  • Page 1 RVON Resource Guide RVON-8 RVON-1 RVON-I/O...

  • Page 3: Basic Network Configuration

    CHAPTER 1 Basic Network Configuration Basic Network Configuration This section covers basic network configuration set-up and testing. Also covered are basic concepts and operations, including the difference between LAN and WAN networks and how IP Addressing is used. In a networked environment, such as a company, typically there are many computers connected together using a router or a switch.

  • Page 4: Wide Area Network

    A wide area network (WAN) connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several branch offices in Nebraska and Arkansas over a WAN. The largest WAN in existence is the Internet.

  • Page 5: Accessing The Wide Area Network (Wan)

    80 is used for HTTP traffic. When you type an address into the address bar of a web browser, your computer goes to find an IP Address for the url you are requesting (http://www.telex.com). To obtain this address, the computer contacts a DNS server (Domain Name Server).
  • Page 6 Basic Network Configuration LAN computer wants to access a web page. The NAT device now uses port 1032 for this connection where it used port 1031 in Table 1. Packet Translation TABLE 2. Packet before Translation Source Port IP Address Number 10.2.100.1 1031...
  • Page 7 Basic Network Configuration IP ADDRESSES If you do not know your IP Address, you can open a DOS screen in a Windows screen. To find your IP Address using ipconfig, do the following: From the Start Menu, open a Command Prompt screen. At the prompt, type ipconfig, then press Enter.

  • Page 8: Possible Pitfall With Routers, Gateways, And Switches

    Basic Network Configuration Ping a Computer Pinging a computer on the network makes sure it is able to be “seen” and receive messages on the network. NOTE: You can also ping your RVON-8 card to verify that it is responding over the network by putting the cards IP Address in place of the computer IP Address.

  • Page 9: Rvon Configuration

    Network Interface Device. See Table X for the ports that need to be opened for the RVON cards to operate properly. Ports necessary for RVON card functionality. TABLE 4. Port Port Description 2076 UDP Call Control Signalling 2077 UDP Audio Packets UDP Telex Proprietary 2079 Signalling 2080 TCP Telex Keypanel Protocol 2081 UDP Pass Through Serial 2082 TCP Firmware Download...

  • Page 10: Network Terminology

    IP Addresses be sure to use the same first 3 “octets” of the IP Address (for example, 192.168.0.X). Domain Name Server (DNS) A DNS Server is an Internet service that translates domain names (for example, in the URL http:// www.telex.com, the domain name is the telex.com) into IP Addresses. The Internet is based on IP Addresses...
  • Page 11 Network Terminology which are numeric and since domain names are alphabetic, they are easier to remember. Every time a domain name is used it must go through the DNS server to be translated into an IP Address. Gateway A gateway is a node on a network that serves as an entrance to another network. The gateway routes traffic from a computer to an outside network that is serving the web pages.
  • Page 12 A wide area network connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several of its branch offices in Nebraska and Arkansas over the wide area network. The largest WAN is the Internet.

  • Page 13: Serial Port Programming

    RVON Serial And Telnet Commands RVON card programming can be done via direct serial or telnet connection. There are several physical connections to an RVON board. • Direct serial through custom debug cable (J20 6-pin botton front) • Backcard DB-9 J2 - The backcardDB-9 must be disabled/enabled via a DIP Switch because it can also be used for serial port pass-through.
  • Page 14 Serial Port Programming RVON Supplemental Coding Table TABLE 5. Coding Codec 729AB 729AB 729AB 729AB 729AB 729AB 729AB Codec Specifications TABLE 6. 0,3,6,9 G.711 1,4,7,10 G.711 2,5,8,11 G.711 12,16 G.729 13,17 G.729 14,18 G.729 15,19 G.729 20,22 G.723 5.3k 24,26 G.723 6.3k 21,23...
  • Page 15 ***************************************************** RVON−8 Revision 1.00.00 (C) Copyright 2003 Telex, Inc. All Rights Reserved. Flash File System initialized. DIP Switch settings:...X Configuration via AZedit disabled (via DIP Switch 1 ON) Back Card UART enabled for pass−through serial (via DIP Switch 6 OFF)
  • Page 16 Serial Port Programming −> Bringing DSP subsystem out of reset... DSP Daughtercard type is set to NONE − No DSP Daughtercard Found 0000002223 − ROOT: FPGA Version = ff24 0x97e796f0 (tNetTask): Link is up on EMAC A: 100 MBps and HALF duplex. About to create Idle Task About to create Measurement Task Idle Measurement Tasks created...
  • Page 17 Set the destination IP Address for this particular X.X.X.X RVON_Channel (same as tcid). dest_type X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/ Set the profile to use which includes the compression codec see below (0-27). Force the channel to disconnect the port.
  • Page 18 RVON-8 Command Table TABLE 7. Command Variable 1 set serial baud activate show rvon show channel [chan] show emac Variable 2 Set the baud rate to use: 50 through 115000. Must do an activate command to cause changes to take effect. Display current settings Display current settings Display current settings...
  • Page 19 Set the destination IP Address for this particular X.X.X.X RVON channel. dest_type X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/ Set the destination channel - the port at the far end of the connection (0-7). Set the profile to use, which includes the compression codec see below (0-27).

