LOADING PAPER
3
Store the pressure plate lock which has been removed in step
2. To store the pressure plate lock, rotate the lock to secure it
as shown below.
4
Fan the paper and insert it into the tray. Make sure that the
edges go under the corner hooks.
Note
5
Gently push the paper tray back into the machine.
Note
20
Pressure plate lock
• Do not load paper above the maximum height line (
Exceeding the line will cause a paper misfeed.
• If the paper is not fanned, double-feeds or misfeeds may occur.
• Make sure the stack of paper is straight before loading it. When
adding paper, take the remaining paper out and combine it into a
single stack with the new paper.
• Make sure that all the paper in the stack is the same size and type.
• When loading paper, ensure that there is no space between the
paper and the guide, and make sure that the guide is not set too
narrow and causes the paper to bend. Incorrect loading will cause the
paper to skew or misfeed.
• If you loaded a paper size that is different from the previously loaded
paper size, change the paper size setting as explained in
"CHANGING A TRAY'S PAPER SIZE SETTING" (p.23)
• When not using the machine for an extended period, remove all
paper from the paper tray and store it in a dry place. If paper is left in
the machine for an extended period, the paper will absorb moisture
from the air, resulting in paper jams.
).
