Supermicro SUPERSERVER 6022L-6 User Manual

Supermicro SUPERSERVER 6022L-6 User Manual

Supermicro superserver 6022l-6 servers: user guide
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S
®
UPER
S
S
6022L-6
UPER
ERVER
USER'S MANUAL
1.0b

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SUPERSERVER 6022L-6

Summary of Contents for Supermicro SUPERSERVER 6022L-6

  • Page 1 ® UPER 6022L-6 UPER ERVER USER’S MANUAL 1.0b...
  • Page 2 The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product. Unless you request and receive written permission from SUPER MICRO COMPUTER, you may not copy any part of this document.

  • Page 3: Preface

    Chapter 2: Server Installation This chapter describes the steps necessary to install the SuperServer 6022L-6 into a rack and check out the server configuration prior to power- ing up the system. memory components, this chapter will refer you to the appropriate sections of the manual for their installation.
  • Page 4 You should thoroughly familiarize yourself with this chapter for a general overview of safety precautions that should be followed when installing and servicing the SuperServer 6022L-6. Chapter 5: Advanced Motherboard Setup Chapter 5 provides detailed information on the P4DLR motherboard, includ- ing the locations and functions of connections, headers, jumpers and IRQs.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    Choosing a Setup Location ... 2-2 Rack Precautions ... 2-2 Server Precautions ... 2-2 Installing the SuperServer 6022L-6 into a Rack ... 2-3 Identifying the Sections of the Rack Rails ... 2-3 Installing the Chassis Rails ... 2-4 Installing the Rack Rails ... 2-4 Installing the Server into the Rack ...
  • Page 7 Power ... 3-3 SCSI Drive Carrier LEDs ... 3-3 Motherboard LED ... 3-3 Chapter 4: System Safety Electrical Safety Precautions ... 4-1 General Safety Precautions ... 4-2 ESD Precautions ... 4-3 Operating Precautions ... 4-4 Chapter 5: Advanced Motherboard Setup Handling the P4DLR Motherboard ...
  • Page 8 UPER ERVER 6022L-6 Manual Fan Headers ... 5-16 LAN1/LAN2 Ports ... 5-16 HD LED Indicator ... 5-17 Power LED ... 5-17 Speaker ... 5-17 Third Power Supply Fail Header ... 5-17 Wake-On-LAN ... 5-18 Chassis Intrusion ... 5-18 Sleep Button ... 5-18 IPMB ...
  • Page 9 Chapter 6: Advanced Chassis Setup Static-Sensitive Devices ... 6-1 Control Panel ... 6-2 System Fans ... 6-3 System Fan Failure ... 6-3 Replacing System Cooling Fans ... 6-3 Drive Bay Installation/Removal ... 6-4 Accessing the Drive Bays ... 6-4 SCSI Drive Installation ... 6-5 5 1/4"...
  • Page 10 UPER ERVER 6022L-6 User's Manual Notes...

  • Page 11: Chapter 1: Introduction To The Superserver 6022L-6

    SuperServer 6022L-6. (www.supermicro.com) In addition to the mainboard and chassis, various hardware components may have been included with your SuperServer 6022L-6, as listed below: Up to two (2) 603-pin Xeon 512k L2 cache processors* Two (2) CPU heatsinks* (Fan-042) Up to 12 GB ECC registered PC1600 DDR SDRAM main memory* One (1) 1.44"...

  • Page 12: Server Chassis Features

    * Type and number depends upon the configuration ordered. Server Chassis Features The SuperServer 6022L-6 is a high-end, scaleable 2U rackmount server platform designed with today's most state-of-the-art features. ing is a general outline of the main features of the SC822R-400RC chassis.

  • Page 13: Cooling System

    I/O Backplane The SC822R-400RC is a 2U rackmount chassis. Its I/O backplane provides three motherboard low profile expansion slots for the 6022L-6, one COM port (the other is internal), two USB ports, PS/2 mouse and keyboard ports and two Ethernet ports. (See Figure 1-1.)

