Archgard Optima 72-DVT30N User's Installation, Operation And Maintenance Manual

Gas fired vented room heater (direct vent)
Hide thumbs
Table of Contents

Advertisement

Quick Links

WARNING: If the information in this manual is
not followed exactly, fire or explosion may result
causing property damage, personal injury or loss
of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS:
∗
Do not try to light any appliance.
Do not touch any electrical switch; do not use
∗
any phone in your building.
Immediately call your gas supplier from a
∗
neighbor's phone. Follow the gas supplier's
instructions.
∗
If you cannot reach your gas supplier, call the
fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
Installer: Please leave this manual with the appliance owner for future reference
FOR USE WITH NATURAL GAS AND PROPANE*
U
O
M
7116 Beatty Dr
Mission, BC V2V 6B4
Canada
Optima 72
72-DVT30N
Gas Fired Vented Room
Heater (Direct Vent)
For serial #42794 and up
I
SERS'
NSTALLATION
PERATION AND
AINTENANCE
This appliance may be installed in an
aftermarket permanently located,
manufactured home (USA only) or mobile
home, where not prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
*Conversion kit required for Propane use
M
ANUAL
200-1907
June 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Optima 72-DVT30N and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Archgard Optima 72-DVT30N

Summary of Contents for Archgard Optima 72-DVT30N

  • Page 1 Optima 72 72-DVT30N Gas Fired Vented Room Heater (Direct Vent) For serial #42794 and up FOR USE WITH NATURAL GAS AND PROPANE* WARNING: If the information in this manual is not followed exactly, fire or explosion may result SERS’ NSTALLATION causing property damage, personal injury or loss of life.
  • Page 2 Requirements for the state of Massachusetts 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: 1.
  • Page 3 INTRODUCTION Congratulations on choosing an Archgard fireplace! The Optima 72-DVT30N is one of the most advanced direct vent fireplace heaters available. It is solidly designed using the latest technology and manufactured to the highest quality. It is our aim to provide you with an appliance for many trouble-free years of reliable service.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Caution and Safety Instructions Appliance Certification, Installation Codes and Specifications, High Altitude Installation Gas Connections Appliance Dimensions and Clearance to Combustibles Mantle Clearances Framing Dimensions, Termination Locating Gas Fireplace and Vent Termination Locations Allowable Termination Locations Approved Vent Components and Venting Connection Venting Electrical Connections (Fan System) and Fan Wiring Diagram Brick Placement...

  • Page 5: Caution And Safety Instructions

    Optima 72 CAUTION FOR YOUR SAFETY - Do not install or operate your Archgard Optima 72 Direct Vent Gas Fireplace without reading and understanding this manual. Any installation or operational deviation from this instruction manual voids the Archgard Industries Warranty and may prove hazardous.

  • Page 6: Appliance Certification, Installation Codes And Specifications, High Altitude Installation

    - ANSI Z21.88b-2003 / CSA 2.33b-2003, Vented Gas Fireplace Heaters, - CAN/CGA-2.17-M91, Gas-Fired Appliances for Use at High Altitudes Please contact Archgard Industries Ltd., if you have any questions regarding the certification of this appliance. INSTALLATION CODES This appliance must be installed by a qualified gas appliance installer. The installation must conform with the local codes or, in the absence of local codes, with the current National Fuel Gas Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code, CAN/CGA-B149.1, in...

  • Page 7: Gas Connections

    Optima 72 GAS CONNECTIONS Before connecting the appliance to the gas supply line, double check that the appliance you have purchased is designed for the gas type you are using. The gas type markings are located on the certification label and also on the appliance’s gas valve. Adequate clearance for proper installation and checking of the gas connections must be provided.

