power supply automatically provides a constant voltage to the lamp for a wide range of mains power voltages.

  • Page 25: Mould Pellet Replacement

    Page 25 of 36 MOULD PELLET REPLACEMENT The Scan Optics SO-5000 series microscopes are fitted with mould protection which lasts for approximately 3 years, but will be dependent on the storage conditions and humidity of the local environment. In extreme tropical climates it may be necessary to change the mould protection as frequently as every year.
  • Page 26 SO-5000 Ophthalmic Microscope User Manual Page 26 of 36 REPLACE ANTI-MOULD PELLET ZOOM ASSEMBLY BACK COVER ZOOM COVER MOUNTING SCREW Figure 14 Mould pellet replacement ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 27: Installing Camera Equipment

    SO-5000 Ophthalmic Microscope User Manual Page 27 of 36 INSTALLING CAMERA EQUIPMENT VIDEO CAMERA AND MONITOR Set up the microscope according to the instructions. Slide the second safety clamp on to the pillar and tighten lock. Slide the mounting arm onto the pillar and rest on top of the safety clamp.
  • Page 28 SO-5000 Ophthalmic Microscope User Manual Page 28 of 36 Figure 15 Video System Schematic ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 29: Attaching The Camera Adapter

    SO-5000 Ophthalmic Microscope User Manual Page 29 of 36 ATTACHING THE CAMERA ADAPTER Remove the protective plastic cap on the trinocular attachment (B) by unscrewing the fasteners located on either side. Attach the photo tube (C) on the trinocular attachment as shown and secure by screwing the fasteners back in.
  • Page 30 SO-5000 Ophthalmic Microscope User Manual Page 30 of 36 KEY TO FIGURE 16: A: Scan Optics SO-111 Microscope head and lamphouse assembly B: Olympus SZ-TRU trinocular attachment C: Olympus SZ-PT photo tube D: Olympus NFK 2.5 x LD photo eyepiece...

  • Page 31: Troubleshooting

    Intensity set Increase intensity on top panel or with foot control. Mould on optical If mould is evident, return microscope surfaces to Scan Optics for servicing. Focusing difficult Stiff focus knob Adjust focus friction. Focus system falls Adjust focus friction.
  • Page 32 SO-5000 Ophthalmic Microscope User Manual Page 32 of 36 SYMPTOM CAUSE REMEDY Microscope unstable G-clamp loose Tighten G-clamp. Mounting surface Use more rigid mounting surface. unstable Microscope head Check microscope correctly seated in movement/vibration collet. Microscope Eyepieces too high Tilt head as necessary.

  • Page 33: Specifications

    SO-5000 Ophthalmic Microscope User Manual Page 33 of 36 SPECIFICATIONS OPTICAL HEAD VIEWING SYSTEM Binocular, stereoscopic (convergence angle 12 Eyepiece tube inclination 45 MAGNIFICATION Zoom magnification, range 4.2 x - 25x Control knobs removable for sterilisation WORKING DISTANCE Lamphouse prism to object distance 165 mm...

  • Page 34: Power Supply

    SO-5000 Ophthalmic Microscope User Manual Page 34 of 36 POWER SUPPLY MAINS POWER 90-260V ac, 47-440Hz universal input. OUTPUT Regulated output with soft start. INTENSITY CONTROL 5 step EARTHING Via earth lead of power cable (green/yellow) DIRECT CURRENT 12 V dc source optional, automatically selected if...
  • Page 35 SO-5000 Ophthalmic Microscope User Manual Page 35 of 36 SO-1370 CAMERA SPECIFICATIONS WATEC WAT-202B CCD Ÿ Ultra Miniature, High Resolution Colour Camera Ÿ 1/3” pick-up element for wide field and high resolution Ÿ white balance selection for incandescent lamp Ÿ...
  • Page 36 SO-5000 Ophthalmic Microscope User Manual Page 36 of 36 SO-1380 MONITOR SPECIFICATIONS TFT LCD Ÿ CE Marked Ÿ Tested to comply with FCC standards. FUNCTIONS AV in, AV out Optional TV tuner Optional PAL or NTSC versions. SCREEN SIZE 130 x 99 mm (W x H), diagonal 165 mm (6.5”) POWER REQUIREMENT 12V dc, <...

  • Page 37: So-1370 Camera

    SO-5000 Ophthalmic Microscope User Manual Page 1 of 36 CONTENTS INTRODUCTION ........................PARTS LIST ........................ASSEMBLY INSTRUCTIONS .................... Floor stand ......................Microscope ......................Connecting to a power source ................Battery operation, maintenance and safety ............Foot controls ......................Binocular assistant microscope ................

  • Page 38: Figure 5 Inserting The Eyepieces And Sterilisable Covers

    SO-5000 Ophthalmic Microscope User Manual Page 2 of 36 LIST OF FIGURES Figure 1 Assembling the floor stand ..............Figure 2 Fixing the floor stand ................Figure 3 Attaching the clamp to a mounting surface ......... Figure 4 Assembling the microscope ..............

  • Page 39: Introduction

    Apart from those instructions within this manual, there are no user-serviceable parts in this microscope. Scan Optics will retain the discretion to advise whether any repairs may be taken out by external qualified technical personnel, or whether part(s) of the microscope must be returned to the manufacturer’s premises for service or repairs to be carried out under warranty or otherwise.

  • Page 40: Parts List

    SO-5000 Ophthalmic Microscope User Manual Page 4 of 36 PARTS LIST MAIN ASSEMBLIES Clamp Assembly (includes power supply, clamp/pillar with pillar safety clamp) Articulated Arm Assembly (includes horizontal arm and adjustable pantograph arm) Microscope Assembly (includes tilt adjuster, microscope head, guide handle,...

  • Page 41: Assembly Instructions

    SO-5000 Ophthalmic Microscope User Manual Page 5 of 36 ASSEMBLY INSTRUCTIONS FLOOR STAND Remove the pillar, base and clamp mount from the case or carton. Insert the pillar into the hole. Tighten the two grubscrews using the 5mm socket key found in the tool kit to fix the pillar in place.
  • Page 42 SO-5000 Ophthalmic Microscope User Manual Page 6 of 36 To fix the floor stand, screw the knobs down until the stops are resting evenly on the floor. Refer to figure 2. Screw the knurled discs down on to the floor stand base to lock the stops. Refer to figure 2.

