RTS RVON-1 Resource Manual

Digital matrix intercom systems
Hide thumbs Also See for RVON-1:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
RVON Resource Guide
RVON-8
RVON-1
RVON-I/O

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RVON-1 and is the answer not in the manual?

Questions and answers

Related Manuals for RTS RVON-1

Summary of Contents for RTS RVON-1

  • Page 1 RVON Resource Guide RVON-8 RVON-1 RVON-I/O...

  • Page 3: Basic Network Configuration

    CHAPTER 1 Basic Network Configuration Basic Network Configuration This section covers basic network configuration set-up and testing. Also covered are basic concepts and operations, including the difference between LAN and WAN networks and how IP Addressing is used. In a networked environment, such as a company, typically there are many computers connected together using a router or a switch.
  • Page 4 Basic Network Configuration “node”), has its own processing unit and executes its own programs; however, it can also access data and devices anywhere on the LAN. This means many users can access and share the same information and devices. A good example of a LAN device is a network printer.

  • Page 5: Accessing The Wide Area Network (Wan)

    A wide area network (WAN) connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several branch offices in Nebraska and Arkansas over a WAN. The largest WAN in existence is the Internet.

  • Page 6: Network Address Translation (Nat)

    For example, port 80 is used for HTTP traffic. When you type an address into the address bar of a web browser, your computer goes to find an IP Address for the url you are requesting (http://www.telex.com). To obtain this address, the computer contacts a DNS server (Domain Name Server). Once the IP Address is found, it tries to connect to the http port of the network device (port 80).
  • Page 7 Basic Network Configuration Packet Translation TABLE 2. Packet before Translation Source Port IP Address Number 10.2.100.1 1031 Internet From 192.156.136.22 Internet Amazingly, all the address translation that occurs takes place automatically in order to make web browsing and other functions easier. This is also a way for large web hosting services to speed up the network by having different devices perform different functions.
  • Page 8 Basic Network Configuration Well-Known TCP Port Numbers TABLE 3. Port Number Description TCP Port Service Multiplexer (TCPMUX) Remote Job Entry (RJE) ECHO Message Send Protocol (MSP) FTP-Data FTP- Control Telnet Simple Mail Transfer Protocol (SMTP) MSG ICP Time Host Name Server (Nameserv) Whols Login Host Protocol (Login) Domain Name Server (DNS)
  • Page 9 Basic Network Configuration IP ADDRESSES If you do not know your IP Address, you can open a DOS screen in a Windows up the ipconfig screen. To find your IP Address using ipconfig, do the following: From the Start Menu, open a Command Prompt screen. At the prompt, type ipconfig, then press Enter.
  • Page 10 Basic Network Configuration Ping a Computer Pinging a computer on the network makes sure it is able to be “seen” and receive messages on the network. NOTE: You can also ping your RVON-8 card to verify that it is responding over the network by putting the cards IP Address in place of the computer IP Address.

  • Page 11: Possible Pitfall With Routers, Gateways, And Switches

    Basic Network Configuration NOTE: If the computer you are pinging is not responding to the ping, you will receive a time-out message in the command prompt screen. POSSIBLE PITFALL WITH ROUTERS, GATEWAYS, AND SWITCHES Anytime computers communicate through routers, gateways, and switches, they may be allowed or denied the connection.

  • Page 12: Rvon Configuration

    Ports necessary for RVON card functionality. TABLE 4. Port Port Description 2076 UDP Call Control Signalling 2077 UDP Audio Packets 2079 UDP Telex Proprietary Signalling 2080 TCP Telex Keypanel Protocol 2081 UDP Pass Through Serial 2082 TCP Firmware Download 2100 Remote Administration...

