- Page 1 PETROL INVERTER GENERA TOR HY3500Ei User Manual...
-
Page 2: Table Of Contents
INDEX CONTENTS PAGE NO.S SAFETY 3 - 8 PART LOCATIONS PRE-ASSEMBLY CHECKS 10 - 11 STARTING PROCEDURE STOPPING PROCEDURE OPERATING INSTRUCTIONS 13 - 16 MAINTENANCE 17 - 19 TRANSPORT & STORAGE TROUBLESHOOTING SPECIFICATION RECYCLING & PRODUCT DISPOSAL DECLARATION OF CONFORMITY CONTACT DETAILS MANUAL UPDATES WARRANTY... -
Page 3: Safety
1. SAFETY General Safety Notes. The operator of the machine is responsible for, and has a duty of care in making sure that the machine is operated safely and in accordance with the instructions in this user manual. Keep the manual safe and pass it on if the machine is loaned or sold to another user. - Page 4 1.10 Carbon Monoxide (where applicable). 1.11 Carbon monoxide is a colourless and odourless gas. Inhaling this gas can cause death as well as serious long term health problems such as brain damage. 1.12 The symptoms of carbon monoxide poisoning can include but are not limited to the following;...
-
Page 5: Safety
1.20 General Fuel Safety (where applicable). CAUTION ALL FUELS ARE FLAMABLE Fire Hazard – keep fuel away from all sources of ignition for example heaters. 1.21 Lamps, sparks from grinding or welding. DO NOT carry out hot work on tanks that have contained fuel. 1.22 1.23 ALWAYS keep the work area tidy. - Page 6 1.50 Batteries (where present). 1.51 Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. NOTE the electrolyte may be in a liquid or gel form.
- Page 7 1.70 Noise (where applicable). 1.71 The operating noise of the machine can damage your hearing. Wear hearing protection such as earplugs or ear defenders to protect your hearing. Long-term and regular users are advised to have hearing checked regularly. Be especially vigilant and cautious when hearing ear protection because your ability to hear alarm warnings will be reduced.
- Page 8 1.91 NEVER allow children or anyone unable to fully understand the directions given in this manual to operate this product. 1.92 Make sure you keep this manual handy so you may refer to it whenever questions arise and ensure you pass this manual on if the machine is loaned or sold. 1.93 Correct Personal Protective Equipment (PPE) MUST be worn at all times when operating or repairing this machine.
-
Page 9: Part Locations
2. PART LOCATIONS Fuel Filler Cap Ignition Switch Exhaust DC Protector Air Filter DC Socket Recoil Starter Handle Indicator Lights Choke AC Circuit Breakers Fuel Switch Economy Switch Control Panel Earth Point Economy Switch AC Sockets LCD Display... -
Page 10: Pre-Assembly Checks
3. PRE OPERATION CHECKS WARNING This machine is shipped without fuel and oil and MUST be filled before operation. Failure to do so may result in engine damage the will not be covered by Warranty. Ensure the generator is on flat, level ground before filling with fuel or oil. WARNING ALL FUELS ARE FLAMMABLE Switch off the engine and allow to cool before filling with fuel and ALWAYS fuel and... - Page 11 To fill with fuel, remove the fuel filler cap. Fill with 12.5 litres of fresh unleaded petrol. DO NOT mix fuel with the oil. DO NOT overfill, fill to the upper limit mark or leave a 25mm gap between the fuel and the top of the fuel tank.
-
Page 12: Starting Procedure
4. STARTING THE ENGINE WARNING NEVER start or stop engine with electrical devices plugged into the power outlets and devices turned on. Unplug all electrical loads from the units power outlets or make sure that the main breaker is in the OFF (down) position before starting the engine. WARNING To avoid carbon monoxide poisoning DO NOT use Petrol/Diesel powered equipment inside any of the following;... -
Page 13: Stopping Procedure
ELECTRIC START Turn the fuel switch (1) to the ‘ON’ position. Turn the engine switch (2) to the ‘ON’ position. Pull the choke knob (3) fully out. NOTE: if starting from warm, do not use the choke. With the power switch in the ‘RUN’ position, rotate the ignition switch (4) to ‘START’ 3.10 and hold there for 1 second or until the engine starts. - Page 14 Keep at least 5 feet (152cm) of clearance on all sides of the generator including overhead. IMPORTANT DO NOT overload the generator. DO NOT overload individual output sockets. The outlet sockets are protected against overload with a push-to-reset type of circuit breakers.