  • Page 43: Microscope

    Note that in cases where the mounting surface is not rigid, over-tightening of the vertical clamp will not improve microscope stability. In this case, add a stiffening plate (such as Scan Optics Table Plate; Cat No. SO-291) beneath the mounting surface and apply the clamp over the stiffening plate and the original mounting surface..
  • Page 44 SO-5000 Ophthalmic Microscope User Manual Page 8 of 36 Tighten the pillar safety clamp at a point midway up the vertical pillar. Refer to figure 4 (A). Remove the articulated arm assembly from the case, and place it on the vertical pillar. Make sure that the arm assembly rests against the pillar safety clamp.
  • Page 45 SO-5000 Ophthalmic Microscope User Manual Page 9 of 36 Remove the microscope eyepiece blanks and insert the eyepieces from the tool kit. Refer to figure 5. Retain the eyepiece blanks in the tool kit for repacking the microscope. Do not discard the eyepiece blanks.

  • Page 46: Connecting To A Power Source

    Page 10 of 36 CONNECTING TO A POWER SOURCE The Scan Optics Ophthalmic Microscope may be connected to either an earthed mains (90-260V) ac supply, or a 12V dc supply, or both. The power supply will automatically select the correct mains voltage.

  • Page 47: Battery Operation, Maintenance And Safety

    'beep' should be heard. BATTERY OPERATION, MAINTENANCE AND SAFETY Scan Optics recommend the use of sealed rechargeable lead-acid 12V batteries such as Scan Optics Cat Nos. SO-251 (small, light, lower (7Ah) capacity) and SO-9210 (large, heavy, higher (35Ah) capacity).

  • Page 48: Binocular Assistant Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 12 of 36 BINOCULAR ASSISTANT MICROSCOPE The optional assistant microscope allows an observer to view procedures under magnification within close proximity of the operating field. To attach the microscope, insert the mounting arm in to the mounting bracket and then insert the locking pin.

  • Page 49: Using The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 13 of 36 USING THE MICROSCOPE ARTICULATED ARM The articulated arm includes a number of features which enable the microscope to be adjusted in almost any position. Refer to figure 8. Figure 8 Adjusting the articulated arm The horizontal arm may rotate about the vertical pillar by unlocking the pillar lock knob (A).
  • Page 50 SO-5000 Ophthalmic Microscope User Manual Page 14 of 36 The knob (E) located on the underneath side of the end of the pantograph arm is used to lock the microscope assembly into place. To release the microscope assembly, simply unscrew the knob and lift the assembly carefully out of the collet The microscope head may be tilted up and down by rotating the knob (F).

  • Page 51: Panel Controls

    Page 15 of 36 PANEL CONTROLS The panel on the SO-5000 clamp/power supply unit controls the main (coaxial) and auxiliary lights, the powered focus and zoom speeds, and provides an interface for connections to the foot control and battery. Refer to figure 9.

  • Page 52: Lamphouse

    LAMPHOUSE The lamphouse on the SO-5000 ophthalmic microscope produces a coaxial light which provides a red fundus reflex from the back of the eye. The intensity of the light may be controlled from the top panel of the power supply or by using the optional foot controls.

  • Page 53: Positioning The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 17 of 36 POSITIONING THE MICROSCOPE Note that the equipment must be located more than 25 cm away from any medical gas system or disinfection or degreasing system containing flammable vapour. The power supply must also be protected from liquid splashes and spills.

  • Page 54: Foot Controls

    SO-5000 Ophthalmic Microscope User Manual Page 18 of 36 FOOT CONTROLS The foot control enables the surgeon to focus the microscope, change the magnification level and change the light intensity by depressing pedals, thus enabling both hands to be kept free for surgery.

  • Page 55: Sterilisation

    SO-5000 Ophthalmic Microscope User Manual Page 19 of 36 The microscope may be focused in the upward direction by depressing the pedal (C) and focused downwards using the pedal (F). The drive system will stop automatically when the focus has reached its upper or lower limit.

  • Page 56: Care And Maintenance

    SO-5000 Ophthalmic Microscope User Manual Page 20 of 36 CARE AND MAINTENANCE CARE OF THE OPTICAL HEAD Cleaning the optical components. The eyepieces should be checked for cleanliness each time the instrument is used. Surface dust should be removed with a clean, soft brush. Fingerprints or grease may be removed by lightly wiping with a cotton cloth or lens tissue moistened with a 70:30 mixture of absolute alcohol (either ethanol or methanol) and ether.

  • Page 57: Main Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 21 of 36 MAIN LAMP REPLACEMENT Always use protective gloves while replacing the lamp as lamp temperatures may be sufficiently high to burn skin should it come into contact with the glass capsule. Where possible, allow the lamp to cool before replacing it.

  • Page 58: Auxiliary Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 22 of 36 AUXILIARY LAMP REPLACEMENT NOTE: The auxiliary light assembly and lamp may be extreme ly hot after extended use. Use a cloth or protective glove to protect hands from the hot surfaces while undertaking lamp maintenance or replacement if the lamp has been on recently.

  • Page 59: Focus Friction

    Page 23 of 36 FOCUS FRICTION The SO-5000 microscope system relies on a friction device to allow the microscope head to stay in position when it is not being focussed, yet still allow the head to be focussed manually or by the motor drive.

  • Page 60: Power Supply

    In many countries the mains voltage fluctuates widely. Low voltage can greatly reduce the light output, and high voltage can greatly reduce lamp life. The Scan Optics power supply automatically provides a constant voltage to the lamp for a wide range of mains power voltages.

  • Page 61: Mould Pellet Replacement

    Page 25 of 36 MOULD PELLET REPLACEMENT The Scan Optics SO-5000 series microscopes are fitted with mould protection which lasts for approximately 3 years, but will be dependent on the storage conditions and humidity of the local environment. In extreme tropical climates it may be necessary to change the mould protection as frequently as every year.
  • Page 62 SO-5000 Ophthalmic Microscope User Manual Page 26 of 36 REPLACE ANTI-MOULD PELLET ZOOM ASSEMBLY BACK COVER ZOOM COVER MOUNTING SCREW Figure 14 Mould pellet replacement ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 63: Installing Camera Equipment

    SO-5000 Ophthalmic Microscope User Manual Page 27 of 36 INSTALLING CAMERA EQUIPMENT VIDEO CAMERA AND MONITOR Set up the microscope according to the instructions. Slide the second safety clamp on to the pillar and tighten lock. Slide the mounting arm onto the pillar and rest on top of the safety clamp.
  • Page 64 SO-5000 Ophthalmic Microscope User Manual Page 28 of 36 Figure 15 Video System Schematic ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 65: Attaching The Camera Adapter

    SO-5000 Ophthalmic Microscope User Manual Page 29 of 36 ATTACHING THE CAMERA ADAPTER Remove the protective plastic cap on the trinocular attachment (B) by unscrewing the fasteners located on either side. Attach the photo tube (C) on the trinocular attachment as shown and secure by screwing the fasteners back in.
  • Page 66 SO-5000 Ophthalmic Microscope User Manual Page 30 of 36 KEY TO FIGURE 16: A: Scan Optics SO-111 Microscope head and lamphouse assembly B: Olympus SZ-TRU trinocular attachment C: Olympus SZ-PT photo tube D: Olympus NFK 2.5 x LD photo eyepiece...

