Analog way Eikos LE Quick Start

QUICK START
Thank you for choosing Analog Way and the Eikos LE. By following these simple steps, you will be able to setup
and use your powerful Multi Layer Hi-Res. Mixer Seamless Switcher within minutes. Discover the Eikos LE extensive
capabilities and intuitive interface while configuring your first show, and unleash your creativity for a new experience in
show and event management by Analog Way.
What's in the box
1 x Eikos LE
1 x Power supply cord
2 x DVI male to HD15 female and DVI-D female breakout cable
1 x HD15 to 5 BNC cable
1 x Ethernet cross cable (for device update)
1 x Set of 11 audio 5 pin screw terminals
1 x RCS - Remote Control Software (PC only) *
4 x Screws for handle removal (M4x12mm)
1 x Quick Start guide
1 x User Manual
* Download on our website:
Quick install and setup
Key points:
• Red LED: Source or layer is on Main
• Blinking button: Source or layer selected for modifica-
tion
• DSK function uses a layer
• Frames and Logos are unscaled sources
• One logo available in Native Matrix Mode per output
• BLACK button allows to remove a Layer (Clear
function)
IN MIXER MODE (Maximum displaying):
- 1 Background Live Seamless in switching
- 2 PIPs on Background Live + 2 Logos
- 3 PIPs on Background Frame + 2 Logos
IN NATIVE MATRIX MODE:
- 1 PIP on Background Frame + 1 Logo
- No preview
www.analogway.com/technical_support/
WARNING !
If required, front handles of the device can be dismantled,
but with caution.
The original screws removed must not be reintroduced to
their location without handles in place.
Substantial damages can occur, including risk of elec-
tric shock from the mains voltage.
Only M4x12mm screws can be used.
(They are supplied with the unit)
Getting started:
1. Observe all safety precautions. Rackmount chassis
(please refer to user's manual) or install in «table
top» configuration.
2. Connect all inputs (please refer to user's manual:
Input specification).
3. Power on.
4. Perform factory reset:
• Press the ExIt/MENu button, from the Home
Menu
• Select [Control] > navigate in the Menu by
rotating the corresponding knob
• Press the ENtER button or push the knob to
enter the control sub-menu
• Select [Default Values] and press ENtER
button. this operation should take approximately
30 seconds.
IMPORTANT: simply selecting a menu item will not
set it to that value. Be sure to press the ENTER button
when parametering the menu items.
Eikos LE - EKS400
