RM22-308
TOP COVER
1
BOTTOM CHASSIS
2
OPTIONAL POWER SUPPLY
3
Hot-swap 80x38CM FANS
4
ODD DRIVE CAGE
5
2.5" DRIVE CAGE
6
2.5"/3.5" HDD TRAY
7
FRONT PANEL IO AND INDICATORS
8
RACK HANDLES
9
2. Removing the top cover
Press and hold the top cover's two buttons while pushing the cover
towards the rear of the chassis to remove it.
Front panel I/O and indicators
USB 2.0 x1
1
USB 3.1 x1
2
Power button
3
System reset button
4
WWW.SILVERSTONETEK.COM
3. Install motherboard
1. Install rackmount ears
Please install rackmount ears as the last step right before integrating the
Power LED
5
chassis into the rackmount. If you plan on shipping the chassis, please remove
rackmount ears.
HDD LED
6
LAN LED 1
7
LAN LED 2
8
4. Install power supply
4-1 If installing 2U redundant power supply, place it into the chassis
and secure with screws
