Connecting to Twisted Pair Network Cabling
Patch panel
RJ45 patch
cords
Wiremap
adapter
Connecting to a Bus Topology
Distribution
center
Connection to bus
RJ11
patch
Wiremap
cords
adapter
Note: You can swap the locations of the tester and
wiremap adapter.
www.
.com
Testing Cabling
Wall
outlet
EGS03.EPS
