Sumake ST-C5444 Quick Start Manual

1/2" air impact wrench twin hammer, composite housing
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
SUMAKE
Twin Hammer, Composite Housing
Specification:
Free Speed
Std. Bolt Size
Max. Torque
Working Torque
Overall Length
Air Consumption
Air Inlet (PT)
Air Hose (I.D.)
Air Pressure
Net Weight
SUMAKE INDUSTRIAL CO., LTD
4F,NO.351,Yangguang St.,Neihu District TAIPEI, TAIWAN, ZIP:114-91
PNEUMATIC TOOLS
1/2" Air Impact Wrench
ST-C5444
8,500 r/min
53/64" (M21)
1100 ft-lb (1491 N-m)
800 ft-lb (1080 N-m)
6.89" (175 mm)
17 CFM (480 L/min)
1/4" (6.35 mm)
3/8" (10 mm)
90 psi (6.3 bar)
3.6 lbs (1.65 kg)
Noise and Vibration:
Vibration
EN ISO 28927-2
Sound Pressure Level
under no load : 96.7 dB(A)
under load: 101.6 dB(A)
under load
:
8.29 m/s²
under no load: 107.7 dB(A)
under load: 112.6 dB(A)
Uncertainty
²
K= 1.5 m/s
Noise
EN ISO 15744
Please always
protector at
Sound power level
environment
noise level >
80 dB(A) due
Uncertainty
K= 3dB
ST-C5444-S-1805D-JUF
Remark
wear ear
to risk of
impaired
hearing!
