Opticon PHL-7000 Quick Manual

OVERVIEW
F1 Key
None(Reserved for Customization)
Charger LED Indicator
Scan Key
Alpha Key
DC Power Jack
USB/Serial/
Synchronization Port
Numeric Key
Hand Strap
Battery Cover Latch
Battery Cover
Stylus
Left Scan Key
Ear Phone
Jack Connector
Scanner LED Indicator
Power Key
Scan Key
F2 Key
Right Scan Key
LCD Touchscreen
F4 Key
F3 Key
Navigation Key
Fn Key
Enter Key
Speaker
(Under the Hand Strap)
Scan Window
BEFORE GETTING STARTED BEFORE GETTING STARTED
1. Open the package and check every
accessory:
Main Unit
Quick Guide Quick Guide
(Not Shown) (Not Shown)
GSM Earphone GSM Earphone
Note:
!
CAUTION:
The PHL-7000 will be powered on when you install Battery Pack.
Power off PHL-7000 after touch screen calibration and charge
batteries for at least 6 hours. Do not turn on the PHL-7000 for the
first time until batteries are charged for at least
℃ ℃
charge batteries at 0 ~45
The Charger LED will be turned to green color when battery charging
is finished.
2. Installing the Battery Pack
1) Detach the Hand Strap.
2) Turn the battery cover latches downwards and lift
the battery cover away.
3) Insert the Battery Pack into the battery compartment with the
label facing out, and make sure the battery fits into place.
4) Place the battery cover by inserting the top first, and then press
End Cap the bottom in firmly. Turn the battery cover latches upwards to
secure the cover to the PHL-7000.
3. Connect Power Adapter to Charge the PDT
1) Insert DC connector into bottom case of the PHL-7000.
2) Connect Power Cord to power adapter.
3) Insert power cord to AC Outlet.
USING THE KEYPAD USING THE KEYPAD
The keypad comprises 52 keys (alpha, numeric,
arrow, functional and Fn) and 4 scan buttons.
1) Press "
lower-case ones.
2) Press "
lower-case ones.
3) Press "
Fn
Sequence of Keys
Battery Pack Battery Pack USB Client USB Client
(3000mAh) (3000mAh) Cable for Terminal Cable for Terminal
Power Adapter Power Adapter Ear/Microphone Set Ear/Microphone Set Sequence of Keys
(5VDC/2.6A) (5VDC/2.6A)
Fn
Fn
Fn
Fn
Fn W
Fn X
Stylus Power Cord Power Cord
Fn 1
Fn 2
Fn 3
CF Support Guide CF Support Guide BATTERY PRODUCT SAFETY
availability depends of PHL-7200 model
Lithium-ion Battery Packs might get hot, explode, ignite
and/ or cause serious injury in case of misuse.
Please follow the safety warnings listed below:
A.Do not throw the battery into fire. Do not expose the battery to
high temperatures.
B. Do not connect the positive Battery Pack with negative
Battery Pack to each other with any metal object (like wire).
6 hours. Always
C. Do not carry or store Battery Pack together with metal objects.
℉ ℉
(32 ~113 ) environment temperature.
D. Do not pierce the Battery Pack with nails or drills, strike the battery
pack with a hammer, step on the Battery Pack or otherwise expose
it to strong impacts, shocks or excessive force.
E. Do not solder directly onto the Battery Pack.
F. Do not expose Battery Pack to liquid or allow the battery contacts
to get wet.
G. Do not disassemble or modify the Battery Pack.The Battery Pack
contains safety and protection measures, which, if damaged,
may cause the Battery Pack to generate heat, explode or ignite.
H. Do not discharge the batteries outside the PHL-7000. Do not use
the battery in another device then the PHL-7000 or IRU-7000
series battery chargers. Otherwise, the Battery Pack can be
damaged, the Battery Pack can be damaged or its life expectancy
reduced. If the device causes any abnormal current to flow, it may
cause the Battery Pack to become hot, explode or ignite and
cause serious injury.
I. In the event the Battery Pack leaks and the fluid gets into one's eye,
do not rub the eye.
Rinse well with water and immediately seek medical care.
If left untreated,the battery fluid could cause damage to the eye.
" to onetime toggle between upper-case character and
SHIFT
" to toggle between upper-case character and
Caps
" to toggle Function Mode.
Special Functions
Sequence of Keys
Description Description
Launch of Application 1 Launch of Application 5
Fn A
Launch of Application 2 Fn B Launch of Application 6
Launch of Application 3 Launch of Application 7
Fn C
Launch of Application 4 Launch of Application 8
Fn D
Special Functions
Sequence of Keys
Description Description
Increase of Brightness
Paste
Fn 4
Reduction of Brightness Delete
Fn 5
－ Minus Sign
Page Down
Fn 6
Page Up Copy
Fn 7
Volume Up &
Fn 8
＊
Volume Down
Fn 9
@
Start Menu
Fn 0
Space
'
Fn
＋