  • Page 67: Troubleshooting

    Intensity set Increase intensity on top panel or with foot control. Mould on optical If mould is evident, return microscope surfaces to Scan Optics for servicing. Focusing difficult Stiff focus knob Adjust focus friction. Focus system falls Adjust focus friction.
  • Page 68 SO-5000 Ophthalmic Microscope User Manual Page 32 of 36 SYMPTOM CAUSE REMEDY Microscope unstable G-clamp loose Tighten G-clamp. Mounting surface Use more rigid mounting surface. unstable Microscope head Check microscope correctly seated in movement/vibration collet. Microscope Eyepieces too high Tilt head as necessary.

  • Page 69: Specifications

    SO-5000 Ophthalmic Microscope User Manual Page 33 of 36 SPECIFICATIONS OPTICAL HEAD VIEWING SYSTEM Binocular, stereoscopic (convergence angle 12 Eyepiece tube inclination 45 MAGNIFICATION Zoom magnification, range 4.2 x - 25x Control knobs removable for sterilisation WORKING DISTANCE Lamphouse prism to object distance 165 mm...

  • Page 70: Power Supply

    SO-5000 Ophthalmic Microscope User Manual Page 34 of 36 POWER SUPPLY MAINS POWER 90-260V ac, 47-440Hz universal input. OUTPUT Regulated output with soft start. INTENSITY CONTROL 5 step EARTHING Via earth lead of power cable (green/yellow) DIRECT CURRENT 12 V dc source optional, automatically selected if...
  • Page 71 SO-5000 Ophthalmic Microscope User Manual Page 35 of 36 SO-1370 CAMERA SPECIFICATIONS WATEC WAT-202B CCD Ÿ Ultra Miniature, High Resolution Colour Camera Ÿ 1/3” pick-up element for wide field and high resolution Ÿ white balance selection for incandescent lamp Ÿ...
  • Page 72 SO-5000 Ophthalmic Microscope User Manual Page 36 of 36 SO-1380 MONITOR SPECIFICATIONS TFT LCD Ÿ CE Marked Ÿ Tested to comply with FCC standards. FUNCTIONS AV in, AV out Optional TV tuner Optional PAL or NTSC versions. SCREEN SIZE 130 x 99 mm (W x H), diagonal 165 mm (6.5”) POWER REQUIREMENT 12V dc, <...
  • Page 73 SO-5000 Ophthalmic Microscope User Manual Page 1 of 36 CONTENTS INTRODUCTION ........................PARTS LIST ........................ASSEMBLY INSTRUCTIONS .................... Floor stand ......................Microscope ......................Connecting to a power source ................Battery operation, maintenance and safety ............Foot controls ......................Binocular assistant microscope ................
  • Page 74 SO-5000 Ophthalmic Microscope User Manual Page 2 of 36 LIST OF FIGURES Figure 1 Assembling the floor stand ..............Figure 2 Fixing the floor stand ................Figure 3 Attaching the clamp to a mounting surface ......... Figure 4 Assembling the microscope ..............

  • Page 75: Introduction

    Apart from those instructions within this manual, there are no user-serviceable parts in this microscope. Scan Optics will retain the discretion to advise whether any repairs may be taken out by external qualified technical personnel, or whether part(s) of the microscope must be returned to the manufacturer’s premises for service or repairs to be carried out under warranty or otherwise.

  • Page 76: Parts List

    SO-5000 Ophthalmic Microscope User Manual Page 4 of 36 PARTS LIST MAIN ASSEMBLIES Clamp Assembly (includes power supply, clamp/pillar with pillar safety clamp) Articulated Arm Assembly (includes horizontal arm and adjustable pantograph arm) Microscope Assembly (includes tilt adjuster, microscope head, guide handle,...

  • Page 77: Assembly Instructions

    SO-5000 Ophthalmic Microscope User Manual Page 5 of 36 ASSEMBLY INSTRUCTIONS FLOOR STAND Remove the pillar, base and clamp mount from the case or carton. Insert the pillar into the hole. Tighten the two grubscrews using the 5mm socket key found in the tool kit to fix the pillar in place.
  • Page 78 SO-5000 Ophthalmic Microscope User Manual Page 6 of 36 To fix the floor stand, screw the knobs down until the stops are resting evenly on the floor. Refer to figure 2. Screw the knurled discs down on to the floor stand base to lock the stops. Refer to figure 2.

  • Page 79: Microscope

    Note that in cases where the mounting surface is not rigid, over-tightening of the vertical clamp will not improve microscope stability. In this case, add a stiffening plate (such as Scan Optics Table Plate; Cat No. SO-291) beneath the mounting surface and apply the clamp over the stiffening plate and the original mounting surface..
  • Page 80 SO-5000 Ophthalmic Microscope User Manual Page 8 of 36 Tighten the pillar safety clamp at a point midway up the vertical pillar. Refer to figure 4 (A). Remove the articulated arm assembly from the case, and place it on the vertical pillar. Make sure that the arm assembly rests against the pillar safety clamp.
  • Page 81 SO-5000 Ophthalmic Microscope User Manual Page 9 of 36 Remove the microscope eyepiece blanks and insert the eyepieces from the tool kit. Refer to figure 5. Retain the eyepiece blanks in the tool kit for repacking the microscope. Do not discard the eyepiece blanks.

  • Page 82: Connecting To A Power Source

    Page 10 of 36 CONNECTING TO A POWER SOURCE The Scan Optics Ophthalmic Microscope may be connected to either an earthed mains (90-260V) ac supply, or a 12V dc supply, or both. The power supply will automatically select the correct mains voltage.

