CHARACTERISTICS:

The HD67B11-B2 is a OPC UA Client / BACnet Slave converter.
It allows the following characteristics:
Up to 1500 bytes in reading and 1500 bytes in writing;
Two-directional information between BACnet and OPC UA;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8...24V AC or 12...35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].

CONFIGURATION:

You need Compositor SW67B11 software on your PC in order to perform the following:
Define the parameter of OPC UA;
Define the parameter of BACnet line;
Define the list of OPC UA servers connected to the converter;
Define the list of BACnet objects accessible on BACnet side;
Update the device.
