INSTRUCTIONS-PARTS LIST
This manual contains important
warnings and information.
READ AND KEEP FOR REFERENCE.
INSTRUCTIONS
HIGH VOLUME
Air Regulators
300 psi (2.1 MPa, 21 bar) Maximum Air Inlet Pressure
5 to 150 psi (.03 to 1 MPa, 0.3 to 10 bar) Pressure Range
Part No. 114-459
1 in. npt(f) inlet and outlet
Part No. 114-105
1/2 npt(f) inlet and outlet

Table of Contents

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440-1441
2
3
4
4
5
7
8
. . . . . . . . . . . . . . . . . .
8
COPYRIGHT 1998, GRACO INC.
Graco Inc. is registered to I.S. EN ISO 9001
308-859
First choice when
quality counts.
Part No. 1 14-459
Part No. 1 14-105
Rev. A

Advertisement

loading

Related Manuals for Graco 114-459

Summary of Contents for Graco 114-459

  • Page 1: Table Of Contents

    ....Part No. 1 14–105 GRACO INC. P.O. BOX 1441 MINNEAPOLIS, MN 55440–1441 COPYRIGHT 1998, GRACO INC. Graco Inc. is registered to I.S. EN ISO 9001...

  • Page 2: Warnings

    This equipment is for professional use only. Read all instruction manuals, tags, and labels before operating the equipment. Use the equipment only for its intended purpose. If you are uncertain about usage, call your Graco distributor. Do not alter or modify this equipment. Use only genuine Graco parts and accessories.

  • Page 3: Installation

    Installation Prepare the Site Install the Regulator NOTE: Always use Genuine Graco Parts and Acces- The air regulator controls pump speed and outlet sories, available from your Graco distributor. If you pressure by adjusting the air pressure to the pump.

  • Page 4: Operation

    Operation Pressure Relief Procedure 6. Lock the gun trigger safety. 7. Open any fluid drain valves (required in your WARNING system), having a container ready to catch the drainage. INJECTION HAZARD The system pressure must be manually 8. Leave the drain valve(s) open until you are ready relieved to prevent the system from to spray again.

  • Page 5: Parts

    Parts Repair Kit 240–817 (includes items 101 to Model 114–459 107). For Part No. 114–459 Air Regulator. Air Regulator Shown Kit parts are marked with an asterisk (101*). Individual Lubricate with no. 2 parts are not available separately. lithium-base grease. Ref.
  • Page 6 Parts Repair Kit 240–818 (includes items 101 to 105). For Part No. 114–105 Air Regulator. Model 1 14–105 Air Regulator Shown Kit parts are marked with an asterisk (101*). Individual parts are not available separately. Lubricate with no. 2 lithium-base grease. Ref.

  • Page 7: Technical Data

    Technical Data Category Data Maximum air input pressure 300 psi (2.1 MPa, 21 bar) Air pressure range 5 to 150 psi (.03 to 1 MPa, 0.3 to 10 bar) Air inlet and outlet size Part No. 1 14–459: 1 in. npt(f) Part No.

  • Page 8: Graco Warranty

    Graco distributor to the original purchaser for use. With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.

This manual is also suitable for:

114-105
