416 50/51/52
OK
1
3
• Installation murale
• Installatie aan de wand
• Wall installation
• Wandmontage
• Instalación de pared
• Installazione a parete
• Instalação â parede
• Εγκατάσταση στον τοίχο
2
R1
10..15mm
0,5..1,5mm Ø
4
3
• Installation sur boîtier
• Installatie op doos
• Box installation
• Doseninstallation
• Instalación en caja
• Installazione su scatola
• Instalação na caixa
• Εγκατάσταση στο κουτί
416 50
• Branchement avec transformateur externe
• Aansluiting met uitwendige transformator
• Connection to the external transformer
• Anschluss mit externem Transformator
• Conexión con transformador externo
• Collegamento con trasformatore esterno
• Ligação com transformador externo
• Σύνδεση με εξωτερικό μετασχηματιστή
8 V~
TRANSFO.
12 V~
11/10-01 PC
