Guldmann GLS5.2 User Manual

Active lifter
Hide thumbs Also See for GLS5.2:
Table of Contents

Advertisement

Quick Links

Download this manual
GB/US . . . . GLS5 .2 Active lifter
User manual – vers . 102 .0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GLS5.2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Guldmann GLS5.2

Summary of Contents for Guldmann GLS5.2

  • Page 1 GB/US . . . . GLS5 .2 Active lifter User manual – vers . 102 .0...

  • Page 2: Table Of Contents

    4.01 ..Where to use GLS5.2 ......
  • Page 3 16 .00 . . . . . . . . Environmental policy statement - V . Guldmann A/S . . . . . . .

  • Page 4: Manufacturer

    4 .00 Conditions for use GLS5.2 is a mobile active lifter which is designed to assist the user from a sitting to a standing position. It can also be used to assist the user in the toilet procedure or the beginning of the rehabilitation process. The lifter is suitable for lifting or moving a person who is capable of actively participating in the process, the user must also have good communication skills.

  • Page 5: Where To Use Gls5.2

    4 .01 Where to use GLS5 .2 GLS5.2 is designed to be used in hospitals, nursing homes, institutions and private homes. It can be used indoors whenever the user needs to be lifted or moved on a level surface. • The lifter is designed so its legs can fit under beds, around chairs / wheelchairs.

  • Page 6: Important

    • The lifter should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, the lifter should be observed to verify normal operation in the configuration in which it will be used. • In case the battery is too hot, disconnect it, evacuate the room, and wait for 2 hours before taking further steps •...

  • Page 7: Definitions

    11. Calf strap 12. Knee pad 13. Lifting actuator 14. Knee pad height adjustment knob 15. Knee pad length adjustment knob 16. Foot plate 17. Chassis leg 18. Brake/release 19. Foot bar Accessories can be found in the Guldmann product catalog...

  • Page 8: Accessories For The Lifter

    Service Team. 6 .01 Assembly instruction Guldmann recommends that the person making the assembly of the Active Lifters have a basic mechanical understanding. Unpack the lifter on to a level surface and gently remove cable ties and protective-foam. Assembling mast/chassis Insert the mast (pos.
  • Page 9 Fitting actuator Fasten the lifting actuator base (pos. 4) on to the mast by inserting the Pipe (pos. 5), secure bolt (pos. 6) and locknut (pos. 7) by tightening them. Complete by adding protective plastic caps (pos. 8) to not and bolt. Actuator motor housing must face right seen from the front.
  • Page 10 Mounting of the hand control Connect the hand control to the DIN port on the control box (pos. 12). Push cable cover back on directly over designated snaps. Fasten push handle (pos. 13) to mast by tightening the Two screws (pos. 14). Attach on the footrest (pos.

  • Page 11: Checklist Before Use

    Secure the knee pad with the adjustment knob (pos. 19). 6 .02 Checklist before use • The lifter must be off charge. • Before first use the service indicator must be reset, done by pressing up and down button at the same time for 5 seconds. • Check the lifter is lifting and lowering and the legs are opening and closing, if you hear the audio warning (a beeping sound) DO NOT USE THE LIFTER –...

  • Page 12: Charging And Installing Battery

    • Release the sling straps and move the lifter away from the user. • The sling is ready for removal - see sling user guide. Working with the Active lifter Always maintain a good working posture when applying the sling or working with the lifter.

  • Page 13: Operation

    DOWN arrow on the hand control or the control box. • On GLS5.2 mobile lifter the leg spread width adjustment of the chassis is operated via the sideways arrows on the hand control. To switch between modes on hand control, one button needs to be released before activating the next.

  • Page 14: Indicator Lamps And Audio Signals

    7 .01 Indicator lamps and audio signals Status Indicator lamps Audio signals Possible GLS5.2 signals Down Leg spread Emergency down Hand control Battery charged 75-100% 3 Green lights Battery charged 50-75% 2 Green lights Battery charged <50% 1 Green light...
  • Page 15 LED 1 - LED 2 - LED 3 LED state (Not listed = off) States while charging LED 1 - 3 constantly on 90 - 100% LED 1 + 2 constantly on 65 - 90% LED 3 flashes slowly LED 1 constantly on 40 - 65% LED 2 flashes slowly LED 1 flashes slowly 0 - 40% LED 1 + 2 + 3 flash slowly Charging stopped due to low battery...
  • Page 16 States in LED state (Not PRIORITY LED 4 + LED 5 normal Comments Reset listed = off) usecharging LED 4 flashing Pairing Not ready to Wait until according to Bluetooth drive ready Bluetooth pairing state* LED 4+5 con- Emergency Not ready to Reactivate stantly on stop activated drive emergency...