  • Page 8: Appliance Dimensions And Clearance To Combustibles

    Optima 72 APPLIANCE DIMENSIONS FRONT VIEW SIDE VIEW DIMENSIONS 31” (787 mm) 6” (152 mm) 3” (76 mm) 29-¾” (756 mm) 38” (965 mm) 38” (965 mm) 21-½” (545 mm) 39-¾” (1010 mm) 6-½” (164 mm) 16-¼” (412 mm) TOP VIEW CLEARANCES TO COMBUSTIBLES BACK 0”...

  • Page 9: Mantle Clearances

    Optima 72 MANTLE CLEARANCE NOTE: Low profile wooden crowns and moldings above the unit are not considered as mantles. I.E. 1” (25 mm) or less protrusions on the upper mantle facing are acceptable. Combustible mantle allowed in shaded area. Mantle extension may be increased 1” (25 mm) for each additional 1”...

  • Page 10: Framing Dimensions, Termination

    Optima 72 FRAMING DIMENSIONS Dimensions * 38” (965 mm) 16-¼” (412 mm) 38” (965 mm) This dimension allows the top of the fireplace to slide under. If more rigidity is required, a stud may be added to the back of the fireplace top nailing flange after the fireplace is installed.

  • Page 11: Locating Gas Fireplace And Vent Termination Locations

    4. Vent terminations located below 7ft (2.13 M) from grade level or anywhere that it can be a burn hazard to the public, such as patios and balconies, must be protected with an approved termination cage. If using Archgard Venting System, order Part # C-1.

  • Page 12: Allowable Termination Locations

    Optima 72 ALLOWABLE TERMINATION LOCATIONS...

  • Page 13: Approved Vent Components And Venting Connection

    The appliance will not function without being connected to a proper venting system. This appliance may only use direct vent system supplied by Archgard Industries or Simpson Dura- Vent direct vent systems with the appropriate adaptor dependent upon the venting guidelines within this manual.

  • Page 14: Venting

    Archgard System Simpson Dura-Vent In the Archgard system, the restrictors With Simpson Dura-Vent, locate are placed on the exhaust outlet on the restrictor in the exhaust the appliance.
  • Page 15 VENTING - VERTICAL TERMINATION CHART The appliance will not function without being connected to a proper venting system. This appliance may only use direct vent system approved by Archgard, or Simpson Dura-Vent direct vent systems with Archgard 999-DV-SDA adapter. VENTING CHART 7.93 M...
  • Page 16 The Optima 72 can be vented vertically using Simpson Dura-Vent Direct Vent System. To vent using Simpson Dura-Vent exclusively, you must use the Archgard 999-DV-SDA Adapter and connect the adapter to the top of flue outlet on the Optima 72 gas fireplace.
  • Page 17 Optima 72 VENTING - VERTICAL TERMINATION USING SIMPSON DURA-VENT PIPE ONLY Typical Vertical venting NOTE: configuration using Simpson Dura- Galvanized pipe is desirable above the roofline • Vent Direct Vent System due to its higher corrosion resistance. Continue to add pipe sections throughout the flashing until the height of the vent cap meets the mini- Vertical Termination Cap mum height requirements specified in Fig.
  • Page 18 Optima 72 VENTING - VERTICAL TERMINATION USING FLEX GAS LINER The Optima 72 can be used with Flexmaster Model GA 4” & 7” (101mm & 178mm) vent liners, and terminate through the roof using Simpson Dura-Vent by using an 999-DV-SDA (Adapter, Flex to Simpson Dura-Vent).
  • Page 19 Optima 72 VENTING - HORIZONTALLY USING FLEXIBLE DIRECT VENT SYSTEMS The Optima 72 can be vented Horizontally by using the Archgard Direct Vent System of flexible pipe. PART # DESCRIPTION 999-DV-TVK3 Flex Vent Kit with 36” (914 mm) vent length (includes 999-DV-HTC) 999-DV-TVK5 Flex Vent Kit with 60”...
  • Page 20 Optima 72 VENTING - HORIZONTALLY USING FLEXIBLE DIRECT VENT SYSTEMS INSTALLATION PROCEDURES - ARCHGARD DIRECT VENT (FLEX) SYSTEM 1. Place the Optima 72 in the framing. Locate the centerline of the termination and mark the wall. Cut an 11” x 10” (279mm x 254mm) hole in the wall. NOTE: a 2” (50mm) x 1-½” (13mm) around the 7”...
  • Page 21 NOTE: Apply high temperature sealant to the SDA-U adaptor and the flue connection on the Optima 72. Seal all pipe joints and follow all venting instructions within this manual. NOTE: Call your local Authorized Archgard Dealer to purchase Simpson Dura-Vent Direct Vent Kits and/ or venting components.
  • Page 22 2. Simpson Dura-Vent Venting System is designed with special twist-lock connec- tions to connect to the appliance. An Archgard adaptor (999-DV-SDA) is re- quired. The adaptor will allow Simpson Dura-Vent System to be used. 3. Apply a bead of sealant inside the outer section of the 999-DV-SDA adaptor.
  • Page 23 Optima 72 VENTING - HORIZONTALLY USING SIMPSON DURA-VENT DIRECT VENT SYSTEMS INSTALLATION PROCEDURES FOR SIMPSON DURA-VENT DIRECT VENT SYSTEM 5. Mark the wall with an 11” (279mm) x 10” (254mm) hole. See termination framing on page 22. The center of the hole should line up with the centerline of the horizontal pipe.

