- Page 1 OWNER'S OPERATING AND MAINTENANCE MANUAL 8500 Treatment Table 8570 Treatment Table with 8550 Adjustable Headrest Recovery Couch Treatment Tables 1-800-237-3377 CHAMPIONCHAIR.COM Document No. 006055 Rev A...
- Page 2 Champion assumes no responsibility for damage or injury caused by improper assembly, instal- lation, use, or maintenance of these products. No part of this manual may be duplicated in any form without the prior consent of Champion Manufacturing, Inc . Unauthorized duplication/distribution of these materials may result in civil prosecution to the maximum extent allowed by law.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important Safety Information ..................... 4 Transportation, Storage, Handling & Disposal ................ 5 Tools Required ..........................5 8500 Treatment Table ........................6 Table Assembly ........................6 Optional Shelf Installation ..................... 6 Parts Reference ......................... 7 8550 Recovery Couch ........................8 Table Assembly ........................ -
Page 4: Important Safety Information
4. NEVER leave an unconscious user unattended on table or INJURY MAY OCCUR. 5. DO NOT use table for transporting user in or with ANY type of vehicle or trailer. Champion tables have not been tested or approved for use by an occupant in any type of vehicle or trailer. -
Page 5: Transportation, Storage, Handling & Disposal
• The product should be stored in an environment that will inhibit rust/mold formation. • Champion Manufacturing, Inc recommends not leaving the product in the factory packing in excess of three (3) months. • The product should always be handled in a manner consistent with the user instructions and in a manner to prevent contamination after each use. -
Page 6: 8500 Treatment Table
8500 TREATMENT TABLE TABLE ASSEMBLY REFER TO “Parts Reference” photo on page 7 for visual reference during table assembly. 1. After checking your product for any shipping damage, the table needs to be positioned upside-down on cardboard or protective surface. Remove all packing material and hardware that was secured for shipping. ... -
Page 7: Parts Reference
Pierce another hole in the strap to give desired tension and re-insert screw. Wrinkles in Vinyl – Storage and shipping can cause wrinkles of the vinyl on your Champion table. •... -
Page 8: 8550 Recovery Couch
8550 TREATMENT TABLE TABLE ASSEMBLY REFER TO “Parts Reference” photo on page 9 for visual reference during table assembly. 1. After checking your product for any shipping damage, the table needs to be positioned upside-down on cardboard or protective surface. Remove all packing material and hardware that was secured for shipping. Cut tape on corners of box so that cardboard will lay flat while you assemble table. -
Page 9: Parts Reference
Pierce another hole in the strap to give desired tension and re-insert screw. Wrinkles in Vinyl – Storage and shipping can cause wrinkles of the vinyl on your Champion table. •... -
Page 10: 8570 Treatment Table With Adjustable Headrest
8570 TREATMENT TABLE WITH ADJUSTABLE HEADREST TABLE ASSEMBLY REFER TO “Parts Reference” photo on page 12 for visual reference during table assembly. 1. After checking your product for any shipping damage, the table needs to be positioned upside-down on the cardboard shi pping container, or protective surface. -
Page 11: Optional Shelf Installation
Pierce another hole in the strap to give desired tension and re-insert screw. Wrinkles in Vinyl – Storage and shipping can cause wrinkles of the vinyl on your Champion table. •... -
Page 12: Adjusting The Gas Spring
ADJUSTING THE GAS SPRING (THE CYLINDER UNDER HEADREST) 1. Remove Cable from Operator. 2. Loosen the 11/ 1 6” locking nut (jam nut) on top of the Operator with a wrench. 3. Remove the Bow-Tie Cotter Pin from the Clevis Pin. 4. -
Page 13: Parts Reference
PARTS REFERENCE Page 13 of 17 manual Document No.: 006055 - Revision: a... -
Page 14: General Care & Cleaning
Periodically inspect tightness of all screws, bolts, nuts, or other fasteners. Champion furnishings are built to provide durable reliable service when properly cared for. In general all of our products should be: 1) Cleaned, 2) Rinsed and 3) Allowed to air dry. It is important to note that disinfecting a product is not the same as cleaning the product. -
Page 15: Specifications
In all cases the labeling on the table or product at the time of delivery indicates the correct rating for your table or product – Weight rating should not be exceeded! 8550 SPECIFICATIONS Recovery Couch 8500 Treatment Table 8570 Treatment Table with Adjustable Headrest... - Page 16 We reserve the right to add or delete products at any time and without prior notice. Always provide your product's specific serial number when ordering any replacement parts. When in doubt, contact a Champion representative (352-854-2929 or 1-800-237-3377) for further information.
- Page 17 Information contained in this document is based on the latest product data available at the time of printing. Photography, artwork, text and specifications are subject to change. Photographs may show optional items. Champion Manufacturing Inc. reserves the right to make changes to products, materials, options, and/or specification at any time without notice or obligation. Always provide your product's specific serial number when ordering replacement parts.