  • Page 17: Safety Functions

    7 .02 Safety functions Only use the emergency stop button and emergency lowering functions in emergencies. If it has been necessary to apply the emergency/safety func- tions due to an error on the lifter, the supplier must be contacted prior to using the lifter again.

  • Page 18: Use Of Active Lifter

    Use of foot bar The foot bar is there to assist the helper to initi- ate movement, and to facilitate the clearing of door thresholds, without a patient in the lifter or to assist loading into vehicles. This is achieved by placing one foot onto the foot bar and gently pulling back on the push handle.

  • Page 19: Cleaning And Disinfection

    1500 ppm. If other chemicals and/or liquids with higher resolution should be used to clean or disinfect these products, please contact Guldmann providing the item´s safety sheet chemical composition for consideration. Caution: Take great care to ensure that no liquids get inside the lift.

  • Page 20: Troubleshooting

    Yes replace hand control No fit connector Are the connectors for the lifting motor and/or leg adjustment motor fitted? Yes see point 5 No fit connector Contact the Guldmann Service Team if the fault cannot be found and corrected.

  • Page 21: Service And Lifespan

    Guldmann Service Team. At the end of the expected life span, the lifter must then be assessed by q ualified service staff as to the lifters future use. The lifespan of the lifting actuator is determined by how regular the lifter is used.

  • Page 22: Environmental Conditions

    11 .00 Environmental conditions Operation The products operational environment: – Operation temperatures between 10 and +35°C / 50 and 95°F – A relative air humidity of between 30 and 70 % – An air pressure of between 700 and 1060 hPa For safety reasons, please adhere to indicated charging and operation tem- perature.
  • Page 23 Loosen the knob and lift the mast from the base. How to pack the lifter for transport Guldmann recommends that the dismantled lifter is always transported in its original packaging. Storage of active lifter The active lifter should be stored in a dry room. The active lifter must neve be stored in bathrooms and similar areas.

  • Page 24: Technical Specifications

    12.00 Technical specifications...
  • Page 25 Functions Lifting capacity, max ........155/205 kg Operation Lift .

  • Page 26: Product Configuration Table

    Scale Service User lifter type line module module module type type functions interface GLS5.2 GLS5.2 Example: GLS5.2 205 560 000 GLS5.2 Manual emergency down, motor turned 90° Castor size ø75/ø125 mm Safe Working Load SWL: 205 kg Lifter, type GLS5.2...

  • Page 27: Labelling

    14 .00 Labelling Pictograms/labels used on product Read the manual before use CE-marking Medical Device Class I in accordance with EU MDR Regulation Type B in accordance with EN 60601-1 Battery condition and charging Must not be disposed of as standard household waste, but must be recycled. Lifting boom vertical up and down movement Leg adjustment...
  • Page 28 Examples of labels Serial number label GLS5.2 (xxxx) xxx xxx xxxx max xxx kg / xxx lbs xxxxxx Duty Cycle max: 10% 2 min/18 min xxxxx V. Guldmann A/S Graham Bells Vej 21-23A 8200 Aarhus N, Denmark yyyy-mm-dd GS1-128 Hand control...

  • Page 29: Eu-Declaration Of Conformity

    Guidance and manufacturer’s declaration – electromagnetic emissions The GLS5.2 is intended for use in the electromagnetic environment specified below. The customer or the user of the GLS5.2 should assure that it is used in such an environment. Emissions test Compliance Electromagnetic environment –...
  • Page 30 Guidance and manufacturer’s declaration – electromagnetic immunity The GLS5.2 is intended for use in the electromagnetic environment specified below. The customer or the user of the GLS5.2 should assure that it is used in such an environment. IMMUNITY test IEC 60601...
  • Page 31 Guidance and manufacturer’s declaration – electromagnetic immunity The GLS5.2 is intended for use in the electromagnetic environment specified below. The customer or the user of the GLS5.2 should assure that it is used in such an environment. IMMUNITY test IEC 60601 TEST...
  • Page 32 RF communications equipment and the GLS5.2 The GLS5.2 is intended for use in an electromagnetic environment in which radiated RF disturbances are con- trolled. The customer or the user of the GLS5.2 can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the GLS5.2 as recommended below, according to the maximum output power of the communications equipment.
  • Page 33 Warranty Period. In the event the warranty is rendered null and void, the purchaser shall indemnify and hold Guldmann harmless of and from any and all claims or liability arising as a result of equipment malfunction or misuse.
  • Page 36 V . Guldmann A/S Corporate Office: Tel. +45 8741 3100 info@guldmann.com www.guldmann.com Guldmann Inc . Tel. 800 664 8834 Tel. 813 880 0619 Fax 813 880 9558 info@guldmann.net www.guldmann.net...