  • Page 14: Mainboard Features

    UPER ERVER 6022L-6 Manual Mainboard Features At the heart of the SuperServer 6022L-6 lies the P4DLR, a dual Xeon pro- cessor motherboard designed to provide maximum performance. Below are the main features of the P4DLR. Chipset The P4DLR is based on the ServerWorks GC-LE chipset, which is a high- performance core logic chipset designed for dual-processor servers.

  • Page 15: Onboard Scsi

    PCI Expansion Slots The P4DLR has one 64-bit 133 MHz PCI-X slot. An active riser card (having its own I/O Controller Bridge) is included with the 6022L-6 that, along with the server backplane, accommodates up to three standard size PCI cards.

  • Page 16: Contacting Supermicro

    UPER ERVER 6022L-6 Manual Contacting Supermicro Headquarters Address: SuperMicro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: SuperMicro Computer B.V.

  • Page 17: Chapter 2: Server Installation

    Decide on a suitable location for the rack unit that will hold the SuperServer 6022L-6. It should be situated in a clean, dust-free area that is well venti- lated. Avoid areas where heat, electrical noise and electromagnetic fields are generated.

  • Page 18: Choosing A Setup Location

    UPER ERVER 6022L-6 Manual Choosing a Setup Location: - Leave enough clearance in front of the rack to enable you to open the front door completely (~25 inches). - Leave approximately 30 inches of clearance in the back of the rack to allow for sufficient airflow and ease in servicing.

  • Page 19: Installing The Superserver 6022L-6 Into A Rack

    This section provides information on installing the SuperServer 6022L-6 into a rack unit. If the 6022L-6 has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. There are a variety of rack units on the market, which may mean the assembly procedure will differ slightly.

  • Page 20: Installing The Chassis Rails

    Position the fixed chassis rail sections you just removed along the side of the 6022L-6 making sure the screw holes line up. Note that these two rails are left/right specific. Screw the rail securely to the side of the chassis (see Figure 2-2).

  • Page 21: Installing The Server Into The Rack

    Chapter 2: Server Installation bly to the other side of the rack, making both are at the exact same height and with the rail guides facing inward. Installing the Server into the Rack: You should now have rails attached to both the chassis and the rack unit.

  • Page 22: Installing The Server Into A Telco Rack

    ERVER 6022L-6 Manual Installing the Server into a Telco Rack: If you are installing the SuperServer 6022L-6 into a Telco type rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.

  • Page 23: Checking The Motherboard Setup

    Checking the Motherboard Setup After you install the 6022L-6 in the rack, you will need to open the unit to make sure the motherboard is properly installed and all the connections have been made. 1. Accessing the inside of the 6022L-6 (see Figure 2-5): First, release the retention screws that secure the unit to the rack.
  • Page 24 UPER ERVER 6022L-6 Manual Figure 2-5. Accessing the Inside of the SuperServer 6022L-6 (with one SCSI Drive removed)

  • Page 25: Checking The Drive Bay Setup

    6. Check all cable connections and airflow: Make sure all power and data cables are properly connected and not blocking the chassis airflow. See Chapter 5 for details on cable connec- tions. Checking the Drive Bay Setup Next, you should check to make sure the peripheral drives and the SCSI drives and SCA backplane have been properly installed and all connections have been made.
  • Page 26 UPER ERVER 6022L-6 Manual 5. Check the airflow: Airflow is provided by four 8-cm redundant cooling fans. component layout was carefully designed to promote sufficient airflow through the 2U rackmount space. cables have been routed in such a way that they do not block the airflow generated by the fans.

  • Page 27: Chapter 3: System Interface

    Overview There are several LEDs on the control panel as well as others on the SCSI drive carriers and the motherboard to keep you constantly informed of the overall status of the system as well as the activity and health of specific components.

  • Page 28: Control Panel Leds

    SUPERSERVER 6022L-6 User's Manual Control Panel LEDs The control panel located on the front of the SC822R-400RC chassis has five LEDs. These LEDs provide you with critical information related to dif- ferent parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 29: Hdd

    A SAF-TE compliant backplane is needed to activate the red LED, which indicates a drive failure. (A SAF-TE compliant SCSI backplane is standard on the 6022L-6.) If one of the SCSI drives fail, you should be notified by your system management software.
  • Page 30 SUPERSERVER 6022L-6 User's Manual Notes...

