GMZ3-24H-S
GMZ4-28H-S
GMZ4-36H-S
Thank you very much for purchasing this Air Conditioner. Please
read this
use and installation instructions
and using this appliance and keep this manual for future reference.
Живлення подається на
Модель
GMZ3-24H-S 1 фаза, 220-240 В, 50 Гц
GMZ4-28H-S 1 фаза, 220-240 В, 50 Гц
GMZ4-36H-S 1 фаза, 220-240 В, 50 Гц
Внутрішній блок GKM18H-S комплектується з'єднувачем
діаметром 9.52-12.7 мм, який монтується на зовнішній блок
carefully before installing
Важлива інформація
Міжблочний
2
Кабель, мм
зовнішній блок
кабель, мм
3х2,5
3х2,5
3х4,0
тується на зовнішній блок
2
4х1,5
4х1,5
4х1,5