  • Page 24: Electrical Connections (Fan System) And Fan Wiring Diagram

    Optima 72 ELECTRICAL CONNECTIONS, FAN SYSTEM WARNING: Before starting, make certain the power supply is turned OFF. The Optima 72 comes complete with a temperature activated fan and rheostat installed and wired to an internal junction box. The heat sensor is factory set to close the circuit to the fan speed control at 110 F (43 C) and will turn off the fan when the temperature falls below 80...

  • Page 25: Brick Placement

    Optima 72 BRICK PLACEMENT The Archgard brick and reflective glass panels offer a variety of looks to customize your fire- place and are purchased seperatly. Care must be given when first installing the bricks, and if removed for servicing, as they can be damaged or broken if not handled properly.
  • Page 26 Optima 72 Right Brick Panel Placement as Shown NOTE: Installing the panels in any other position other than shown will result in flame im- pingement causing sooting of the logs, brick liner and ceramic glass viewing area.
  • Page 27 Optima 72 Left Brick Panel Placement as Shown NOTE: Installing the panels in any other position other than shown will result in flame im- pingement causing sooting of the logs, brick liner and ceramic glass viewing area.

  • Page 28: Log Placement (Fiber Log Set)

    Optima 72 LOG PLACEMENT The Archgard pan burner and fiber logs are designed to give a realistic fire package, and are created to look the same as the day they were originally installed. Care must be given when first installing the logs, and if removed for servicing, as they can be damaged or broken if not handled properly.
  • Page 29 Optima 72 LOG PLACEMENT... Continued Step 1. Locate Log with 7207 stamped on the bottom and place it as shown. LOG 134 7207 Step 2. Locate Log with 7201 stamped on the bottom and place it as shown. 7201 IMPORTANT: Back of log #7201 must rest on top of log rests as shown...
  • Page 30 Optima 72 LOG PLACEMENT... Continued Step 3. Locate Log with 7203 stamped on the bottom and place it at the rear as shown. LOG 132 7203 Step 4. Locate Log with 7202 stamped on the bottom and place it on the burner as shown. LOG 133 7202...
  • Page 31 Optima 72 LOG PLACEMENT... Continued Step 5. Locate Log with 6 stamped on the bottom and place it on the front pins as shown. Step 6. Locate Log with no number stamped on the bottom and place it as shown.
  • Page 32 Optima 72 LOG PLACEMENT... Continued Step 6. Locate Log with 7205 stamped on the bottom and place it on the front pins as shown. 7205 7204 Step 7. Place black embers around logs as shown , do not cover the holes in the burner. Black embers...
  • Page 33 Grey and reflective glass panels. The brick panel options come separate from the unit and must be installed inside of the unit once you have chosen your color option. If you find any damage to the Ceramic Brick Panels, please contact the Authorized Archgard Dealer where you purchased the unit to order replacements.