  • Page 13: Network Terminology

    Network Terminology Figure X is an example of a router configuration screen. Not all routers are configured the same way and may not look exactly like this screen. NOTE: Linksys™ supports up to 253 nodes on a router. This is why it is called a Router/Switch because there are WAN functions like a router as well as having a 4-port LAN switch.
  • Page 14 A DNS Server is an Internet service that translates domain names (for example, in the URL http://www.telex.com, the domain name is the telex.com) into IP Addresses. The Internet is based on IP Addresses which are numeric and since domain names are alphabetic, they are easier to remember.
  • Page 15 Network Terminology The four numbers in and IP Address are used in different was to identify a particular network and host on that network. There are three classes of Internet Addresses. CLASS A - supports 16 million hosts on each of 127 networks. CLASS B - supports 65,000 hosts on each of 16,000 networks.
  • Page 16 A wide area network connects two or more LANs and can span a relatively large geographical area. For example, Telex Headquarters in Burnsville, MN is connected to several of its branch offices in Nebraska and Arkansas over the wide area network. The largest WAN is...

  • Page 17: Serial Port Programming

    RVON Serial and Telnet Commands RVON card programming can be done via direct serial or telnet connection. There are several physical connections to an RVON board: • Direct serial through custom debug cable (J20 6-pin bottom front) The customer debug cable always functions as the general-purpose debug tool. Backcard DB-9 J2 •...
  • Page 18 Serial Port Programming RVON-I/O supplemental Coding Table TABLE 1. Codec Coding Codec Rate 711u 711u 711u 711u 711u 711u 711A 711A 711A 711A 711A 711A 729AB 729AB 729AB 729AB 729AB 729AB 729AB 729AB 5.3k 5.3k 5.3k 5.3k 6.3k 6.3k 6.3k 6.3k Size...
  • Page 19 Codec Specifications. Table 1. 0,3,6,9 G.711 1,4,7,10 G.711 2,5,8,11 G.711 12,16 G.729 13,17 G.729 14,18 G.729 15,19 G.729 20,22 G.723 5.3k 24,26 G.723 6.3k 21,23 G.723 5.3k 25,27 G.723 6.3k NOTE : A channel consists of a transmitting and a receiving side, so the bandwidth is double for a bi-directional audio stream. NOTE : Bandwidth values are approximate maximums, actual bandwidth could be considerably lower with VAD enabled.
  • Page 20 Serial Port Programming...
  • Page 21 ***************************************************** RVON−8 Revision 1.00.00 (C) Copyright 2003 Telex, Inc. All Rights Reserved. Flash File System initialized. DIP Switch settings:...X Configuration via AZedit disabled (via DIP Switch 1 ON) Back Card UART enabled for pass−through serial (via DIP Switch 6 OFF)
  • Page 22 About to create Idle Task About to create Measurement Task Idle Measurement Tasks created 0000002536 − SERV: initializing connection server 0000002536 − DNLD: initializing download server 0000002535 − NMM: ATPM Update Database Granted 0000002735 − NMM: ATPM Configured for RVON operation 0000002735 −...
  • Page 23 Set the destination IP Address for this particular X.X.X.X RVON_Channel (same as tcid). dest_type X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/O). Set the profile to use which includes the compression Force the channel to disconnect the port. Force the channel to connect the port.
  • Page 24 RVON-8 Command Table TABLE 5. Command Variable 1 set emac 100 full set serial ip_addr set serial baud activate show rvon show channel [chan] show emac Variable 2 Description Configures the Ethernet interface for 100 Mbps full Set the destination IP Address for this serial pass- X.X.X.X Set the baud rate to use: 50 through 115000.
  • Page 25 Help screen which lists all “set rvon” commands. Set the IP Address for the RVON-1 Card. Set network mask for the RVON-1 Card. Set the gateway IP Address for the RVON-1 card. Set the RVON-1 user name for telnet access. Default “telex”...

