Archgard 72-DVTE30P-2-ERG Installation, Operation And Maintenance Manual

Direct vent fireplace heater
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
WARNING: If the information in this manual is
not followed exactly, fire or explosion may result
causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do not use
any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
For use with natural gas or propane
(Conversion kit required to change fuel)
INSTALLER:
LEAVE THIS MANUAL WITH THE
APPLIANCE.
CONSUMER:
RETAIN THIS MANUAL FOR FUTURE
REFERENCE.
Archgard Fireplace Products
7116 Beatty Dr
Mission, BC V2V 6B4
Canada
INSTALLATION, OPERATION,
AND MAINTENANCE MANUAL
Direct Vent Fireplace Heater
Models:
Serial Numbers 700714 and higher
This appliance may be installed in an aftermarket
permanently located, manufactured home (USA only) or
mobile home where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other
gases, unless a certified kit is used.
Gas Fireplace Efficiency Rating
68.45%
Based on CSA P.4.1-15
Optima 72
72-DVTE30P-2
72-DVTE30N-2
72-DVTE30P-2-ERG
72-DVTE30N-2-ERG
200-1917-13
September 18, 2023