  • Page 34: Optional Wall Switch, Thermostat Or Remote Control. Suggested Wiring

    If a wall mounted switch or a wall mounted thermostat is desired, Archgard recommends that the device be wired as shown in Fig 1. NOTE: Archgard Industries does not manufacture or sell any type of wall switch or wall thermo- stat and will not extend warranty to them.

  • Page 35: First Fire And Lighting Instructions (Caution)

    Optima 72 FIRST FIRE When operated for the first few times, the appliance will emit some odor and fumes. This is due to the heat from the appliance evaporating the oils and solvents used in fabricating the appliance. Close off the room to the rest of the house and open all windows. Keep the room well ventilated as smoke alarm may sound.

  • Page 36: Final Installation Check And Initial Operation

    Optima 72 FINAL INSTALLATION CHECK Each Archgard Gas Fireplace is checked and tested at the factory prior to being packaged, shipped to our dealers, and finally installed in your home. Archgard recommends that, before leaving this unit with the customer, the installer must ensure that the appliance is firing correctly, and that the electrical system is in working order.

  • Page 37: Lighting Instructions On Rating Plate

    Optima 72 LIGHTING INSTRUCTIONS ON RATING PLATE FOR YOUR SAFETY READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fire of explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by a spark •...

  • Page 38: Glass Door Removal And If Your Glass Breaks

    Fig. 1. Buckle latch Buckle latch IF YOUR GLASS BREAKS the event your glass cracks or breaks, Archgard recommends that a new door assembly be ordered to replace the original door. Remove door as per the instructions above. • Replace with new door assemblies.

  • Page 39: Louver (Grill) Instructions

    Optima 72 LOUVER (UPPER & LOWER GRILLS) INSTALLATION The Optima 72 is packaged without the upper and lower louvers (grills). They must be ordered separately. This is to allow you the option of black, black/gold, black/pewter louvers or all gold louvers.

  • Page 40: Troubleshooting Guide

    Optima 72 TROUBLESHOOTING Please check to make sure the instructions are followed exactly before attempting troubleshooting of the appliance. WARNING: Troubleshooting and servicing of gas and electrical devices of the appliance should only be conducted by a qualified service technician. SYMPTOM ACTION Pilot will not light after...
  • Page 41 Optima 72 TROUBLESHOOTING Cont... SYMPTOM ACTION The main burner does not turn 3. Check to make sure the thermostat is set high enough to turn on the on with the pilot lit. Cont... appliance. 4. Check that the remote switch or the thermostat is turned on. 5.

  • Page 42: Maintenance And Cleaning The Appliance

    The exterior painted surfaces, glass and gold trims may be cleaned with a soft, non-abrasive cloth and water or a suitable, mild, non-abrasive cleaner. Regularly: Frequent cleaning of the ceramic glass is required. Archgard recommends using a good • quality “gas fireplace” glass cleaner that is available at any hearth retail location. DO NOT CLEAN WHILE HOT.

  • Page 43: Servicing Under Warranty & Adjusting Primary Air Shutter

    Optima 72 SERVICING UNDER WARRANTY Before servicing, read the terms and conditions of the Archgard warranty at the back of the manual. Contact the Authorized Archgard dealer were you purchased the appliance from and provide them with details of the problem together with the initial installation information (from the back of this manual).

  • Page 44: Adjusting Primary Air Shutter (Continued) Changing Main Burner Orifice

    Change the orifice cap to the fuel type desired. Use a small quantity of gas thread seal compound. Do not over tighten. Reverse steps 6 to 1. THIS APPLIANCE IS EQUIPPED FOR NATURAL GAS. An additional CONVERSION kit is required to convert for Propane use. To order the CONVERSION kit, please contact your Authorized Archgard Dealer.