  • Page 27: Rvon-I/O Command Table

    Set the destination IP Address for this particular X.X.X.X RVON channel. X = 0 (rvon-8), 1 (rvon-1, 2 (rvon-I/O Set the destination channel - the port on the far Set the profile to use which includes the compression codec (see page X) (0-27).
  • Page 28 RVON-I/O Command Table TABLE 7. Command Parameter 1 set channel input_gain [chan] set channel output_gain [chan] set channel onhook [chan] set channel offhook [chan] set serial set serial mode set serial ip_addr set serial ip_addr_2 set serial baud set gpio set gpio mode set gpio...
  • Page 29 RVON-I/O Command Table RVON-I/O Command Table TABLE 7. Command Parameter 1 set panel [pnl] poll_id set panel [pnl] baud Parameter 2 Description Make sure the panel poll_id corresponds to the source of the audio it is connected to. 0= do not respond to polls Set the baud rate for the panel.
  • Page 31 VAD Threshold Value Description Destination IP Address for this particular X.X.X.X Destination Type - Y = 0 (rvon-8), 1 (rvon-1), Destination Channel - What port of far-end (0-7). Profile to use (see coding table) characters) RVON_CH 2 (rvon-I/O).
  • Page 32 VAD Threshold Value Destination IP Address for this particular X.X.X.X channel. Destination Type: X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/O). Destination Channel - what port of far-end (0-7). Profile to use (see coding table). Description Description...
  • Page 33 RVON-I/O password for Telnet access (8-40 characters). VAD Threshold DESCRIPTION Destination IP Address for this particular channel. Destination type X = 0 (rvon-8), 1 (rvon-1), 2 (rvon-I/O) Destination channel - the port on the far end (0-7) Profile to use (previous coding table).
  • Page 35 CHAPTER 8 Product Specific Descriptions...

  • Page 36: Rvon-1 Jumpers And Connections

    J21 must be jumped from pins 1 to 2 to select UART B for RS485 RVON-1 keypanel operation. J2 Connector The RVON-1 card is designed to be used with either a keypanel or an RVON-I/O card. The J2 connector mounts the RVON-1 card onto a keypanel.
  • Page 37 How to Configure the RVON-1 using Telnet Without access to the physical KP-32 with RVON-1 installed on it, you can still configure the card through the use of Telnet. The following instructions will show you how to access the Telnet screen and show you some of the information you can see and edit.
  • Page 38 Product Specific Descriptions Press Enter. The RVON logon screen appears. In the logon field, type the RVON logon (default = telex). Press Enter. In the password field, type the RVON password (default = password). Press Enter. A prompt appears. Type dbgcmd to access the debug command screens.
  • Page 39 At the MXP prompt, type the show command you want to see (for example, “show rvon”). Press Enter. The values for the RVON-1 card appear. To edit the RVON-1 configuration, do the following: Repeat steps 1 through 9 from above. At the MXP prompt, type either set RVON or set EMAC (see screen descriptions below).
  • Page 40 Allows you to edit the serial IP Address Allows you to set the baud rate (50-38400) Allows you to set the username for the RVON-1 card. By default the user name is “telex” Allows you to set the password for the RVON-1 card. By default, the password is “password”...
  • Page 41 Allows you to edit the CODEC to be used for transferring the data between the two devices Allows you to edit the input gain for the RVON-1 card Allows you to edit the output gain for the RVON-1 card. onhook = hang up If the channel was already connected, going offhook will have no effect (it is already offhook if connected).
  • Page 42 Product Specific Descriptions NOTE: This Telnet screen is almost duplicate to the left side of the Configuration screen for the RVON in AZedit. One item to note is the ONHOOK and OFFHOOK...this is a setting regarding the connection of the card to the Matrix.
  • Page 43 How to Configure the RVON-1 using Telnet...
  • Page 44 Product Specific Descriptions...

  • Page 45: Rvon-I/O Quick Start

    At the prompt, type telnet 192.168.0.1 (default RVON-I/O IP Address). The RVON login screen appears. In the logon field, type telex (default user logon for the unit). Press Enter. In the password field, enter password (default password for the unit).
  • Page 46 RVON-I/O Quick Start Press Enter. At the prompt, type dbgcmd and press Enter to access the MXP programming shell. At the prompt, type set channel. Press Enter. The Set Channel menu list appears. At the prompt, type set channel 0 dest_ip 192.168.0.10 (the address of the RVON-8 you want to connect with).
  • Page 47 Setting Channel Information of an RVON-I/O for a Remote Keypanel RVON-I/O supplemental Coding Table Figure 8. Codec Coding Codec Rate 711A 729AB 729AB 729AB 729AB 729AB 729AB 729AB 729AB 5.3k 5.3k 5.3k 5.3k 6.3k 6.3k 6.3k 6.3k Size...
  • Page 48 12000 Portland Avenue South • Burnsville, MN 55337 • U.S.A...