  • Page 31: Chapter 4: System Safety

    Electrical Safety Precautions Basic electrical safety precautions should be followed to protect yourself from harm and the SuperServer 6022L-6 from damage: ! Be aware of the locations of the power on/off switch on the chassis as well as the room's emergency power-off switch, disconnection switch or electrical outlet.

  • Page 32: General Safety Precautions

    General Safety Precautions Follow these rules to ensure general safety: ! Keep the area around the SuperServer 6022L-6 clean and free of clutter. ! The SuperServer 6022L-6 weighs approximately 58.5 lbs (26.6 kg) when fully loaded.

  • Page 33: Esd Precautions

    ! After accessing the inside of the system, close the system back up and secure it to the rack unit with the retention screws after ensuring that all connections have been made. ESD Precautions Electrostatic discharge (ESD) is generated by two objects with different electrical charges coming into contact with each other.

  • Page 34: Operating Precautions

    Operating Precautions Care must be taken to assure that the chassis cover is in place when the 6022L-6 is operating to assure proper cooling. Out of warranty damage to the 6022L-6 system can occur if this practice is not strictly followed.

  • Page 35: Chapter 5: Advanced Motherboard Setup

    Advanced Motherboard Setup This chapter covers the steps required to install processors and heatsinks, connect the data and power cables and install add-on cards. motherboard jumpers and connections are also described. quick reference chart are included in the chapter. Remember to close the chassis completely when you have finished working on the motherboard to protect and cool the system sufficiently.

  • Page 36: Pga Processor And Heatsink Installation

    UPERSERVER 6022L-6 User’s Manual PGA Processor and Heatsink Installation When handling the processor package, avoid placing direct pressure on the label area of the fan. Also, do not place the motherboard on a conductive surface, which can damage the BIOS battery and prevent the system from booting up.
  • Page 37 4. Apply the proper amount of thermal glue to the CPU die and place the heatsink/fan assembly on top of the CPU with the fan toward the rear of the chassis (note arrow on top of heatsink). 5. Secure the heatsink/fan assembly by locking the retention clips into their proper position.
  • Page 38 UPERSERVER 6022L-6 User’s Manual Figure 5-2. Heatsink Installation...

  • Page 39: Connecting Cables

    Connecting Cables Now that the processors and heatsinks are installed, the next step is to connect the cables to the board. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The ribbon cables used to transfer data from the peripheral devices have been carefully routed in preconfigured systems to prevent them from block- ing the flow of cooling air that moves through the system from front to back.

  • Page 40: Connecting The Control Panel

    UPERSERVER 6022L-6 User’s Manual Connecting the Control Panel JF1 contains header pins for various front control panel connectors. See Figure 5-3 for the pin locations of the various front control panel buttons and LED indicators. Please note that even and odd numbered pins are on opposite sides of each header.

  • Page 41: I/O Ports

    USB Ports (Purple) Figure 5-4. P4DLR Rear Panel I/O Ports Installing Memory Note: Check the Supermicro web site for recommended memory modules: http://www.supermicro.com/TECHSUPPORT/FAQs/Memory_vendors.htm Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Also note that the memory is interleaved to improve performance (see step 1).
  • Page 42 UPERSERVER 6022L-6 User’s Manual 3. Gently press down on the DIMM module until it snaps into place in the slot. Repeat for all modules (see step 1 above). Memory Support The P4DLR only supports ECC registered PC1600 (DDR-200) SDRAM memory.

  • Page 43: Adding Pci Cards

    Adding PCI Cards 64-bit PCI slot: The P4DLR system board has one 64-bit 133 MHz slot. The 6022L-6 includes an active riser card (part number CSE-RR2U-LE) solution that enables the use of three full-sized PCI cards. 64-bit PCI card installation: The system should be powered down when adding or removing PCI cards.