  • Page 83: Battery Operation, Maintenance And Safety

    'beep' should be heard. BATTERY OPERATION, MAINTENANCE AND SAFETY Scan Optics recommend the use of sealed rechargeable lead-acid 12V batteries such as Scan Optics Cat Nos. SO-251 (small, light, lower (7Ah) capacity) and SO-9210 (large, heavy, higher (35Ah) capacity).

  • Page 84: Binocular Assistant Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 12 of 36 BINOCULAR ASSISTANT MICROSCOPE The optional assistant microscope allows an observer to view procedures under magnification within close proximity of the operating field. To attach the microscope, insert the mounting arm in to the mounting bracket and then insert the locking pin.

  • Page 85: Using The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 13 of 36 USING THE MICROSCOPE ARTICULATED ARM The articulated arm includes a number of features which enable the microscope to be adjusted in almost any position. Refer to figure 8. Figure 8 Adjusting the articulated arm The horizontal arm may rotate about the vertical pillar by unlocking the pillar lock knob (A).
  • Page 86 SO-5000 Ophthalmic Microscope User Manual Page 14 of 36 The knob (E) located on the underneath side of the end of the pantograph arm is used to lock the microscope assembly into place. To release the microscope assembly, simply unscrew the knob and lift the assembly carefully out of the collet The microscope head may be tilted up and down by rotating the knob (F).

  • Page 87: Panel Controls

    Page 15 of 36 PANEL CONTROLS The panel on the SO-5000 clamp/power supply unit controls the main (coaxial) and auxiliary lights, the powered focus and zoom speeds, and provides an interface for connections to the foot control and battery. Refer to figure 9.

  • Page 88: Lamphouse

    LAMPHOUSE The lamphouse on the SO-5000 ophthalmic microscope produces a coaxial light which provides a red fundus reflex from the back of the eye. The intensity of the light may be controlled from the top panel of the power supply or by using the optional foot controls.

  • Page 89: Positioning The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 17 of 36 POSITIONING THE MICROSCOPE Note that the equipment must be located more than 25 cm away from any medical gas system or disinfection or degreasing system containing flammable vapour. The power supply must also be protected from liquid splashes and spills.

  • Page 90: Foot Controls

    SO-5000 Ophthalmic Microscope User Manual Page 18 of 36 FOOT CONTROLS The foot control enables the surgeon to focus the microscope, change the magnification level and change the light intensity by depressing pedals, thus enabling both hands to be kept free for surgery.

  • Page 91: Sterilisation

    SO-5000 Ophthalmic Microscope User Manual Page 19 of 36 The microscope may be focused in the upward direction by depressing the pedal (C) and focused downwards using the pedal (F). The drive system will stop automatically when the focus has reached its upper or lower limit.

  • Page 92: Care And Maintenance

    SO-5000 Ophthalmic Microscope User Manual Page 20 of 36 CARE AND MAINTENANCE CARE OF THE OPTICAL HEAD Cleaning the optical components. The eyepieces should be checked for cleanliness each time the instrument is used. Surface dust should be removed with a clean, soft brush. Fingerprints or grease may be removed by lightly wiping with a cotton cloth or lens tissue moistened with a 70:30 mixture of absolute alcohol (either ethanol or methanol) and ether.

  • Page 93: Main Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 21 of 36 MAIN LAMP REPLACEMENT Always use protective gloves while replacing the lamp as lamp temperatures may be sufficiently high to burn skin should it come into contact with the glass capsule. Where possible, allow the lamp to cool before replacing it.

  • Page 94: Auxiliary Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 22 of 36 AUXILIARY LAMP REPLACEMENT NOTE: The auxiliary light assembly and lamp may be extreme ly hot after extended use. Use a cloth or protective glove to protect hands from the hot surfaces while undertaking lamp maintenance or replacement if the lamp has been on recently.

  • Page 95: Focus Friction

    Page 23 of 36 FOCUS FRICTION The SO-5000 microscope system relies on a friction device to allow the microscope head to stay in position when it is not being focussed, yet still allow the head to be focussed manually or by the motor drive.

  • Page 96: Power Supply

    In many countries the mains voltage fluctuates widely. Low voltage can greatly reduce the light output, and high voltage can greatly reduce lamp life. The Scan Optics power supply automatically provides a constant voltage to the lamp for a wide range of mains power voltages.

  • Page 97: Mould Pellet Replacement

    Page 25 of 36 MOULD PELLET REPLACEMENT The Scan Optics SO-5000 series microscopes are fitted with mould protection which lasts for approximately 3 years, but will be dependent on the storage conditions and humidity of the local environment. In extreme tropical climates it may be necessary to change the mould protection as frequently as every year.
  • Page 98 SO-5000 Ophthalmic Microscope User Manual Page 26 of 36 REPLACE ANTI-MOULD PELLET ZOOM ASSEMBLY BACK COVER ZOOM COVER MOUNTING SCREW Figure 14 Mould pellet replacement ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 99: Installing Camera Equipment

    SO-5000 Ophthalmic Microscope User Manual Page 27 of 36 INSTALLING CAMERA EQUIPMENT VIDEO CAMERA AND MONITOR Set up the microscope according to the instructions. Slide the second safety clamp on to the pillar and tighten lock. Slide the mounting arm onto the pillar and rest on top of the safety clamp.
  • Page 100 SO-5000 Ophthalmic Microscope User Manual Page 28 of 36 Figure 15 Video System Schematic ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 101: Attaching The Camera Adapter

    SO-5000 Ophthalmic Microscope User Manual Page 29 of 36 ATTACHING THE CAMERA ADAPTER Remove the protective plastic cap on the trinocular attachment (B) by unscrewing the fasteners located on either side. Attach the photo tube (C) on the trinocular attachment as shown and secure by screwing the fasteners back in.
  • Page 102 SO-5000 Ophthalmic Microscope User Manual Page 30 of 36 KEY TO FIGURE 16: A: Scan Optics SO-111 Microscope head and lamphouse assembly B: Olympus SZ-TRU trinocular attachment C: Olympus SZ-PT photo tube D: Olympus NFK 2.5 x LD photo eyepiece...

  • Page 103: Troubleshooting

    Intensity set Increase intensity on top panel or with foot control. Mould on optical If mould is evident, return microscope surfaces to Scan Optics for servicing. Focusing difficult Stiff focus knob Adjust focus friction. Focus system falls Adjust focus friction.
  • Page 104 SO-5000 Ophthalmic Microscope User Manual Page 32 of 36 SYMPTOM CAUSE REMEDY Microscope unstable G-clamp loose Tighten G-clamp. Mounting surface Use more rigid mounting surface. unstable Microscope head Check microscope correctly seated in movement/vibration collet. Microscope Eyepieces too high Tilt head as necessary.

