Proserve NMS80
Endress+Hauser
Further parameter settings
The following parameters affect the safety function. However, they may be freely
configured in accordance with the application:
It is recommended to note down the configured values!
Parameter
Setup
Setup
Setup
Setup
Setup
Current input measurement: Setup → Advanced setup → Input/output → Analog
I/O
The following parameters affect the safety function and are not freely configurable in
Expert mode. Instead, they are automatically set by the device to the safety-related values
mentioned at the start of SIL confirmation:
Parameter
Operation → Gauge command → Gauge command
Setup → Advanced setup → Input/output → Digital input mapping → Digital input
source 1
Setup → Advanced setup → Input/output → Digital input mapping → Digital input
source 2
Setup → Advanced setup → Input/output → Digital Xy-z → Contact type
Setup → Advanced setup → Input/output → Digital Xy-z → Output simulation
Setup → Advanced setup → Application → Tank calculation → HyTD → HyTD mode
Setup → Advanced setup → Application → Tank calculation → CTSh → CTSh mode
Setup → Advanced setup → Application → Alarm → Alarm X → Error value
Setup → Advanced setup → Application → Alarm → Alarm X → Alarm mode
Setup → Advanced setup → Safety settings → Output out of range
Diagnostics → Simulation → Simulation distance on
Diagnostics → Simulation → Current output 1 simulation
Expert → Input/output → Digital Xy-z → Error on event
Expert → Input/output → Analog I/O → Error on event
Expert → Input/output → Analog I/O → Output out of range
Expert → Input/output → Analog I/O → Feedback threshold
Those parameters which are not mentioned do not affect the safety function and can
be configured to any meaningful values. The visibility of the parameters mentioned in
the operating menu depends in part on the user role, the SW options ordered and on
the configuration of other parameters.
Unlocking a SIL device
When SIL locking is active on a device, the device is protected against unauthorized
operation by means of a locking code and, as an additional option, by means of a hardware
write protection switch. The device must be unlocked in order to change the configuration
Use in safety instrumented systems
Parameter name
Upper density
Process condition
High stop level
Low stop level
Empty
0 % value
100 % value
Preset value
Level
None
None
Normally closed
Disable
No
No
All alarms
On
Alarm
Off
Off
Any error
Any error
Alarm
1 s