- Page 15 Once the overload indicator light switches off, you can reconnect the electrical appliances. Observe the following to prevent overloading of the unit; Add up the total wattage of all electrical devices to be connected at one time. This total should NOT be greater than the generators wattage capacity. The rated wattage of lights can be taken from light bulbs.
- Page 16 5.18 Turn the economy switch to the OFF position. 5.19 In order to avoid producing a spark, connect the charging cables to the battery terminals first and then to the generator. Reverse this procedure when disconnecting. 5.20 Connect the positive battery terminal to the positive charging cable. DO NOT reverse the charging cable as this could damage the generator or battery.
-
Page 17: Maintenance
7. MAINTENANCE WARNING Before cleaning, inspecting or repairing your unit, you MUST make sure that the engine has stopped and allowed to cool. You MUST disconnect the spark plug HT lead cap to prevent any accidental starting. CAUTION ALWAYS refuel in a well-ventilated area with the engine off and the spark plug HT cap removed. - Page 18 AIR FILTER CAUTION The engine MUST NOT be run without an air filter otherwise piston and/or cylinder damage can occur. This type of damage will NOT be covered under warranty. Maintaining the air filter is very important. If dirt is allowed to get in to the engine through improperly installed, serviced or inadequate filter elements, it can damage and wear out the engine.
- Page 19 6.10 Fill to the upper limit on the oil filler neck (3). 6.11 If you overfill with oil, you can drain the excess by removing the oil drain plug (3). 6.12 Once the correct oil level has been reached. Refit the oil filler cap/dipstick securely. SPARK PLUG 6.13 Always replace with the same model spark plug, recommended spark plug for this...
-
Page 20: Transport & Storage
8. TRANSPORT & STORAGE TRANSPORT For transport, do not overfill the fuel tank. If the generator has been used, allow it to cool for at least 15 minutes before loading it in to the transport vehicle. To prevent fuel spillage, the generator should be secured upright in its normal working position with the start switch in the OFF position and the fuel cap vent lever in the OFF position. -
Page 21: Troubleshooting
9. TROUBLESHOOTING Problem Recommended Action Not enough fuel Fill with fuel Start switch and fuel valve not Turn them to the ON position Not enough engine oil Add more oil Engine will not start Start a few times to ensure No fuel in the carburetor fuel enters the carburetor Replace spark plug... -
Page 22: Specification
10. SPECIFICATION Model Type 4 stroke OHV single cylinder Displacement 212cc Bore/Stroke 70mm/54mm Compression Ratio 8.5:1 Rated Power 4.0/3600 kW/min ENGINE Ignition System Full transistor Starting Method Recoil / Electric Fuel Type Unleaded petrol Oil Capacity 600ml Oil Type Semi-synthetic SAE 15W-40 Model HY3500i 50Hz... -
Page 23: Recycling & Product Disposal
11. RECYCLING & PRODUCT DISPOSAL We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and or Batteries is passed onto you by So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site. -
Page 24: Declaration Of Conformity
12. DECLARATION OF CONFORMITY Genpower Ltd confirms that this Hyundai generator conforms to the following CE directives: 2006/42/EC Machinery Directive 2004/108/EC EMC Directive 2000/14/EC Noise Emissions Directive 97/68/EC NRMM Emissions Directive... -
Page 25: Contact Details
13. CONTACT DETAILS 9.0 POSTAL ADDRESS Genpower Ltd, Isaac Way, London Road, Pembroke Dock, Pembrokeshire. SA72 4RW. UK. 9.1 TELEPHONE +44 (0) 1646 687880 9.2 FAX +44 (0) 0164 686198 9.3 WEBSITE www.hyundaipowerequipment.co.uk 14. MANUAL UPDATES 10.0 Our manuals are constantly being reviewed and updated. However if you find and error, omission or something you find unclear, please contact your dealer for assistance. - Page 28 POWER PRODUCTS Imported/Distributed by GENPOWER LTD Licensed by Hyundai Corporation, Korea...
