RVON-8
RTS Voice Over Network
9350-7756-000 Rev M
June 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVON-8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for RTS RVON-8

Summary of Contents for RTS RVON-8

  • Page 1 RVON-8 RTS Voice Over Network 9350-7756-000 Rev M June 2006...
  • Page 2 OTICE The product information and design disclosed herein were originated by and are the property of Telex Communications, Inc. Telex reserves all patent, proprietary design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed therein, except to the extent rights are expressly granted to others.

  • Page 3: Table Of Contents

    Features ... 2 Specifications ... 2 Chapter 2 Installation ... 3 Installation of the RVON-8 Card into the ADAM System ... 3 Color Key Code ... 3 Addresses and the RVON-8 Card ... 4 Switches and Connections 4 Configuring the RVON-8 Card with AZedit ... 5 RVON-8 Connection Status Screen ...

  • Page 5: Chapter 1 Introduction

    CHAPTER 1 Introduction Description of the RVON-8 Voice Over Network Card Installed directly into the ADAM Intercom frame, the RVON-8 provides voice over IP (Internet Protocol) communications for ® the RTS ADAM intercom family. In general, voice over IP means sending voice information in digital form using discrete packets rather than the traditional telephone network.

  • Page 6: Features

    Power...12.5w / 2.5 A at 5V Physical ...5.687” W x 11.024” L The RVON-8 card is hot-swappable and installs in any available slot in an ADAM Intercom System. It provides a single RJ-45 Ethernet connection for use with a 10 BASE-T or 100 BASE-TX network.

  • Page 7: Chapter 2 Installation

    When inserting the RVON-8 card into the ADAM system, the following considerations need to be made: • Gently insert the RVON-8 card into the correct slot. If the card is forced or twisted while inserting, a pin on the backplane could short or break causing the card to become inoperable.

  • Page 8: Addresses And The Rvon-8 Card

    Addresses and the RVON-8 Card Because the RVON-8 has an Ethernet interface, it is required to have a MAC (Media Access Control) address. This is a low level address that contains 48 bits. Do not confuse this address with an IP (Internet Protocol) Address. In order to be IP com- pliant, all cards must have a unique MAC ID when shipped from the manufacturer.

  • Page 9: Configuring The Rvon-8 Card With Azedit

    Configuring the RVON-8 Card with AZedit Once the RVON-8 card is inserted into the Intercom, AZedit will automatically recognize the card. NOTE: Requires intercom firmware and AZedit software that supports RVON cards.
  • Page 10 The RVON-8 Configuration screen appears. From the RVON-8 drop down list, select the slot in which the RVON-8 card resides, if it is not already selected. In the IP Address field, enter the IP Address you have assign to the RVON-8 card.
  • Page 11 Configuring the RVON-8 Card with AZedit In the RVON-8 Channel drop down list, select the channel you want to use to communicate to another device across the network. In the Device IP Addr: field, enter the IP Address of the device to which you want to connect.

  • Page 12: Rvon-8 Connection Status Screen

    NOTE: To view the RVON-8 Connection Status screens make sure both AZedit and the RVON-8 card are on the same Ethernet network. The reason this is important is because the statistics are updated once per second. At this rate of dynamic update, a serial port could not pass this much data effectively.
  • Page 13 From the Channel drop down list, select the channel for which you want to view the status. Displays the type of device the RVON-8 card is connected to on the other end of the channel. Displays the IP Address of the device connected at the other end of the channel.
  • Page 14 The state of the connection. There are two connection states: Connected or Idle. Displays which end of the connection originated or terminated the call. Local: RVON-8 card Remote: device at the other end of the connection. Displays why the connection was terminated, for example, congestion, network error, local release, remote release.
  • Page 15 RVON-8 Connection Status Screen SCREEN ITEM Playout Buffer Displays how much audio can be received from the network before packets are lost. This is four times Size bigger than configured packet size. This is a static system setting. Nominal Displays how much audio is collected before playout begins. Playout begins at half the Playout Buffer Playout Delay Size, which is two times the configured packet size.
  • Page 16 Displays the number of DTMF (dual tone multiple frequency) relay packets transmitted and received. DTMF Relay Packets DTMF relay packets are a bandwidth and quality saving feature within the (Tx/Rx) RVON-8 card. Silence Detections Displays the number of times a silence detection packet has been sent or received. VAD (voice activity Packets (Tx/Rx) detection) must be enabled.
  • Page 17 RVON-8 Connection Status Screen SCREEN ITEM Invalid Headers Displays how many IP packets could not be parsed. Invalid MAC Address Displays how many invalid MAC addresses tried to connect. Invalid SSRC Displays the number of packets with an invalid SSRC.