  • Page 105: Specifications

    SO-5000 Ophthalmic Microscope User Manual Page 33 of 36 SPECIFICATIONS OPTICAL HEAD VIEWING SYSTEM Binocular, stereoscopic (convergence angle 12 Eyepiece tube inclination 45 MAGNIFICATION Zoom magnification, range 4.2 x - 25x Control knobs removable for sterilisation WORKING DISTANCE Lamphouse prism to object distance 165 mm...

  • Page 106: Power Supply

    SO-5000 Ophthalmic Microscope User Manual Page 34 of 36 POWER SUPPLY MAINS POWER 90-260V ac, 47-440Hz universal input. OUTPUT Regulated output with soft start. INTENSITY CONTROL 5 step EARTHING Via earth lead of power cable (green/yellow) DIRECT CURRENT 12 V dc source optional, automatically selected if...
  • Page 107 SO-5000 Ophthalmic Microscope User Manual Page 35 of 36 SO-1370 CAMERA SPECIFICATIONS WATEC WAT-202B CCD Ÿ Ultra Miniature, High Resolution Colour Camera Ÿ 1/3” pick-up element for wide field and high resolution Ÿ white balance selection for incandescent lamp Ÿ...
  • Page 108 SO-5000 Ophthalmic Microscope User Manual Page 36 of 36 SO-1380 MONITOR SPECIFICATIONS TFT LCD Ÿ CE Marked Ÿ Tested to comply with FCC standards. FUNCTIONS AV in, AV out Optional TV tuner Optional PAL or NTSC versions. SCREEN SIZE 130 x 99 mm (W x H), diagonal 165 mm (6.5”) POWER REQUIREMENT 12V dc, <...
  • Page 109 SO-5000 Ophthalmic Microscope User Manual Page 1 of 36 CONTENTS INTRODUCTION ........................PARTS LIST ........................ASSEMBLY INSTRUCTIONS .................... Floor stand ......................Microscope ......................Connecting to a power source ................Battery operation, maintenance and safety ............Foot controls ......................Binocular assistant microscope ................
  • Page 110 SO-5000 Ophthalmic Microscope User Manual Page 2 of 36 LIST OF FIGURES Figure 1 Assembling the floor stand ..............Figure 2 Fixing the floor stand ................Figure 3 Attaching the clamp to a mounting surface ......... Figure 4 Assembling the microscope ..............

  • Page 111: Introduction

    Apart from those instructions within this manual, there are no user-serviceable parts in this microscope. Scan Optics will retain the discretion to advise whether any repairs may be taken out by external qualified technical personnel, or whether part(s) of the microscope must be returned to the manufacturer’s premises for service or repairs to be carried out under warranty or otherwise.
  • Page 112 SO-5000 Ophthalmic Microscope User Manual Page 4 of 36 PARTS LIST MAIN ASSEMBLIES Clamp Assembly (includes power supply, clamp/pillar with pillar safety clamp) Articulated Arm Assembly (includes horizontal arm and adjustable pantograph arm) Microscope Assembly (includes tilt adjuster, microscope head, guide handle,...

  • Page 113: Assembly Instructions

    SO-5000 Ophthalmic Microscope User Manual Page 5 of 36 ASSEMBLY INSTRUCTIONS FLOOR STAND Remove the pillar, base and clamp mount from the case or carton. Insert the pillar into the hole. Tighten the two grubscrews using the 5mm socket key found in the tool kit to fix the pillar in place.
  • Page 114 SO-5000 Ophthalmic Microscope User Manual Page 6 of 36 To fix the floor stand, screw the knobs down until the stops are resting evenly on the floor. Refer to figure 2. Screw the knurled discs down on to the floor stand base to lock the stops. Refer to figure 2.

  • Page 115: Microscope

    Note that in cases where the mounting surface is not rigid, over-tightening of the vertical clamp will not improve microscope stability. In this case, add a stiffening plate (such as Scan Optics Table Plate; Cat No. SO-291) beneath the mounting surface and apply the clamp over the stiffening plate and the original mounting surface..
  • Page 116 SO-5000 Ophthalmic Microscope User Manual Page 8 of 36 Tighten the pillar safety clamp at a point midway up the vertical pillar. Refer to figure 4 (A). Remove the articulated arm assembly from the case, and place it on the vertical pillar. Make sure that the arm assembly rests against the pillar safety clamp.
  • Page 117 SO-5000 Ophthalmic Microscope User Manual Page 9 of 36 Remove the microscope eyepiece blanks and insert the eyepieces from the tool kit. Refer to figure 5. Retain the eyepiece blanks in the tool kit for repacking the microscope. Do not discard the eyepiece blanks.

  • Page 118: Connecting To A Power Source

    Page 10 of 36 CONNECTING TO A POWER SOURCE The Scan Optics Ophthalmic Microscope may be connected to either an earthed mains (90-260V) ac supply, or a 12V dc supply, or both. The power supply will automatically select the correct mains voltage.

  • Page 119: Battery Operation, Maintenance And Safety

    'beep' should be heard. BATTERY OPERATION, MAINTENANCE AND SAFETY Scan Optics recommend the use of sealed rechargeable lead-acid 12V batteries such as Scan Optics Cat Nos. SO-251 (small, light, lower (7Ah) capacity) and SO-9210 (large, heavy, higher (35Ah) capacity).

  • Page 120: Binocular Assistant Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 12 of 36 BINOCULAR ASSISTANT MICROSCOPE The optional assistant microscope allows an observer to view procedures under magnification within close proximity of the operating field. To attach the microscope, insert the mounting arm in to the mounting bracket and then insert the locking pin.

  • Page 121: Using The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 13 of 36 USING THE MICROSCOPE ARTICULATED ARM The articulated arm includes a number of features which enable the microscope to be adjusted in almost any position. Refer to figure 8. Figure 8 Adjusting the articulated arm The horizontal arm may rotate about the vertical pillar by unlocking the pillar lock knob (A).
  • Page 122 SO-5000 Ophthalmic Microscope User Manual Page 14 of 36 The knob (E) located on the underneath side of the end of the pantograph arm is used to lock the microscope assembly into place. To release the microscope assembly, simply unscrew the knob and lift the assembly carefully out of the collet The microscope head may be tilted up and down by rotating the knob (F).

