Axis Q1715 User Manual page 15

AXIS Q1715 Block Camera
Configure your device
Create the preset positions:
1. Go to PTZ > Preset positions.
2. Create the home position that includes the entrance of the gate.
3. Create the zoomed-in preset position so that it covers the area in the image where you assume that the license plate
will appear.
Create a rule:
1. Go to System > Events and add a rule.
2. Name the rule "Gatekeeper".
3. In the list of actions, under Preset positions, select Go to preset position.
4. Select a Video channel.
5. Select the Preset position.
6. To make the camera wait a while before it returns to the home position, set a time for Home timeout.
7. Click Save.
Record video when the camera detects impact
Shock detection allows the camera to detect tampering caused by vibrations or shock. Vibrations due to the environment or to an
object can trigger an action depending on the shock sensitivity range, which can be set from 0 to 100. In this scenario, someone is
throwing rocks at the camera after hours and you would like to get a video clip of the event.
Turn on shock detection:
1. Go to System > Detectors > Shock detection.
2. Turn on shock detection, and adjust the shock sensitivity.
Create a rule:
3. Go to System > Events > Rules and add a rule.
4. Type a name for the rule.
5. In the list of conditions, under Device status, select Shock detected.
6. Click + to add a second condition.
7. In the list of conditions, under Scheduled and recurring, select Schedule.
8. In the list of schedules, select After hours .
9. In the list of actions, under Recordings, select Record video while the rule is active.
10. Select where to save the recordings.
11. Select a Camera.
12. Set the prebuffer time to 5 seconds.
13. Set the postbuffer time to 50 seconds.
14. Click Save.
