DEMO MANUAL DC1307A
PARTS LIST
ITEM QUANTITY REFERENCE
Required Circuit Components
1 1 C5
2 1 C1
3 1 C2
4 2 C3, C4
5 1 R1
6 1 R2
7 1 R3
8 1 R4
9 1 U1
Additional Demo Board Circuit Components
1 1 C
IN
2 1 C6
3 0 C7 (Optional)
4 0 C8 (Optional)
5 0 C9 (Optional)
6 0 L2 (Optional)
7 0 FB1 (Optional)
Hardware, for Demo Board Only
1 6 E1-E6
2 1 JP1
3 1 JP1
4 4 E7-E10
5 4 (Stand-Off)
4
DESCRIPTION
Capacitor, COG, 1500pF , 100V, 5%, 0603
Capacitor, X5R, 2.2μF , 100V, 10%, 1210
Capacitor, X5R, 22μF , 16V, 20%, 1210
Capacitor, TQC, 68μF , 16V
Resistor, Chip, 56.2k, 1/16W, 1%, 0603
Resistor., Chip, 845k, 1/16W, 1%, 0603
Resistor, Chip, 49.9k, 1/16W, 1%, 0603
Resistor, Chip, 82.5k, 1/16W, 5%, 0603
I.C., LTM8027EV#PBF , LGA,113-Pin
Capacitor, Aluminum, 22μF , 63V
Capacitor, X7R, 0.1μF , 50V, 10%, 0603
Capacitor, Aluminum, 63V 22μF
Capacitor, 1210
Capacitor, 1206
Inductor, 22μH
Resistor, Chip, 1206
Testpoint, Turrent, .095"
2mm Single Row Header, 3-Pin
Shunt
Banana Jack
Stand-Off, Nylon 0.50" Tall
MANUFACTURER'S PART NUMBER
AVX, 06031A152JAT2A
TDK, C3225X5R2A225K
AVX, 1210YC226MAT2A
SANYO, 16TQC68M
Vishay, CRCW060356K2FKEA
Vishay, CRCW0603845KFKEA
Vishay, CRCW060349K9FKEA
Vishay, CRCW060382K5FKEA
Linear Technology, LTM8027EV#PBF
Sun Electronic, 63CE22BS
Murata, GRM188R71H104KA93D
Vishay, IHLP-4040DZER22R0M11
MILL-MAX, 2501-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Samtec, 2SN-BK-G
Keystone, 575-4
Keystone, 8833(Snap On)