  • Page 123: Panel Controls

    Page 15 of 36 PANEL CONTROLS The panel on the SO-5000 clamp/power supply unit controls the main (coaxial) and auxiliary lights, the powered focus and zoom speeds, and provides an interface for connections to the foot control and battery. Refer to figure 9.

  • Page 124: Lamphouse

    LAMPHOUSE The lamphouse on the SO-5000 ophthalmic microscope produces a coaxial light which provides a red fundus reflex from the back of the eye. The intensity of the light may be controlled from the top panel of the power supply or by using the optional foot controls.

  • Page 125: Positioning The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 17 of 36 POSITIONING THE MICROSCOPE Note that the equipment must be located more than 25 cm away from any medical gas system or disinfection or degreasing system containing flammable vapour. The power supply must also be protected from liquid splashes and spills.

  • Page 126: Foot Controls

    SO-5000 Ophthalmic Microscope User Manual Page 18 of 36 FOOT CONTROLS The foot control enables the surgeon to focus the microscope, change the magnification level and change the light intensity by depressing pedals, thus enabling both hands to be kept free for surgery.

  • Page 127: Sterilisation

    SO-5000 Ophthalmic Microscope User Manual Page 19 of 36 The microscope may be focused in the upward direction by depressing the pedal (C) and focused downwards using the pedal (F). The drive system will stop automatically when the focus has reached its upper or lower limit.

  • Page 128: Care And Maintenance

    SO-5000 Ophthalmic Microscope User Manual Page 20 of 36 CARE AND MAINTENANCE CARE OF THE OPTICAL HEAD Cleaning the optical components. The eyepieces should be checked for cleanliness each time the instrument is used. Surface dust should be removed with a clean, soft brush. Fingerprints or grease may be removed by lightly wiping with a cotton cloth or lens tissue moistened with a 70:30 mixture of absolute alcohol (either ethanol or methanol) and ether.

  • Page 129: Main Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 21 of 36 MAIN LAMP REPLACEMENT Always use protective gloves while replacing the lamp as lamp temperatures may be sufficiently high to burn skin should it come into contact with the glass capsule. Where possible, allow the lamp to cool before replacing it.

  • Page 130: Auxiliary Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 22 of 36 AUXILIARY LAMP REPLACEMENT NOTE: The auxiliary light assembly and lamp may be extreme ly hot after extended use. Use a cloth or protective glove to protect hands from the hot surfaces while undertaking lamp maintenance or replacement if the lamp has been on recently.

  • Page 131: Focus Friction

    Page 23 of 36 FOCUS FRICTION The SO-5000 microscope system relies on a friction device to allow the microscope head to stay in position when it is not being focussed, yet still allow the head to be focussed manually or by the motor drive.

  • Page 132: Power Supply

    In many countries the mains voltage fluctuates widely. Low voltage can greatly reduce the light output, and high voltage can greatly reduce lamp life. The Scan Optics power supply automatically provides a constant voltage to the lamp for a wide range of mains power voltages.

  • Page 133: Mould Pellet Replacement

    Page 25 of 36 MOULD PELLET REPLACEMENT The Scan Optics SO-5000 series microscopes are fitted with mould protection which lasts for approximately 3 years, but will be dependent on the storage conditions and humidity of the local environment. In extreme tropical climates it may be necessary to change the mould protection as frequently as every year.
  • Page 134 SO-5000 Ophthalmic Microscope User Manual Page 26 of 36 REPLACE ANTI-MOULD PELLET ZOOM ASSEMBLY BACK COVER ZOOM COVER MOUNTING SCREW Figure 14 Mould pellet replacement ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 135: Installing Camera Equipment

    SO-5000 Ophthalmic Microscope User Manual Page 27 of 36 INSTALLING CAMERA EQUIPMENT VIDEO CAMERA AND MONITOR Set up the microscope according to the instructions. Slide the second safety clamp on to the pillar and tighten lock. Slide the mounting arm onto the pillar and rest on top of the safety clamp.
  • Page 136 SO-5000 Ophthalmic Microscope User Manual Page 28 of 36 Figure 15 Video System Schematic ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 137: Attaching The Camera Adapter

    SO-5000 Ophthalmic Microscope User Manual Page 29 of 36 ATTACHING THE CAMERA ADAPTER Remove the protective plastic cap on the trinocular attachment (B) by unscrewing the fasteners located on either side. Attach the photo tube (C) on the trinocular attachment as shown and secure by screwing the fasteners back in.
  • Page 138 SO-5000 Ophthalmic Microscope User Manual Page 30 of 36 KEY TO FIGURE 16: A: Scan Optics SO-111 Microscope head and lamphouse assembly B: Olympus SZ-TRU trinocular attachment C: Olympus SZ-PT photo tube D: Olympus NFK 2.5 x LD photo eyepiece...

  • Page 139: Troubleshooting

    Intensity set Increase intensity on top panel or with foot control. Mould on optical If mould is evident, return microscope surfaces to Scan Optics for servicing. Focusing difficult Stiff focus knob Adjust focus friction. Focus system falls Adjust focus friction.
  • Page 140 SO-5000 Ophthalmic Microscope User Manual Page 32 of 36 SYMPTOM CAUSE REMEDY Microscope unstable G-clamp loose Tighten G-clamp. Mounting surface Use more rigid mounting surface. unstable Microscope head Check microscope correctly seated in movement/vibration collet. Microscope Eyepieces too high Tilt head as necessary.

  • Page 141: Specifications

    SO-5000 Ophthalmic Microscope User Manual Page 33 of 36 SPECIFICATIONS OPTICAL HEAD VIEWING SYSTEM Binocular, stereoscopic (convergence angle 12 Eyepiece tube inclination 45 MAGNIFICATION Zoom magnification, range 4.2 x - 25x Control knobs removable for sterilisation WORKING DISTANCE Lamphouse prism to object distance 165 mm...

