The Front
Panel
2
1
3-SDG6000X Quick Start
3
11
10
Figure 2 SDG6000X Front Panel
5
4
6
7
9
8
1. Power Key
2. USB Host
3. Touch Screen Display
4. Numeric Keyboard
5. Knob
6. Arrow Keys
7. CH1/CH2 Control/
Output Port
8. Channel Select Key
9. Function Keys
10. Waveform Option
11. Menu Keys
