SUMAKE
Specification:
Free Speed
Capacity Bolt Size
Max. Torque
Working Torque
Air Consumption
Overall Length
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
3/8" Angle Impact Wrench
(Twin Hammer)
ST-IW7130
8,500 r/min
1/2" (13mm)
369 ft-lb (500 N-m)
332 ft-lb (450 N-m)
14 CFM (400 L/min)
3-1/2" (88mm)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
3.06 lbs (1.39 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
Under No load: 84.8 dB(A)
Under load: 90.1 dB(A)
No Load:
4.894 m/s²
Sound power level
Under No load: 95.8 dB(A)
Under load: 101.1 dB(A)
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
protector at
environment
noise level >
80 dB(A) due
Uncertainty
K= 3dB
ST-IW7130-S-2107B-YCF
Remark
wear ear
to risk of
impaired
hearing!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Sumake ST-IW7130
Summary of Contents for Sumake ST-IW7130
- Page 1 3/8” (10 mm) Air Hose (I.D.) to risk of impaired Uncertainty Uncertainty Air Pressure 90 psi (6.3 bar) hearing! ² K= 1.5 m/s K= 3dB Net Weight 3.06 lbs (1.39 kg) SUMAKE INDUSTRIAL CO., LTD 4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91 ST-IW7130-S-2107B-YCF...
- Page 2 DECLARATION OF CONFORMITY SUMAKE INDUSTRIAL CO., LTD. 4F, No. 351, Yangguang St., Neihu District, Taipei City, Taiwan declare in sole responsibility that the equipment Equipment： 3/8" ANGLE IMPACT WRENCH (TWIN HAMMER) Model/ Serial No.：ST-IW7130 to which this declaration applies, complies with these normative documents: ...
- Page 3 Foreword which indicated by 1 to 6. “ 1 ” indicates Coupler Recoil hose Leader Water the smallest torque output and “ 6 ” Su make is a manufacturer and exporter of air hose separation supply indicats the largest torque output. tools since established.
- Page 4 Reverse Lever IW7140-06 Anvil Collar [ST-IW7140] IW7140-36 Spring Pin IW7130-07 O-Ring [ST-IW7130] IW7140-37 Trigger IW7140-07 O-Ring [ST-IW7140] IW7140-38 IW7130-08 3/8" Dr. Anvil [ST-IW7130] IW7140-39 O-Ring IW7140-08 1/2" Dr. Anvil [ST-IW7140] IW7140-40 Set Screw IW7140-09 Hammer Pin IW7140-41 Shaft IW7140-10 Hammer Cage...
- Page 5 IMPACT WRENCH Original instructions SUMAKE Industrial Co. Ltd.
- Page 6 The tool has been manufactured in conformity with the instruction of EU machine directive. The EU mark will be considered void in the event of inexpert repairs, the use of non-original parts and in case of non-observance of the safety instructions in the user’s manual. Possible direct or indirect consequential damages are not the responsibility of SUMAKE Industrial co., Ltd. General safety rules: Watch the tool at all times when in use.
- Page 7 3. If the operator experiences symptoms such as persistent or recurring discomfort, pain, throbbing, aching, tingling, numbness, burning sensations or stiffness, these warning signs should not be ignored. The operator should tell the employer and consult a qualified health professional. Safety precautions for accessory hazards 1.
- Page 8 General preparation and connection: When using brand-new air hose or air pipe. Blow and clean the inside of air hose or pipe before installation. Keep inside of air hose or air pipe clean to prevent airdrop problem caused by the lots of drain and dust accumulated and possibly make the inside diameter smaller in the long use.
