- Page 1 PETROL GENERATOR HYW130DC Instruction Manual...
-
Page 4: Safety Instruction
1. Safety Instruction Please read the manual before operation, failure to comply with the manual could lead to danger of operator, others and the machine. 1.1.Protect yourself and others. Welding can make you and others in danger of many risk factors: Make sure to never weld without a welding mask. - Page 5 let your body touch the ground and the electrode at that same time.o 1.3 Welding fumes and gasses can cause serious harm to operator and all other by standards. Please keep your head away from a place you could possibly breathe in fumes and make sure to use the machine in a well ventilated area.
- Page 6 1.8 The engine operates on gasoline. It is important to keep inmind this unit cannot be run indoors. Carbon Monoxide has no odor and can be fatal in a short period of time. 1.9 Gasoline is highly flammable and is capable of causing a large explosion.
- Page 7 1.12 Refrain from using the air compressor when welding. Also, it is recommended that you disconnect all sources from the generator as well when welding. 1.13 Welding power source used for pipeline defrost operation is prohibited.
-
Page 8: Machine Structure
3.Machine structure Notice: Any modification on the control panel and appearance will not be advised again. 1. Starting lock 2. Three-phase circuit 3. 3 in 1 digit meter 4. Power supply switch 5.Current indicator 6.Thrust regulator 7. Negative welding socket 8．... - Page 9 1. Engine assy. 2. Frame beam 3. Fuel tank 4. Fuel tank cover 5. Plastic cover 6. Frame 7. Handle 8. Handle sheath 9. Muffler 1． Throttle 2． Air cleaner 3． Recoil starter and handle 4． Recharge module 5． Fuel switch 6． Side board...
- Page 10 4.Preparation 4.1 Before starting the unit, please read this manual carefully, fully understand the operating procedures, and do not blindly start the machine. 4.2 checks whether the unit parts are completely equipped, and the connecting bolts, nuts and other fasteners and joints are assembly securely, if not, please be repaired in a timely manner.
- Page 11 4.4 Engine Oil Recommodation 4.4.1 Oil is a major factor affecting engine performance and service life. Please use 4-stroke gasoline engine oil meet or exceed API classification SE grade or equivalent rating required. Remember to check the oil API classification label on the package to make sure it comes with the letters SE or an equivalent grade of.
- Page 12 box, remove the air filter cover. being careful not to damage the air filter cover. 4.6.3 Remove filter element from the air filter cover. 4.6.4 Checking if air filter is clean and in good condition. If air filter is dirty, wash it. If the air filter is damaged, it must be replaced.
- Page 13 5.Starting 5.1 Turn on fuel switch. "Fuel valve" located between fuel tank and carburetor. When you want to start generator, turn fuel valve to "on" position.After shut down,please turn the fuel valve to "off" position. Fuel switch 5.2The choke is used to provide an enriched fuel mixture when starting a cold engine.
- Page 14 5.3 Start and stop engine. 5.3.1 Electric start machine: Please operate starting key on the control panel, turn to clockwise until engine started, and turn back the key to start position. If not started, please try it again after 30s. Stop : Stop engine running Start : Startengine Open : Machine running...
- Page 15 6. Running ° ° 6.1 Environment temperature: welding:-10 C ,--�40 ° ° 6.2 Transportation and storage: -20 C �,55 ° ° 6.3 Relative humidity:�50%in40 C ,�90% in 20 suitable altitude�1000. 6.4 Inclination angle: welding electricity resource inclination angle shouldn't exceed 1 0degree. 6.5When connect plug to panel, if there is short circuit or over load, the circuit breaker will shut down automatically, once is was shut down, please check the...
- Page 16 6.7 Attention: The machine can work under two types of power, generator and commercial power. 6.7.1 If choose generator to supply welding, operator needs to start the generator first. Then turn Power Supply Switch to “GENERATING” position. Next turn “GENERATING” circuit to “ON” position.
- Page 17 ◆ When using generator function, operator needs to cut off power circuit first. Let machine running for 3 minutes with non-load. Then turn off the power switch to “OFF” position. ◆When using welding function, operator needs to stop welding first. Then turn Power Supply Switch to middle position. Cut off all circuit on the control panel.
- Page 26 1, Short circuit on thermal 1, Change thermal resistor. resistor 2, Short circuit on power 2, Change three -phase bridge board three -phase bridge rectifier response rectifier after 3,Inspect the wire connection 3, Bad connection between start power board and control and tighten the connector machine panel (3 red, 3 black)
- Page 28 Isaac Way, London Road Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported/Distributed by GENPOWER LTD for The United Kingdom & Ireland Licensed by Hyundai Corporation, Korea...