  • Page 21: Rvon-I/O Command Table

    Set the destination IP Address for this X.X.X.X particular RVON channel. X = 0 (rvon-8), 1 (rvon-1, 2 (rvon-I/O Set the destination channel - the port on the far end (0-7). Set the profile to use which includes the compression codec (see page X) (0-27).
  • Page 22 RVON-I/O Command Table TABLE 9. Command Parameter 1 set channel onhook [chan] set channel offhook [chan] set serial set serial mode set serial ip_addr set serial ip_addr_2 set serial baud set gpio set gpio mode set gpio ip_addr set gpio panel set panel set panel...
  • Page 23 Gateway IP Address for the RVON-8 card. Pass-thru serial port IP Address for the none RVON-8 Set the pass-thru serial port baud rate for the 9600 RVON-8 card telex RVON-8 user name for Telnet access RVON-8 password for Telnet access (8-40 password characters) adaptive VAD Threshold...
  • Page 24 RVON-1 password for Telnet access (8-40 password characters). adaptive VAD Threshold Value Description Destination IP Address for this particular X.X.X.X channel. Destination Type: X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/O). Destination Channel - what port of far-end (0-7). Profile to use (see coding table).
  • Page 25 RVON-I/O password for Telnet access (8-40 characters). VAD Threshold DESCRIPTION Destination IP Address for this particular channel. Destination type X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/O) Destination channel - the port on the far end (0-7) Profile to use (previous coding table).
  • Page 27 CHAPTER 3 Product Specific Descriptions...
  • Page 28 J21 must be jumped from pins 1 to 2 to select UART B for RS485 RVON-1 keypanel operation. J2 Connector The RVON-1 card is designed to be used with either a keypanel or an RVON-I/O card. The J2 connector mounts the RVON- 1 card onto a keypanel.
  • Page 29 To Display the settings for the RVON-1 Card, do the following: Open a command prompt. At the prompt, type Telnet <IP ADDRESS> (The IP Address is the IP Address assigned to the RVON-1 card). Press Enter. The RVON logon screen appears.
  • Page 30 At the MXP prompt, type the show command you want to see (for example, “show rvon”). Press Enter. The values for the RVON-1 card appear. To edit the RVON-1 configuration, do the following: Repeat steps 1 through 9 from above. At the MXP prompt, type either set RVON or set EMAC (see screen descriptions below).
  • Page 31 Allows you to edit the serial IP Address Allows you to set the baud rate (50-38400) Allows you to set the username for the RVON-1 card. By default the user name is “telex” Allows you to set the password for the RVON-1 card.
  • Page 32 RVON-1 will talk with Allows you to edit the CODEC to be used for transferring the data between the two devices Allows you to edit the input gain for the RVON-1 card Allows you to edit the output gain for the RVON-1 card.

  • Page 33: Rvon-I/O Quick Start

    At the prompt, type telnet 192.168.0.1 (default RVON-I/O IP Address). The RVON login screen appears. In the logon field, type telex (default user logon for the unit). Press Enter. In the password field, enter password (default password for the unit).

  • Page 34: Setting Channel Information Of An Rvon-I/O For A Remote Keypanel

    You have entered MXP programming shell. At the MXP prompt, type show rvon and press Enter. A list of settings will appear which contains the RVON-1 version. NOTE: If the RVON-1 is not at Version 1.1.0 or higher, contact your RTS service engineer.
  • Page 35 Press Enter. The Set Channel menu list appears. At the prompt, type set channel 0 dest_ip 192.168.0.10 (the address of the RVON-1 you want to connect with). Press Enter. At the prompt, type set channel 0 dest_type 1 (this tells the RVON-I/O it is connecting to an RVON-1).