  • Page 142: Power Supply

    SO-5000 Ophthalmic Microscope User Manual Page 34 of 36 POWER SUPPLY MAINS POWER 90-260V ac, 47-440Hz universal input. OUTPUT Regulated output with soft start. INTENSITY CONTROL 5 step EARTHING Via earth lead of power cable (green/yellow) DIRECT CURRENT 12 V dc source optional, automatically selected if...
  • Page 143 SO-5000 Ophthalmic Microscope User Manual Page 35 of 36 SO-1370 CAMERA SPECIFICATIONS WATEC WAT-202B CCD Ÿ Ultra Miniature, High Resolution Colour Camera Ÿ 1/3” pick-up element for wide field and high resolution Ÿ white balance selection for incandescent lamp Ÿ...
  • Page 144 SO-5000 Ophthalmic Microscope User Manual Page 36 of 36 SO-1380 MONITOR SPECIFICATIONS TFT LCD Ÿ CE Marked Ÿ Tested to comply with FCC standards. FUNCTIONS AV in, AV out Optional TV tuner Optional PAL or NTSC versions. SCREEN SIZE 130 x 99 mm (W x H), diagonal 165 mm (6.5”) POWER REQUIREMENT 12V dc, <...

  • Page 145: So-1370 Camera

    SO-5000 Ophthalmic Microscope User Manual Page 1 of 36 CONTENTS INTRODUCTION ........................PARTS LIST ........................ASSEMBLY INSTRUCTIONS .................... Floor stand ......................Microscope ......................Connecting to a power source ................Battery operation, maintenance and safety ............Foot controls ......................Binocular assistant microscope ................
  • Page 146 SO-5000 Ophthalmic Microscope User Manual Page 2 of 36 LIST OF FIGURES Figure 1 Assembling the floor stand ..............Figure 2 Fixing the floor stand ................Figure 3 Attaching the clamp to a mounting surface ......... Figure 4 Assembling the microscope ..............

  • Page 147: Introduction

    Apart from those instructions within this manual, there are no user-serviceable parts in this microscope. Scan Optics will retain the discretion to advise whether any repairs may be taken out by external qualified technical personnel, or whether part(s) of the microscope must be returned to the manufacturer’s premises for service or repairs to be carried out under warranty or otherwise.
  • Page 148 SO-5000 Ophthalmic Microscope User Manual Page 4 of 36 PARTS LIST MAIN ASSEMBLIES Clamp Assembly (includes power supply, clamp/pillar with pillar safety clamp) Articulated Arm Assembly (includes horizontal arm and adjustable pantograph arm) Microscope Assembly (includes tilt adjuster, microscope head, guide handle,...

  • Page 149: Assembly Instructions

    SO-5000 Ophthalmic Microscope User Manual Page 5 of 36 ASSEMBLY INSTRUCTIONS FLOOR STAND Remove the pillar, base and clamp mount from the case or carton. Insert the pillar into the hole. Tighten the two grubscrews using the 5mm socket key found in the tool kit to fix the pillar in place.
  • Page 150 SO-5000 Ophthalmic Microscope User Manual Page 6 of 36 To fix the floor stand, screw the knobs down until the stops are resting evenly on the floor. Refer to figure 2. Screw the knurled discs down on to the floor stand base to lock the stops. Refer to figure 2.

  • Page 151: Microscope

    Note that in cases where the mounting surface is not rigid, over-tightening of the vertical clamp will not improve microscope stability. In this case, add a stiffening plate (such as Scan Optics Table Plate; Cat No. SO-291) beneath the mounting surface and apply the clamp over the stiffening plate and the original mounting surface..
  • Page 152 SO-5000 Ophthalmic Microscope User Manual Page 8 of 36 Tighten the pillar safety clamp at a point midway up the vertical pillar. Refer to figure 4 (A). Remove the articulated arm assembly from the case, and place it on the vertical pillar. Make sure that the arm assembly rests against the pillar safety clamp.
  • Page 153 SO-5000 Ophthalmic Microscope User Manual Page 9 of 36 Remove the microscope eyepiece blanks and insert the eyepieces from the tool kit. Refer to figure 5. Retain the eyepiece blanks in the tool kit for repacking the microscope. Do not discard the eyepiece blanks.

  • Page 154: Connecting To A Power Source

    Page 10 of 36 CONNECTING TO A POWER SOURCE The Scan Optics Ophthalmic Microscope may be connected to either an earthed mains (90-260V) ac supply, or a 12V dc supply, or both. The power supply will automatically select the correct mains voltage.

  • Page 155: Battery Operation, Maintenance And Safety

    'beep' should be heard. BATTERY OPERATION, MAINTENANCE AND SAFETY Scan Optics recommend the use of sealed rechargeable lead-acid 12V batteries such as Scan Optics Cat Nos. SO-251 (small, light, lower (7Ah) capacity) and SO-9210 (large, heavy, higher (35Ah) capacity).

  • Page 156: Binocular Assistant Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 12 of 36 BINOCULAR ASSISTANT MICROSCOPE The optional assistant microscope allows an observer to view procedures under magnification within close proximity of the operating field. To attach the microscope, insert the mounting arm in to the mounting bracket and then insert the locking pin.

  • Page 157: Using The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 13 of 36 USING THE MICROSCOPE ARTICULATED ARM The articulated arm includes a number of features which enable the microscope to be adjusted in almost any position. Refer to figure 8. Figure 8 Adjusting the articulated arm The horizontal arm may rotate about the vertical pillar by unlocking the pillar lock knob (A).
  • Page 158 SO-5000 Ophthalmic Microscope User Manual Page 14 of 36 The knob (E) located on the underneath side of the end of the pantograph arm is used to lock the microscope assembly into place. To release the microscope assembly, simply unscrew the knob and lift the assembly carefully out of the collet The microscope head may be tilted up and down by rotating the knob (F).

  • Page 159: Panel Controls

    Page 15 of 36 PANEL CONTROLS The panel on the SO-5000 clamp/power supply unit controls the main (coaxial) and auxiliary lights, the powered focus and zoom speeds, and provides an interface for connections to the foot control and battery. Refer to figure 9.

  • Page 160: Lamphouse

    LAMPHOUSE The lamphouse on the SO-5000 ophthalmic microscope produces a coaxial light which provides a red fundus reflex from the back of the eye. The intensity of the light may be controlled from the top panel of the power supply or by using the optional foot controls.

  • Page 161: Positioning The Microscope

    SO-5000 Ophthalmic Microscope User Manual Page 17 of 36 POSITIONING THE MICROSCOPE Note that the equipment must be located more than 25 cm away from any medical gas system or disinfection or degreasing system containing flammable vapour. The power supply must also be protected from liquid splashes and spills.

  • Page 162: Foot Controls

    SO-5000 Ophthalmic Microscope User Manual Page 18 of 36 FOOT CONTROLS The foot control enables the surgeon to focus the microscope, change the magnification level and change the light intensity by depressing pedals, thus enabling both hands to be kept free for surgery.