  • Page 44: Motherboard Details

    UPERSERVER 6022L-6 User’s Manual Motherboard Details Figure 5-7. SUPER P4DLR Layout Keyboard/Mouse USB0/1 Bank 3 Bank 3 COM1 Bank 2 Bank 2 Parallel Port Bank 1 Bank 1 UPER LAN2 LAN1 Rage XL LED2 LED1 JP56 JP55 JP54 AIC-7899 JPA1 Note: CR5 is a power LED indicator.
  • Page 45 P4DLR Quick Reference Jumper Description 33 MHz PCI Enable/Disable SCSI Enable/Disable JBT1 CMOS Clear Speaker Enable/Disable Watch Dog Enable/Disable JP4/P2 PCI-X Speed Settings JP48 Chassis/Overheat Fan Select JP54 LAN1 Enable/Disable JP55 LAN2 Enable/Disable JP56 VGA Enable/Disable JP58 CPU/Chassis Fan Select JPA1 SCSI Channel A Termination JPA2...

  • Page 46: Chipset Diagram

    UPERSERVER 6022L-6 User’s Manual Chipset Diagram ATI XL Graphics Processor 1 Processor 0 Ethernet Controller PCI-X Slot ATA 100 400 MHz Host Bus Ports CSB5 North Bridge CIOBX2 (South USB Ports (CMIC) (IO Bridge) Bridge) SMBus 200 MHz Memory Bus...

  • Page 47: Connector Definitions

    Connector Definitions ATX Power Connection power supply meets the SSI (Superset ATX) 24- pin specification, however it also supports a 20-pin power supply connector. Make sure that the ori- entation of the PS connector is correct. See the table on the right for pin definitions.

  • Page 48: Nic2 Led

    UPERSERVER 6022L-6 User’s Manual NIC2 LED The NIC2 (Network Interface Con- troller for LAN2) LED connection is located on pins 9 and 10 of JF1. Attach the NIC2 LED cable to dis- play network activity. Refer to the table on the right for pin defini- tions.

  • Page 49: Pwr_On

    PWR_ON The PWR_ON connection is lo- cated on pins 1 and 2 of JF1. Mo- mentarily contacting both pins will power on/off the system. button can also be configured to function as a suspend button (see the Power Button Mode setting in BIOS).

  • Page 50: Ps/2 Keyboard And Mouse

    UPERSERVER 6022L-6 User’s Manual Serial Ports The COM1 serial port is located under the parallel port (see Figure 2-3). See the table on the right for pin definitions. The COM2 connec- tor is a header located near the battery on the motherboard.

  • Page 51: Hd Led Indicator

    PWR_LED pin on JF1 to provide indication of a power failure on the chassis. Note: This feature is only available when us- ing triple redundant Supermicro power supplies. See the table on the right for pin definitions. Chapter 5: Advanced Motherboard Setup...

  • Page 52: Wake-On-Lan

    UPERSERVER 6022L-6 User’s Manual Wake-On-LAN The Wake-On-LAN header is des- ignated as WOL. See the table on the right for pin definitions. must enable the LAN Wake-Up set- ting in BIOS and also have a LAN card with a Wake-on-LAN connec- tor and cable to use this feature.

  • Page 53: Onboard Indicators

    Onboard Indicators LAN1/LAN2 LEDs Each of the Ethernet ports (located beside the VGA port) has a yellow and a green LED. See the table below for the functions associated with these LEDs. LED1/LED2 (Debug LEDs) The two surface-mounted debug LEDs (LED1 and LED2) are each com- posed of four individual LEDs, which are used to provide POST code infor- mation.

  • Page 54: Cr5 Led

    UPERSERVER 6022L-6 User’s Manual CR5 LED CR5 is an onboard LED that serves as a power indicator. table on the right for the menaing of each of the three colors dis- played by CR5. 5-10 DIP Switch Settings DIP Switch 4: Processor Speed The red "DIP"...

  • Page 55: 5-11 Jumper Settings

    5-11 Jumper Settings Explanation of Jumpers To modify the operation of the motherboard, jumpers can be used choose optional settings. create shorts between two pins to change the function of the connector. Pin 1 is identified with a square solder pad on the printed circuit board.

  • Page 56: Speakerenable/Disable

    UPERSERVER 6022L-6 User’s Manual SpeakerEnable/Disable You may want to disable the onboard speaker. done by putting a jumper on pins pins 10 and 11 of J69. VGA Enable/Disable JP56 allows you to enable or dis- able the VGA port. position is on pins 1 and 2 to en- able VGA.

