  • Page 1 Single-room air handling unit CIVIC EC LB 1200 CIVIC EC LBE 1200 CIVIC EC LBE2 1200 USER'S MANUAL...
  • Page 2: Table Of Contents

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................7 Mounting and set-up .................................. 9 Connection to power mains ..............................14 Control .........................................
  • Page 3 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
  • Page 4: Purpose

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de PURPOSE The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafes, conference halls, and other utility and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of intake air.
  • Page 5: Technical Data

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de TECHNICAL DATA The unit is designed for indoor application with the ambient temperature ranging from +1 °C up to +40 °C and relative humidity up to 60 % without condensation. In cold, damp rooms, there is a possibility of freezing or condensation inside and outside the casing. In order to prevent condensation on the internal walls of the unit, it is necessary that the surface temperature of the casing is 2-3 °C above the dew point temperature of the transported air.
  • Page 6 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de OVERALL DIMENSIONS [mm] 2106 2000 1110 1900 1951...
  • Page 7: Design And Operating Principle

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE UNIT OPERATION LOGIC Heat Recovery mode: warm stale extract air from the room flows into the unit, where it is filtered by the extract filters, then air flows through the heat exchanger and is exhausted outside by the extract fan. Cold fresh air from the outside flows into the unit, where it is cleaned by the supply filters.
  • Page 8 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de DVUT 1200 HB E2 EC unit design 13 14 15 1 – air dampers 2 – G4 supply filter 3 – F7 supply filter (option) 4 – preheater 5 – supply fan 6 – SETUP MODE button 7 – louver shutters for adjusting supply air direction 8 –...
  • Page 9: Mounting And Set-Up

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de MOUNTING AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. While choosing the mounting location provide enough access for maintenance or repair work. Ø 425-450 min 950 The unit is designed for mounting to a horizontal surface adjacent to the wall with the ready-made holes for the air ducts. Lower the supports on the feet of the unit.
  • Page 10 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de Layout of holes for mounting screws (A – M6, B – M8) Remove the protective panels to access the bottom of the unit. At the end of the installation, install the panels in reverse order. Caution: Do not operate the unit with the panels removed.
  • Page 11 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de Secure the sections with screw connections (mounting screws are included in the delivery set). Close the door and install the decorative panel.
  • Page 12 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de , VOC, HUMIDITY SENSOR MOUNTING (NOT INCLUDED IN THE DELIVERY SET) The sensors are installed in the exhaust air duct upstream of the heat exchanger. Before installation, remove the protection plate and remove the extract filter. Install the CO and VOC sensors in the respective brackets and connect the connectors to them.
  • Page 13 CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de CONDENSATE DRAINAGE The models without a drain pump are equipped with condensate drain pipes. Connect the drain system to the spigots. min 3° 1 – drain pipe (Ø 20 mm) 2 – coupling 3 – L-shaped bend (Ø 20 mm) 4, 6 – connection pipe 5 – U-trap 7 – sewage system A separate drainage system must be connected to each drain pipe.
  • Page 14: Connection To Power Mains

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL.
  • Page 15: Control

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de EXTERNAL CONNECTION DIAGRAM FOR CIVIC EC LB 1200 CCU* +24V 1~230 V/50 Hz (unit with a drain pump) 1~230 V/50(60) Hz PK1* Boost* (unit without a drain pump) EXTERNAL CONNECTION DIAGRAM FOR CIVIC EC LBE 1200, CIVIC EC LBE2 1200...
  • Page 16: Technical Maintenance

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de TECHNICAL MAINTENANCE Maintenance operations of the unit are required 3-4 times per year. They include general cleaning of the unit and the following operations: 1. Filter maintenance. Dirty filters increase air resistance in the system and reduce supply air volume.
  • Page 17: Troubleshooting

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de TROUBLESHOOTING IF UNIDENTIFIED NOISES OR ODOURS SHOULD ARISE AND IN CASE OF DEFORMATION OF ELEMENTS, VIBRATION, TERMINATION OF AIR SUPPLY/EXTRACTION OR REDUCED SYSTEM PERFORMANCE, IMMEDIATELY DISCONNECT THE UNIT FROM POWER SUPPLY AND CONTACT THE SELLER FOR THE UNIT DIAGNOSTICS DIAGNOSTICS MUST BE CARRIED OUT BY QUALIFIED SPECIALISTS Problem Possible reasons...
  • Page 18: Manufacturer's Warranty

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC.
  • Page 19: Certificate Of Acceptance

    CiViC eC lB(e/e2) 1200 www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Single-room air handling unit Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted.