  • Page 18: Download Rvon-8 Firmware Through Azedit

    Master Controller. For this reason, verify the PC running AZedit is on the same network as the RVON-8 card. If it is not, AZedit will not be able to find the RVON-8 card. To test the connection, ping the RVON-card from a command line.
  • Page 19 Verify the version upgrade in the I/O Card Version Information Window is correct. WARNING!: Do NOT power down the frame or pull the RVON-8 card(s) from the frame until you have verified the new version information from AZedit. If the card loses power while reprogramming the on-board flash memory, the card may become unbootable, and my need to have its flash chips replaced.

  • Page 20: Rvon-8 Backcard

    *On jumpers J10, J11, and J12: • if all 1 & 2 pins are covered, then RS- 485 is active • if all 2 & 3 pins are covered, then RS- 232 is active. Pinout positions on the RVON-8 backcard DB9 (J2) Connector.
  • Page 21 Crosspoint Closed Channel 5 Crosspoint Closed Channel 6 Crosspoint Closed Channel 7 Crosspoint Closed Channel 8 Not Defined Pass-Through Serial RX Not Defined Not Defined Ethernet Full Duplex Ethernet - 100 Mbps Ethernet Link Good Control Bus RX RVON-8 LINK...
  • Page 22 Installation...
  • Page 23 REAR VIEW link MC-XCP DE-9-P DE-9-P MALE, 9 PINS MALE, 9 PINS " D " SUB " D " SUB CONNECT TO MATRIX CONNECT TO RVON-8 XCP-ADAM-MC J2 RS485 + RS485 + RS485 - RS485 - GROUND GROUND DE-9-P DE-9-P...

  • Page 25: Basic Network Configuration

    Appendix A Basic Network Configuration Basic Network Configuration This section covers basic network configuration set-up and testing. Also covered are basic concepts and operations, including the difference between LAN and WAN networks and how IP Addressing is used. In a networked environment, such as a company, typically there are many computers connected together using a router or a switch.

  • Page 26: Wide Area Network

    A wide area network (WAN) connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several branch offices in Nebraska and Arkansas over a WAN. The largest WAN in existence is the Internet.

  • Page 27: Accessing The Wide Area Network (Wan)

    80 is used for HTTP traffic. When you type an address into the address bar of a web browser, your computer goes to find an IP Address for the url you are requesting (http://www.telex.com). To obtain this address, the computer contacts a DNS server (Domain Name Server).
  • Page 28 Basic Network Configuration Packet Translation TABLE 2. Packet before Translation Source Port IP Address Number 10.2.100.1 1031 Internet From 192.156.136.22 Internet Amazingly, all the address translation that occurs takes place automatically in order to make web browsing and other functions easier.

  • Page 29: Ip Addresses

    Basic Network Configuration IP ADDRESSES If you do not know your IP Address, you can open a DOS screen in a Windows screen. To find your IP Address using ipconfig, do the following: From the Start Menu, open a Command Prompt screen. At the prompt, type ipconfig, then press Enter.

  • Page 30: Ping A Computer

    Pinging a computer on the network makes sure it is able to be “seen” and receive messages on the network. NOTE: You can also ping your RVON-8 card to verify that it is responding over the network by putting the cards IP Address in place of the computer IP Address.