  • Page 57: Lan1 Enable/Disable

    LAN1 Enable/Disable Change the setting of jumper JP54 to enable or disable the onboard LAN1 or NIC (Network Interface Card) on the motherboard. the table on the right for jumper settings. The default setting is pins 1-2. LAN2 Enable/Disable Change the setting of jumper JP55 to enable or disable the onboard LAN2 or NIC (Network Interface Card) on the motherboard.

  • Page 58: 33 Mhz Pci Enable/Disab;E

    UPERSERVER 6022L-6 User’s Manual 33 MHz PCI Enable/Disable If you wish to use 33 MHz PCI cards, close JP4 to force (enable) the P1 bus to run at 33 MHz. See the table on the right for jumper set- tings.

  • Page 59: Floppy Connector

    Floppy Connector The floppy connector is located on JP12. See the table below for pin definitions. IDE Connectors There are no jumpers to configure the onboard IDE#1 and #2 connectors (J18 and J19, respectively). See the table on the right for pin definitions.

  • Page 60: Ultra160 Scsi Connectors

    UPERSERVER 6022L-6 User’s Manual Ultra160 SCSI Connector Refer to the table below for the pin definitions of the Ul- tra160 SCSI connectors lo- cated at JA1, JA2 and JA5. 68-pin Ultra160 SCSI Connectors (JA1, JA2, JA5) Connector Contact Number Connector...

  • Page 61: 5-13 Installing Software Drivers

    Chapter 5: Advanced Motherboard Setup 5-13 Installing Software Drivers After all the hardware has been installed you must install the software drivers. The necessary drivers are all included on the Supermicro CD that came packaged with your motherboard. After inserting this CD into your CD-ROM drive, the display shown in Figure 5-8 should appear.
  • Page 62 UPERSERVER 6022L-6 User’s Manual Notes 5-28...

  • Page 63: Chapter 6: Advanced Chassis Setup

    Advanced Chassis Setup This chapter covers the steps required to install components and perform maintenance on the SC822R-400RC chassis. follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the step that follows.

  • Page 64: Control Panel

    UPER ERVER 6022L-6 Manual SCSI Drives (6) USB Ports Power Supplies (2) Mouse/Keyboard Ports Figure 6-1. Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the motherboard to provide you with system status indications.

  • Page 65: System Fans

    Replace the failed fan with an identical 8-cm, 12 volt fan (available from Supermicro). Position the new fan at its proper place in the chassis by fitting the fan with its housing onto the fan mounts in the chassis. A "click"...

  • Page 66: Drive Bay Installation/Removal

    SuperServer 6022L-6. CD-ROM/Floppy Disk Drive: For installing/removing the CD-ROM or floppy disk drive, you will need to gain access to the inside of the 6022L-6 by removing the top cover of the chassis. Proceed to the "CD-ROM and Floppy Drive Installation" section later in this chapter for instructions.

  • Page 67: Scsi Drive Installation

    SCSI Drive Installation Mounting a SCSI drive in a drive carrier: The SCSI drives are mounted in drive carriers to simplify their installation and removal from the chassis. These carriers also help promote proper airflow for the SCSI drive bays. For this reason, even empty carriers without SCSI drives installed must remain in the chassis to cool each drive equally.
  • Page 68 UPER ERVER 6022L-6 Manual Installing/removing hot-swap SCSI drives: The SCSI drive bays are located in the front of the chassis, making them easily accessible for installation and removal. The SCSI drives are hot- swap units, meaning that they can be installed and removed while the system is running.
  • Page 69 Chapter 6: Advanced Chassis Setup SCA Backplane The SCSI drives plug into a SAF-TE compliant SCA backplane that provides power, SCSI ID and bus termination. A RAID controller can be used with the SCA backplane to provide data security. The operating system you use must have RAID support to enable the hot-swap capability of the SCSI drive.
  • Page 70 CD-ROM and Floppy Drive Installation The top cover of the chassis must be opened to gain full access to the CD- ROM and floppy drive bays. The 6022L-6 accomodates only slim-line CD- ROM drives. Side mounting brakets are typically needed to mount a slim-line CD-ROM drive in the 6022L-6 server.

