- Page 1 Air hAndling unit KOMFORT EC S200 KOMFORT EC S200-E KOMFORT EC SB200 KOMFORT EC SB200-E KOMFORT EC S250 KOMFORT EC S250-E KOMFORT EC SB250 KOMFORT EC SB250-E USER’S MANUAL...
-
Page 2: Table Of Contents
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivry set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................6 Installation and set-up................................8 Connection to power mains ..............................11 Technical maintenance ................................ - Page 3 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de • Do not change the power cable length at your own discretion. Do not bend the • Do not lay the power cable of the unit in power cable. Avoid damaging the power close proximity to heating equipment. cable.
-
Page 4: Purpose
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de PURPOSE The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafés, conference halls, and other utility and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of supply air. -
Page 5: Technical Data
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de TECHNICAL DATA The unit is designed for indoor application with the ambient temperature ranging from +1 °C up to +40 °C and relative humidity up to 80 %. In order to prevent condensation on the internal walls of the units, it is necessary that the surface temperature of the casing is 2-3 °C higher than the dew point temperature of the transported air. -
Page 6: Design And Operating Principle
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE The unit has the following operating principle: Warm stale extract air from the room flows into the unit, where it is filtered by the extract filter, then air flows through the heat exchanger and is exhausted outside by the extract fan. Cold fresh air from the outside flows into the unit, where it is cleaned by the supply filter. - Page 7 Summer cooling mode Heat recovery mode Supply fan is off Bypass duct is open Bypass duct is open KOMFORT EC S(B)200 KOMFORT EC S200 KOMFORT EC SB200 KOMFORT EC SB200 KOMFORT EC S(B)250 KOMFORT EC S250 KOMFORT EC SB250 KOMFORT EC SB250...
-
Page 8: Installation And Set-Up
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de INSTALLATION AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. HUMIDITY SENSOR MOUNTING IN THE EXTRACT AIR DUCT ATTENTION! The humidity sensor must be installed in the air duct prior to the unit mounting. Mounting steps for the FS1 humidity sensor: •... - Page 9 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de KOMFORT EC S(B)250 Note: the service panel change is shown for UNIT MOUNTING To attain the best performance of the unit and to minimise turbulence-induced air pressure losses while mounting connect a straight air duct section on both sides of the unit.
- Page 10 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de WARNING! • Do not remove the plugs before the heaters are connected to the air handling unit. • Make sure to cover the socket connector with the plugs after dismantling of the connecting cable. • If only one heater is connected, do not remove the plugs from the other socket connector that is not in use. •...
-
Page 11: Connection To Power Mains
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de CONNECTION TO POWER MAINS DISCONNECT THE UNIT FROM POWER MAINS PRIOR TO ANY OPERATIONS. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. - Page 12 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de Access to the control unit • Unscrew the front panel on the service side and remove it. • Remove the hear exchanger. • Remove the screws that retain the electric connection plate and push it downwards. KOMFORT EC S(B)200 models both terminal blocks X1 and S2 are located on the electric connection plate of the...
- Page 13 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de KOMFORT EC S(B)200 +12V — ELECTRIC SHOCK HAZARD +12V no c KOMFORT EC S(B)250 +12V — ELECTRIC SHOCK HAZARD no c +12V no c UNIT CONTROL OPERATING THE UNIT WITH THE S14 CONTROL PANEL VIA SOFTWARE To enable operation of the unit using the pre-installed software connection the unit to a laptop or PC via a USB cable with Type A and Type B connectors.
-
Page 14: Technical Maintenance
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de TECHNICAL MAINTENANCE DISCONNECT THE UNIT FROM POWER SUPPLY BEFORE ANY MAINTENANCE OPERATIONS! The unit must undergo technical maintenance 3 to 4 times a year. Maintenance includes general cleaning of the unit and the following operations: 1. Filter maintenance (3–4 times per year). Clogged filters increase air resistance in the system and reduce supply air volume. - Page 15 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de 4. Condensate drainage maintenance (once per year). The drain pipes may get clogged with the extracted particles. Pour some water inside the drain pan to check the pipe for clogging. Clean the U-trap and the drain pipe if required. 5.
-
Page 16: Storage And Transportation Regulations
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de STORAGE AND TRANSPORTATION REGULATIONS • Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range from +5 ˚С up to +40 ˚С and relative humidity up to 70 %. •... -
Page 17: Manufacturer's Warranty
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Council Directive 2014/30/EU, Low Voltage Directive 2014/35/ EU and CE-marking Directive 93/68/EEC. - Page 18 KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de...
-
Page 19: Certificate Of Acceptance
KOMFOrt EC S(B)200(250)(-E) www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Air handling unit Model KOMFORT EC S_____________ Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 20 www.blaubergventilatoren.de B106-5EN-03...