  • Page 31: Rvon Configuration

    Ports necessary for RVON card functionality. TABLE 4. Port Port Description 2076 UDP Call Control Signalling 2077 UDP Audio Packets 2079 UDP Telex Proprietary Signalling 2080 TCP Telex Keypanel Protocol 2081 UDP Pass Through Serial 2082 TCP Firmware Download 2100 Remote Administration...

  • Page 32: Network Terminology

    A DNS Server is an Internet service that translates domain names (for example, in the URL http:// www.telex.com, the domain name is the telex.com) into IP Addresses. The Internet is based on IP Addresses which are numeric and since domain names are alphabetic, they are easier to remember. Every time a domain name is used it must go through the DNS server to be translated into an IP Address.
  • Page 33 Network Terminology A gateway is a node on a network that serves as an entrance to another network. The gateway routes traffic from a computer to an outside network that is serving the web pages. For example, the gateway for a home computer is the ISP provider that connects the user to the Internet.
  • Page 34 A wide area network connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several of its branch offices in Nebraska and Arkansas over the wide area network. The largest WAN is the Internet.

  • Page 35: Rvon-8 Card Serial Port Programming

    DB-9 can be used for a debug terminal when DIP switch 6 is switched to the ON position. • Backcard RJ-45 J1 (Telnet Only) Setup Serial Port Telnet RVON-8 Card Serial Port Programming 38.400 baud, No-flow control IP Address, port 23 CHAPTER 5...
  • Page 36 RVON-8 Card Serial Port Programming ***************************************************** RVON−8 Revision 1.00.00 (C) Copyright 2003 Telex, Inc. All Rights Reserved. Flash File System initialized. DIP Switch settings:...X Configuration via AZedit disabled (via DIP Switch 1 ON) Back Card UART enabled for pass−through serial (via DIP Switch 6 OFF)
  • Page 37 RVON Serial and Telnet Commands 0000002744 − NMM: 5, states: oper=NORMAL, admin=NORMAL, call=IDLE 0000002745 − NMM: 6, states: oper=NORMAL, admin=NORMAL, call=IDLE 0000002746 − NMM: 7, states: oper=NORMAL, admin=NORMAL, call=IDLE 0000002746 − RVON: port 0, now idle 0000002746 − RVON: port 1, now idle 0000002746 −...
  • Page 38 RVON-8 Card Serial Port Programming There are many different serial port commands supported from here but it is NOT recommended that any be used EXCEPT: dbgcmd Type “dbgcmd”, then press Return. This places the serial port into the MXP> (MXP command mode) The MXP Command Mode is the only mode that will be used.

  • Page 39: Rvon-8 Command Table

    Set the IP Address for the RVON-8 Card. X.X.X.X Set network mask for the RVON-8 Card. X.X.X.X Set the gateway IP Address for the RVON-8 card. Set the RVON-8 user name for telnet access. abcdefg Default “telex” Set the RVON-8 password for telnet access (8-40 characters).

  • Page 40: Rvon-8 Default Setup

    RVON-8 Card Serial Port Programming Codec Specifications. Table 6. 0,3,6,9 G.711 1,4,7,10 G.711 2,5,8,11 G.711 12,16 G.729 13,17 G.729 14,18 G.729 15,19 G.729 20,22 G.723 5.3k 24,26 G.723 6.3k 21,23 G.723 5.3k 25,27 G.723 6.3k NOTE : A channel consists of a transmitting and a receiving side, so the bandwidth is double for a bi-directional audio stream.
  • Page 41 IP Address for the RVON-8 Card 255.255.255.0 Network Mask for the RVON08 card none Gateway IP Address for the RVON-8 Card none Pass-thru serial port IP Address for the RVON-8 Card 9600 Set the pass-thru serial port baud rate for the RVON-8 Card telex...
  • Page 42 The Environment name is listed because this is the label used by the software IMPORTANT!: If the user is attempting to do a “setenv” to change a parameter from the RVON-8 boot code, the Environment Name must be used and NOT the “set rvon variable” name.
  • Page 43 RVON-8 Default Setup...
