SS1002 / SS2002 Supplemental Information

Installing the Box to the Faceplate

Step 1: Connecting the Wires from the Box to the Faceplate

Use the appropriate pin connections, below, to connect the wires from the XLR audio connector on the box to
the terminal strip on the circuit board. (Or in the case of the "U" box, connect wires from the intercom system to
the terminal strip.) To insert a wire into the terminal strip, push back the green lever on the top of the terminal as
shown, then insert the wire and release the lever.
XLR Connector
on Box
Pin 1
Pin 2
Pin 3
Table 1:
XLR Connector
on Box
Pin 1
Pin 2
Pin 3

Table 2: SS1002 wire connections for use in Clear-com System

SS1002 / SS2002 Supplemental Information
9330-7627-000 Rev B

General Instructions

If you ordered SS1002/ SS2002 boxes and faceplates separately, use
these instructions to assemble the speaker stations. Once you have
assembled the stations, refer to the User Manual for all installation and
operation information.
Terminal Strip on
Circuit Board
TB1-1
TB1-3
TB1-4
SS1002 wire connections for use in Audiocom System
Terminal Strip on
Circuit Board
TB1-1
TB1-3
TB1-4
Description
DC Common
Audiocom Channel audio low and +24VDC phan-
tom power
Audiocom Channel audio high and +24VDC
phantom power
Description
Common
Clear-com power input
Clear-com audio / call signal