  • Page 45: Checking Inlet/Outlet Gas Pressures, Adjusting Pilot And Convertible Pilot Orifice

    7/16” (11 mm) open then push the small metal tab across WRENCH (HERE) to the other side of the body and retighten. Call your local Authorized Archgard Dealer to purchase the correct fuel con- version kit for your gas appliance.

  • Page 46: Replacing Convection Blower (Fan)

    Optima 72 REPLACING CONVECTION BLOWER Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. Verify proper operation after servicing This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical code, CSA C22.1.

  • Page 47: Valve Tray Assembly And Parts List

    Optima 72 VALVE TRAY ASSEMBLY Item # Item Description Unit 314-0015 Flex tub gasket 308-0120 Wing Nut, Plated Steel (AIR Shutter) 301-6007 7” Flex line assembly ,flanged orifice 301-0068 Orifice (Main Burner Orifice) Drill to # 37 DMS (2.65 mm) for Natural Gas and Drill to #52 DMS (1.62 mm) or Propane 308-0013 Valve NOVA SIT 820 (0.820.652) Natural Gas 739-0019 Pilot Assembly Box...

  • Page 48: Log And Pan Burner Parts List

    Optima 72 PARTS LIST - Logs and Pan Burner 7207 7201 7204 7203 7202 Black Embers GRATE Pan Burner Item # Item Description Unit 310-634720-1 Log 7201 310-634720-2 Log 7202 310-634720-3 Log 7203 310-634720-4 Log 7204 310-634720-5 Log 7205 (there is only 5 on log) 310-634720-6 Log 7206 (there is only 6 on log) 310-634720-7 Log 7207 872-0060-R2...

  • Page 49: Replacement Parts List

    Optima 72 REPLACEMENT PARTS LIST ARCHGARD OPTIMA 72 Item # Item Description Unit 200-0200 Owner’s Manual 300-0031 Magnet Pull (holds bottom louver) 300-0034 Catch, Door Latch. (Buckle for door) 308-0005 Piezo Igniter Only 700-0140 Vent Restrictor #1 700-0141 Vent Restrictor #2 308-0046 Knob Extension - ON/OFF 1-/12”...
  • Page 50 Optima 72 REPLACEMENT PARTS LIST ARCHGARD OPTIMA 72 (continued) Item # Brick Panel Kit ( Quebec City Red) Unit 72-BRPL-QCR Ceramic Brick Panel Set 311-6340-R Ceramic Brick Liner - Right Side 311-6340-L Ceramic Brick Liner - Left Side 311-6340-C Ceramic Brick Liner - Center...

  • Page 51: Warranty

    Problem Description ❖ NOTE: Warranty may be void if work is carried out by an unqualified person (s). Only original Archgard parts may be used. Please consult your Archgard dealer or representative if in doubt about a replacement part (s).

  • Page 52: Frequently Asked Questions

    Q. My fan/blower makes a “whirring” or “humming” noise. A. Your Archgard gas appliance uses a powerful fan to push heated air into your room. It is not unusual to hear a “humming” noise when your fan is running. Note: the sound will change depending on the setting that your fan speed control is set at.

  • Page 53: Warranty Registration

    POSTAGE WARRANTY REGISTRATION RCHGARD NDUSTRIES 7116 BEATTY DRIVE MISSION, B.C. CANADA V2V 6B4 FOLD DOWN AT LINE FOLD DOWN AT LINE & TAPE CLOSED 72-DVT30N Model # : Serial #: Date Installed: yyyy Name: Address: City: State/Prov: ZIP: Phone: ( _____ ) Dealer's Name &...
  • Page 54 Archgard Industries Ltd. 7116 Beatty Drive Mission, B.C. V2V 6B4 Canada Website: www.archgard.com...
