We are very pleased that you decided to

purchase this product from SWAROVSKI OPTIK.

If you have any questions, please consult your

specialist dealer or contact us directly at

WWW.SWAROVSKIOPTIK.COM.

1 Carry strap

2 Eyepiece cover

3 Screw-in-type eye cups

4 Focusing wheel

5 Dioptric scale

Please find our current product accessories at WWW.SWAROVSKIOPTIK.COM.

DE EN

6 Dioptric zero point

7 Covering for the tripod

connector thread

8 Objective lens cover

9 Snap Shot Adapter

Page 1 We are very pleased that you decided to purchase this product from SWAROVSKI OPTIK. If you have any questions, please consult your specialist dealer or contact us directly at WWW.SWAROVSKIOPTIK.COM. 1 Carry strap 2 Eyepiece cover 3 Screw-in-type eye cups...
Page 2 For your safety! WARNING! Never look at the sun with the binocular! This leads to injury of your eyes! Never look through the binocular when walking! You could encounter ob- stacles! General information Please protect your bino- culars from jolts and jars.
Page 3 Operation Adjustment of the screw-in-type eye cups Use without eyeglasses: Basically, there are two different adjustment posi- tions available with different distances between the eye and the lens. This allows you to adjust the eye cups individually to your personal preference. Pos.
Page 4 Use with equal acuity of both eyes: 1. Pull the focusing wheel outwards. 2. By turning the focusing wheel, set the dioptric scale to “0”. 3. Push the focusing wheel back in. Use with varying acuity of both eyes: 1. Look through the left ocular with your left eye and turn the focusing wheel to focus sharply on a selected object.
Page 5 In the event of hard-to-remove dirt (e.g. sand) the eye cups can be unscrewed and cleaned very easily. Storage You should keep your binocular in its bag in a well- ventilated, dry place. If the instrument is wet, it must be dried prior to storage.
