Page 1: User Manual
Telex User Manual Lufthansa LCU-3 Communication Unit 9350-7773-000 Rev b 12/2005... -
Page 2: Modes Of Operation
Parcel Service or specified shipper Telephone: (877) 392-3497 collect. Fax: (800) 323-0498 Modes of Operation HEADSET LCU-3 Power Figure 4. The LCU-3 Communication unit in battery powered mode of operation. HEADSET LCU-3 Power 4-pin XLR Connector 9 VOLT BATTERY CHARGE Figure 5. - Page 3 Bottom Panel: AUX, XLR, 4-pin male Pin 1 Talk (electret pwr) Pin 2 Listen Pin 3 Pin 4 External Power Charger connector, 3.5 mm Power Chassis GND Signal GND Mechanical Specifications Color Clear Anodized Aluminum Weight 13.4 oz. / 381 g Dimensions Length 5.0 inches / 127 mm Width...
-
Page 4: Specifications
Contents General Description ... 5 Features ... 5 Operations ... 6 Controls and Connections ... 6 Specifications ... 9 Modes of Operation ... 10 Specifications Power Requirements Battery 9VDC 250 mAh recharge able External Power 12-28 VDC Electrical Specifications Gain (Input to Output) +42 dBu ±2 dB Frequency Response 400 -10 kHz + 1/-3... -
Page 5: General Description
Battery Charger 3.5mm Connector 9 Volt, 250 mAh battery General Description The LCU-3 communication unit, is a simple accessory allowing three people to communicate in full-duplex mode (i.e., talking and listening at the same time). With two headsets, it covers all situations where up to three people... -
Page 6: Operation
GroundCom headset 2002 must use the PTT (push-to-talk) feature to enable their mic. System Power The LCU-3 communication unit is powered by a 9 Volt rechargable battery (see figure 1). It can also be powered externally through the AUX connector 9 Volt battery Figure 1.