  • Page 71: Power Supply

    Power Supply The SuperServer 6022L-6 has two 400 watt hot-swap power supply modules. These power supply modules have an auto-switching capabil- ity, which enables them to automatically sense and operate at any input voltage between 110 and 220V. Power Supply Failure...
  • Page 72 UPER ERVER 6022L-6 Manual Notes 6-10...

  • Page 73: Chapter 7: Amibios

    Introduction This chapter describes the AMIBIOS for the P4DLR. The AMI ROM BIOS is stored in a Flash EEPROM and can be easily upgraded using a floppy disk- based program. Note: Due to periodic changes to BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 74: Bios Features

    UPER ERVER 6022L-6 Manual BIOS Features • Supports Plug and Play V1.0A and DMI 2.3 • Supports Intel PCI (Peripheral Component Interconnect) (PME) local bus specification 2.2 • Supports Advanced Power Management (APM) specification v 1.1 • Supports ACPI •...

  • Page 75: The Main Bios Setup Menu

    The Main BIOS Setup Menu Press the <Delete> key during the POST (Power On Self Test) to enter the Main Menu of the BIOS Setup Utility. All Main Setup options are described in this section. The Main BIOS Setup screeen is displayed below. Main Advanced Chipset...

  • Page 76: Advanced Bios Setup

    UPER ERVER 6022L-6 Manual Advanced BIOS Setup Choose Advanced BIOS Setup from the AMIBIOS Setup Utility main menu with the Left/Right arrow keys. You should see the following display. Select one of the items in the left frame of the screen, such as SuperIO Configuration, to go to the sub screen for that item.

  • Page 77: Super Io Configuration

    Super IO Configuration Advanced Configure Winbond627F Serial Port(s) and Parallel P Serial Port1 Address Serial Port1 IRQ Serial Port2 Address Serial Port2 IRQ Serial Port2 Mode Parallel Port Address Parallel Port IRQ Parallel Port Mode ECP Mode DMA Channel V07.00 (C)Copyright 1985-2001, American Megatrends, Inc. The Super IO Configuration includes the following items: Serial Port 1 Address This option specifies the base I/O port address of serial port 1.

  • Page 78: Ide Configuration

    UPER ERVER 6022L-6 Manual Serial Port 2 Mode Use this option to choose the Serial Port 2 Mode. The settings are Normal, Sharp-IR, SIR and consumer. Parallel Port Address This option specifies the I/O address used by the parallel port. The settings for this item include Disabled, 378, 278 and 3BC.
  • Page 79 Primary IDE Master When entering "Setup", BIOS automatically detects the presence of IDE devices. This displays the auto detection status of the IDE de- vices. You can also manually configure the IDE drives by providing the following information: This option allows the user to configure the IDE devices. When the desired item is highlighted (selected), press "Enter"...
  • Page 80 UPER ERVER 6022L-6 Manual PIO Mode IDE PIO (Programmable I/O) mode programs timing cycles between the IDE drive and the programmable IDE controller. As the PIO mode in- creases, the cycle time decreases. The settings are: Auto, 0, 1, 2, 3 and 4.
  • Page 81 Chapter 7: AMIBIOS Primary IDE Slave When the system enters "Setup", BIOS automatically detects the presence of IDE devices. This option displays the auto detection status of IDE de- vices. The settings for "Primary IDE Slave" are the same as those for the "Primary IDE Master".

  • Page 82: Floppy Configuration

    UPER ERVER 6022L-6 Manual Floppy Configuration Floppy A Use this option to specify which of floppy drive you have installed in the A drive. The settings are Disabled, 360 KB 5 1/4", 1.2 MB 5 1/4", 720 KB 3 1/ 2", 1.44 MB 3 1/2"...
  • Page 83 Chapter 7: AMIBIOS allows the computer to force a third party BIOS to display during system boot. Keep Current has the system display AMIBIOS information on bootup. BootUp Num Lock This option is used to select the status of the Number Lock function on your keyboard on bootup.
  • Page 84 UPER ERVER 6022L-6 Manual Wait for F1 if Error This settings for this option are Enabled and Disabled. Disabled: This prevents the AMIBIOS to wait on an error for user intervention. This setting should be used if there is a known reason for a BIOS error to appear. An example would be a system administrator must remote boot the system.

