IPPAN3-B
Installation Manual
Version 1.0
May 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Wattstopper IPPAN3-B and is the answer not in the manual?

Questions and answers

Summary of Contents for LEGRAND Wattstopper IPPAN3-B

  • Page 1 IPPAN3-B Installation Manual Version 1.0 May 2020...
  • Page 2: Table Of Contents

    CONTENTS OVERVIEW IPPAN3-B MODULE SPECIFICATIONS ANTENNAS OPERATING CHANNELS MODES OF OPERATION INSTALLATION DESIGN GUIDELINES END USER GUIDELINES AGENCY CERTIFICATIONS OEM LABELING REQUIREMENTS END USER LICENSE AGREEMENT...
  • Page 3: Overview

    1.0 OVERVIEW Thank you for choosing the IPPAN3-B module by Wattstopper. This manual will guide you through the process of installing the module. IPPAN3-B embeds wireless IPv6-based communication into each Wattstopper or host device, and uses wireless mesh networking technology to connect to the internet. Each IPPAN3-B module has a unique IPv6 address and “smart”...
  • Page 4: Specifications

    2.1 SPECIFICATIONS Specification IPPAN3-B Performance Internally calibrated for the selected IEEE Tuning Range channel Data Rate 250kb/s Max 802.15.4 Radio Output Power 16.4dBm Max BLE Radio Output Power 2.0dBm 802.15.4 Receiver Sensitivity -101dBm BLE Receiver Sensitivity -96 dBm Power Requirements 2.0 - 3.3Vdc, 0.3A General Dimensions...
  • Page 5 FIG 3.0 PIN # NAME DESCRIPTION 3v3/VCC Voltage Supply UART-DOUT Serial UART Out UART-DIN Serial UART In GPIO_4 High Drive General Purpose Input/Output RESET Module Inverted Reset EXT_SPI_MISO SPI Master Input → Slave Output EXT_SPI_CLK SPI Clock GPIO_0 General Purpose Input/Output EXT_SPI_MOSI SPI Master Output →...
  • Page 6 AMP_BYPASS/NFC2 Front End Bypass or Near-Field Communication General Purpose Input/Output (Low Frequency) GPIO_6 General Purpose Input/Output SWDCLK SWD Clock SWDIO SWD Data GPIO_2 General Purpose Input/Output GPIO_5 General Purpose Input/Output EXT_SPI_CS SPI CS or General Purpose Input/Output I2C_DATA I2C Data I2C_CLK I2C Clock GPIO-3...
  • Page 7: Antennas

    2.2 Antennas The IPPAN3-B module can have two antennas. ANT1 antenna use ceramic antenna , the gain less than 0.5dBi, and the ANT2 antenna can use Dipole antenna and other wire antennas, but the gain can not higher than 2.0dBi. 2.3 Operating Channels IPPAN3-B provides a wide range of channels.
  • Page 8: Modes Of Operation

    3.0 Modes of Operation The final use and application of IPPAN3-B is dependent on the firmware pre-installed at the factory. However, all applications have common modes of operations that can be summarized as follows for both the IEEE® 802.15.4 and BLE radios: NOTE: IEEE®...
  • Page 9: Installation

    4.0 INSTALLATION IPPAN3-B will come pre-programmed from the manufacturer, and in many cases pre-installed in a device. If you have elected to install IPPAN3-B in house, it is important to understand how to handle, install, and use properly. 4.1 DESIGN GUIDELINES ●...
  • Page 10: End User Guidelines

    4.2 END USER GUIDELINES The module is designed to be used in fixed locations. If the end user experiences communication problems it is recommended to move the transceivers closer to one another or purchase a repeater. Objects including, but not limited to, steel reinforced walls, metal electrical boxes, water, and snow may degrade the working distance between transceivers, and should be avoided.
  • Page 11 Operating Requirements and Conditions This device complies with Part 15, Subpart C, Section 15.247 of the FCC Rules,This device IPPAN3-B should not collocate with other radio. Mobile Device RF Exposure Statement This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment.
  • Page 12 Exigences et conditions de fonctionnement: La conception de IPPAN3-B est conforme aux limites d'exposition aux Frequences Radio définies par les normes IC et FCC pour les appareils mobiles. Déclaration d'exposition aux fréquences radio d'appareil mobile Cet équipement est conforme aux limites d’exposition aux radiations de la IC définies pour un environnement non contrôlé.
  • Page 13 6.0 OEM Labeling Requirements WARNING! The Original Equipment Manufacturer (OEM) must ensure that FCC/IC labeling requirements are met. This includes a clearly visible label on the outside of the final product enclosure that displays the contents shown below. FCC: Contains FCC ID: Q4B-P3B Contains IC: 21161-P3B Exigences en matière d'étiquetage OEM : ATTENTION! Le fabricant d'équipement d'origine (OEM) doit veiller à...
  • Page 14 7.0 END USER LICENSE AGREEMENT 1. USER NOTICE Please read this End User Software License Agreement (“License Agreement”) carefully before using your Wattstopper product. By installing and registering an Wattstopper device you hereby agree with the terms of this License Agreement. If you do not agree with the terms of this License Agreement, do not use the Wattstopper Product and Wattstopper Software.
  • Page 15 5. DISCLAIMER OF WARRANTIES TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, WATTSTOPPER PROVIDES THE WATTSTOPPER SOFTWARE “AS IS” AND “AS AVAILABLE” WITH ALL FAULTS AND WITHOUT WARRANTY OF ANY KIND. WATTSTOPPER HEREBY DISCLAIMS WITH RESPECT TO THE WATTSTOPPER SOFTWARE ALL WARRANTIES AND CONDITIONS, WHETHER EXPRESS, IMPLIED OR STATUTORY, INCLUDING BUT NOT LIMITED TO ANY (IF ANY) WARRANTIES OR CONDITIONS OF OR RELATED TO: NON-INFRINGEMENT, MERCHANTABILITY, FITNESS FOR A...
  • Page 16 9. GOVERNMENT END USERS The Wattstopper Software is classified as “commercial computer software” and the Documentation is classified as “commercial software documentation” or “commercial items.” Any use, modification, reproduction, release, performance, display or disclosure of the Wattstopper Software or Documentation shall be governed solely by the terms of this License Agreement and shall be prohibited except to the extent expressly permitted.