  • Page 163: Sterilisation

    SO-5000 Ophthalmic Microscope User Manual Page 19 of 36 The microscope may be focused in the upward direction by depressing the pedal (C) and focused downwards using the pedal (F). The drive system will stop automatically when the focus has reached its upper or lower limit.

  • Page 164: Care And Maintenance

    SO-5000 Ophthalmic Microscope User Manual Page 20 of 36 CARE AND MAINTENANCE CARE OF THE OPTICAL HEAD Cleaning the optical components. The eyepieces should be checked for cleanliness each time the instrument is used. Surface dust should be removed with a clean, soft brush. Fingerprints or grease may be removed by lightly wiping with a cotton cloth or lens tissue moistened with a 70:30 mixture of absolute alcohol (either ethanol or methanol) and ether.

  • Page 165: Main Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 21 of 36 MAIN LAMP REPLACEMENT Always use protective gloves while replacing the lamp as lamp temperatures may be sufficiently high to burn skin should it come into contact with the glass capsule. Where possible, allow the lamp to cool before replacing it.

  • Page 166: Auxiliary Lamp Replacement

    SO-5000 Ophthalmic Microscope User Manual Page 22 of 36 AUXILIARY LAMP REPLACEMENT NOTE: The auxiliary light assembly and lamp may be extreme ly hot after extended use. Use a cloth or protective glove to protect hands from the hot surfaces while undertaking lamp maintenance or replacement if the lamp has been on recently.

  • Page 167: Focus Friction

    Page 23 of 36 FOCUS FRICTION The SO-5000 microscope system relies on a friction device to allow the microscope head to stay in position when it is not being focussed, yet still allow the head to be focussed manually or by the motor drive.

  • Page 168: Power Supply

    In many countries the mains voltage fluctuates widely. Low voltage can greatly reduce the light output, and high voltage can greatly reduce lamp life. The Scan Optics power supply automatically provides a constant voltage to the lamp for a wide range of mains power voltages.

  • Page 169: Mould Pellet Replacement

    Page 25 of 36 MOULD PELLET REPLACEMENT The Scan Optics SO-5000 series microscopes are fitted with mould protection which lasts for approximately 3 years, but will be dependent on the storage conditions and humidity of the local environment. In extreme tropical climates it may be necessary to change the mould protection as frequently as every year.
  • Page 170 SO-5000 Ophthalmic Microscope User Manual Page 26 of 36 REPLACE ANTI-MOULD PELLET ZOOM ASSEMBLY BACK COVER ZOOM COVER MOUNTING SCREW Figure 14 Mould pellet replacement ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 171: Installing Camera Equipment

    SO-5000 Ophthalmic Microscope User Manual Page 27 of 36 INSTALLING CAMERA EQUIPMENT VIDEO CAMERA AND MONITOR Set up the microscope according to the instructions. Slide the second safety clamp on to the pillar and tighten lock. Slide the mounting arm onto the pillar and rest on top of the safety clamp.
  • Page 172 SO-5000 Ophthalmic Microscope User Manual Page 28 of 36 Figure 15 Video System Schematic ISSUE NUMBER: SUPERSEDES: WRITTEN BY: CHECKED BY: DATE: 22/05/01 DATE: 22/08/97 DATE: 22/08/97 DATE: 11/04/02...

  • Page 173: Attaching The Camera Adapter

    SO-5000 Ophthalmic Microscope User Manual Page 29 of 36 ATTACHING THE CAMERA ADAPTER Remove the protective plastic cap on the trinocular attachment (B) by unscrewing the fasteners located on either side. Attach the photo tube (C) on the trinocular attachment as shown and secure by screwing the fasteners back in.
  • Page 174 SO-5000 Ophthalmic Microscope User Manual Page 30 of 36 KEY TO FIGURE 16: A: Scan Optics SO-111 Microscope head and lamphouse assembly B: Olympus SZ-TRU trinocular attachment C: Olympus SZ-PT photo tube D: Olympus NFK 2.5 x LD photo eyepiece...

  • Page 175: Troubleshooting

    Intensity set Increase intensity on top panel or with foot control. Mould on optical If mould is evident, return microscope surfaces to Scan Optics for servicing. Focusing difficult Stiff focus knob Adjust focus friction. Focus system falls Adjust focus friction.
  • Page 176 SO-5000 Ophthalmic Microscope User Manual Page 32 of 36 SYMPTOM CAUSE REMEDY Microscope unstable G-clamp loose Tighten G-clamp. Mounting surface Use more rigid mounting surface. unstable Microscope head Check microscope correctly seated in movement/vibration collet. Microscope Eyepieces too high Tilt head as necessary.

  • Page 177: Specifications

    SO-5000 Ophthalmic Microscope User Manual Page 33 of 36 SPECIFICATIONS OPTICAL HEAD VIEWING SYSTEM Binocular, stereoscopic (convergence angle 12 Eyepiece tube inclination 45 MAGNIFICATION Zoom magnification, range 4.2 x - 25x Control knobs removable for sterilisation WORKING DISTANCE Lamphouse prism to object distance 165 mm...

  • Page 178: Power Supply

    SO-5000 Ophthalmic Microscope User Manual Page 34 of 36 POWER SUPPLY MAINS POWER 90-260V ac, 47-440Hz universal input. OUTPUT Regulated output with soft start. INTENSITY CONTROL 5 step EARTHING Via earth lead of power cable (green/yellow) DIRECT CURRENT 12 V dc source optional, automatically selected if...
  • Page 179 SO-5000 Ophthalmic Microscope User Manual Page 35 of 36 SO-1370 CAMERA SPECIFICATIONS WATEC WAT-202B CCD Ÿ Ultra Miniature, High Resolution Colour Camera Ÿ 1/3” pick-up element for wide field and high resolution Ÿ white balance selection for incandescent lamp Ÿ...
  • Page 180 SO-5000 Ophthalmic Microscope User Manual Page 36 of 36 SO-1380 MONITOR SPECIFICATIONS TFT LCD Ÿ CE Marked Ÿ Tested to comply with FCC standards. FUNCTIONS AV in, AV out Optional TV tuner Optional PAL or NTSC versions. SCREEN SIZE 130 x 99 mm (W x H), diagonal 165 mm (6.5”) POWER REQUIREMENT 12V dc, <...

Table of Contents