  • Page 85: Event Log Configuration

    Chapter 7: AMIBIOS Event Log Configuration Event Logging This option Enables or Disables the logging of events. You can use this screen to select options for the Event Log Configuration Settings. You can access sub screens to view the event log and mark all events as read. Use the up and down arrow keys to select an item, and the plus (+) and minus (-) keys to change the option setting.

  • Page 86: Peripheral Device Configuration

    UPER ERVER 6022L-6 Manual Peripheral Device Configuration Onboard SCSI Option - ROM This option gives you the ability to boot up the system from a SCSI device. The settings are Enabled and Disabled. Onboard LAN1 Option - ROM This option gives you the ability to boot up the system from a LAN1 device.
  • Page 87 Chapter 7: AMIBIOS Overheat Warning Temperature This option allows you to specify the temperature threshold that, when exceeded, will trigger the overheat warning alarm. The rest of the System Health Monitor menu lists various voltages and tem- peratures as they are currently being measured. These include CPU tem- perature, CPU voltage and the rpms of the CPU fans.

  • Page 88: Chipset Setup

    UPER ERVER 6022L-6 Manual Chipset Setup Choose Chipset Setup from the AMIBIOS Setup Utility main menu. The screen is shown below. All Chipset Setup options are described following the screen. Main Advanced Chipset C000,16k Shadow C400,16k Shadow C800,16k Shadow CC00,16k Shadow...
  • Page 89 Chapter 7: AMIBIOS for faster application. The settings for this option are Disabled and Enabled. (The optimal settings are Cached for C000, C400, C800 anc CC00 and Disabled for all the other addresses. Memory Auto Precharge The options for this setting are Enabled and Disabled. Write Combining This settings for this option are Disabled and Enabled.

  • Page 90: Pci Pnp Setup

    UPER ERVER 6022L-6 Manual Hide XIOAPIC PCI Functions The settings for this option are Yes and No. Watchdog Timer This option is used to configure the Watchdog timer. abled, 2 minutes, 5 minutes, 10 minutes and 15 minutes. PCI PnP Setup Choose PCI/PnP Setup from the AMIBIOS Setup main menu.
  • Page 91 Chapter 7: AMIBIOS Plug & Play OS This option specifies how Plug and Play devices will be configured. settins are Yes and No. No lets BIOS configure all devices in the system. Yes lets the operating system (if supported) configure PnP devices not required for bootup.

  • Page 92: Power Setup

    UPER ERVER 6022L-6 Manual Legacy USB Support This option allows you to enable support for Legacy USB. The settings are Auto, Enabled and Disabled. ARMD Emulation Type This settings for this option are Hard Disk, Auto and Floppy. Power Setup Choose Power Setup from the AMIBIOS Setup main menu.
  • Page 93 ACPI Aware O/S This option allows the system to utilize Intel's ACPI (Advanced Configuration and Power Interface) specification. Windows 3.x®, and Windows NT® are examples of non-ACPI aware oper- ating systems. Windows 95®, Windows 98®, Windows ME® and Windows 2000® are examples of ACPI aware operating systems. Power Management When enabled, this option displays the following four options relating to power management.

  • Page 94: Boot Setup

    UPER ERVER 6022L-6 Manual Boot Setup Choose Boot Setup from the AMIBIOS Setup main menu. options are described in this section. below. Main Advanced Chipset > Boot Device Priority > Hard Disk Drives > Removable Devices > ATAPI CDROM Drives V02.03 (C)Copyright 1985-2000, American Megatrends, Inc.
  • Page 95 3rd Boot Device The settings for the 3rd Boot Device are Removable Device, ATAPI CDROM, Hard Drive, Onboard LAN2 Option-ROM and IBA 4.0.1.9 Slot 0102. 4th Boot Device The settings for the 4th Boot Device are Removable Device, ATAPI CDROM, Hard Drive, Onboard LAN2 Option-ROM and IBA 4.0.1.9 Slot 0102.

  • Page 96: Security Setup

    UPER ERVER 6022L-6 Manual Security Setup Choose Security Setup from the AMIBIOS Setup main menu. All Security Setup options are described in this section. The Security Setup screen is shown below. Main Advanced Chipset Supervisor Password User Password > Change Supervisor Password >...
  • Page 97 Change Supervisor Password This option allows you to change a supervisor password that was entered previously. Change User Password This option allows you to change a user password that was entered previ- ously. Clear User Password Use this option to clear the user password so that it is not required to be entered when the system boots up.

  • Page 98: 7-10 Exit Setup

    UPER ERVER 6022L-6 Manual 7-10 Exit Setup Choose Exit Setup from the AMIBIOS Setup main menu. All Exit Setup op- tions are described in this section. The Exit Setup screen is shown below. Main Advanced Chipset > Exit Saving Changes >...
  • Page 99 Chapter 7: AMIBIOS Load Optimal Defaults Highlighting this setting and then pressing <Enter> provides the optimum performance settings for all devices and system features. Load Failsafe Defaults Highlighting this setting and then pressing <Enter> provides the safest set of parameters for the system. Use them if the system is behaving errati- cally.
  • Page 100 UPER ERVER 6022L-6 Manual Notes 7-28...

  • Page 101: Appendix A: Amibios Error Beep Codes

    AMIBIOS Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process. The error messages normally appear on the screen.
  • Page 102 UPER ERVER 6022L-6 Manual Notes...

  • Page 103: Appendix B: Amibios Post Codes

    AMIBIOS POST Codes When AMIBIOS performs the Power On Self Test, it writes diagnostic codes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, diagnostic equipment can be attached to the computer to read I/O port 0080h. Uncompressed Initialization Codes The uncompressed initialization checkpoint codes are listed in order of execution: Checkpoint...
  • Page 104 UPER ERVER 6022L-6 Manual Bootblock Recovery Codes The bootblock recovery checkpoint codes are listed in order of execution: Checkpoint Code Description The onboard floppy controller if available is initialized. Next, beginning the base 512 KB memory test. Initializing the interrupt vector table next.
  • Page 105 initialization before the keyboard BAT command is issued. The keyboard controller input buffer is free. Next, issuing the BAT command to the keyboard controller. The keyboard controller BAT command result has been verified. Next, performing any necessary initialization after the keyboard controller BAT command test.
  • Page 106 UPER ERVER 6022L-6 Manual Checkpoint Code Description Interrupt vector initialization is done. Clearing the password if the POST DIAG switch is on. Any initialization before setting video mode will be done next. Initialization before setting the video mode is complete. Configuring the monochrome mode and color mode settings next.
  • Page 107 Checkpoint Code Description Patterns written in base memory. Determining the amount of memory below 1 MB next. The amount of memory below 1 MB has been found and verified. Determining the amount of memory above 1 MB memory next. The amount of memory above 1 MB has been found and verified. Checking for a soft reset and clearing the memory below 1 MB for the soft reset next.
  • Page 108 UPER ERVER 6022L-6 Manual Checkpoint Code Description The DMA page register test passed. Performing the DMA Controller 1 base register test next. The DMA controller 1 base register test passed. Performing the DMA controller 2 base register test next. The DMA controller 2 base register test passed. Programming DMA controllers 1 and 2 next.
  • Page 109 Checkpoint Code Description Initializing the bus option ROMs from C800 next. See the last page of this chapter for additional information. Initializing before passing control to the adaptor ROM at C800. Initialization before the C800 adaptor ROM gains control has com- pleted.
  • Page 110 UPER ERVER 6022L-6 Manual Notes...

  • Page 111: Appendix C: System Specifications

    2.20 GHz and faster at a front side (system) bus speed of 400 MHz. Note: Please refer to the support section of our web site for a complete listing of supported processors. (http://www.supermicro.com/TechSupport.htm) Chipset ServerWorks GC-LE chipset BIOS ®...
  • Page 112 UPER ERVER 6022L-6 Manual Expansion Slots One (1) 64-bit 133/100 MHz PCI-X slot on motherboard. An active riser card enables the use of three standard size PCI cards. Power Supply Type: 2 x 400W with +3.3V, +5V, +12V, -5V and -12V main DC...
