Canature WaterGroup 185HTO Owner's Manual

Dual media tank
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Certified by IAPMO R&T
to NSF/ANSI 42 for
Chlorine Reduction
85UF Dual
Media Tank
Specialty System Manual
1. This manual contains important safety and operating instructions. Read all instructions and follow
them when using this product. Failure to consider this information and follow these instructions,
including those concerning maintenance, may result in property damage, injury and or death.
Page 28 of this manual contains important maintenance procedures for the continued proper
operation of your unit. These MUST be performed regularly for your warranty to remain valid.
2. We recommend installation only be completed by a competent installer or plumbing professional to insure this
product is installed in accordance with local plumbing codes.
3. Read this manual in full and follow all instructions carefully before operation.
4. Avoid pinched O-rings during installation by applying NSF certified lubricant to all seals (provided with install kit).
5. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without
adequate disinfection before or after the system.
6. Discard small parts remaining after the installation.
7. Failure to install the system correctly voids the warranty.
8. Handle all components of the system with care. Do not drop, drag or turn components upside down.
9. Save these instructions and keep track of your product's serial number.
NOTICE: THIS MANUAL CONTAINS A LIMITED WARRANTY. BY INSTALLING AND OR USING THIS PRODUCT, YOU WAIVE
CERTAIN LEGAL RIGHTS INCLUDING THE RIGHT TO SUE OR CLAIM COMPENSATION IN THE EVENT OF PROPERTY
DAMAGE, INJURY, AND OR DEATH.
Canature WaterGroup Canada Inc.
855 Park St., Unit 1
Regina, SK, S4N 6M1
Toll Free: (877) 288-9888
Canature WaterGroup U.S.A. Inc.
6353 Commerce Drive
Whitestown, IN, 46075
Toll Free: (877) 288-9888

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 185HTO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Canature WaterGroup 185HTO

Summary of Contents for Canature WaterGroup 185HTO

  • Page 1 NOTICE: THIS MANUAL CONTAINS A LIMITED WARRANTY. BY INSTALLING AND OR USING THIS PRODUCT, YOU WAIVE CERTAIN LEGAL RIGHTS INCLUDING THE RIGHT TO SUE OR CLAIM COMPENSATION IN THE EVENT OF PROPERTY DAMAGE, INJURY, AND OR DEATH. Canature WaterGroup Canada Inc. Canature WaterGroup U.S.A. Inc. 855 Park St., Unit 1...

  • Page 3: Table Of Contents

    SAFETY FIND AND RECORD VALVE TYPE & SERIAL NUMBERS RECORDS & CONTACTS KNOW THIS BEFORE STARTING YOUR INSTALLATION HOW YOUR WATER CONDITIONER WORKS FEATURES & TERMINOLOGY FLOW RATE INFORMATION FEED WATER PARAMETERS UNPACKING/INSPECTION BEFORE INSTALLATION PREPARATIONS PLANNING YOUR INSTALLATION INSTALLATION STEPS UNDERSTAND THE SCREEN &...

  • Page 4: Safety

    Used to depict a specific behavior that MUST be followed to avoid the present hazard (problem). Canature WaterGroup U.S.A. Inc. / Canature WaterGroup Canada Inc. (“Canature”) has disclosed all known risks associated with the product within this manual but cannot disclose risks that are beyond its knowledge.

  • Page 5: Find And Record Valve Type & Serial Numbers

    FIND AND RECORD VALVE TYPE & SERIAL NUMBERS There are two labels located on your Unit: 1) Control valve label and 2) System number label. Find and record your product model number, serial number, and valve serial number in the Records & Contacts section as they will be important if you need to troubleshoot. Item # Model # Control Valve Serial #...

  • Page 6: Know This Before Starting Your Installation

    KNOW THIS BEFORE STARTING YOUR INSTALLATION   Read this manual thoroughly to become familiar with Do not use this conditioner on hot water supply lines. the conditioner and its capabilities before installing or  Avoid pinched O-rings during installation by applying the operating.

  • Page 7: How Your Water Conditioner Works

    HOW YOUR WATER CONDITIONER WORKS Water conditioners remove problem minerals (calcium and manganese) causing hardness, from your water by exchanging them with harmless sodium ions in a process called ion exchange. Unlike calcium and magnesium, sodium does not form scaling. Sodium also does not interfere with the cleaning action of soaps.

  • Page 8: Flow Rate Information

    FLOW RATE INFORMATION At the stated service flow rates, the pressure drop through these devices will not exceed 15 psig. Peak flow rates are intended for intermittent use only (10 minutes or less) and are for residential applications only. Do not use peak flow rate for commercial applications or for a continuous rate when treated water supplies are geothermal heat pump, swimming pool, etc.

  • Page 9: Unpacking/Inspection

    UNPACKING/INSPECTION Be sure to check the entire unit for any shipping damage or parts loss. Also note damage to the shipping cartons. Contact the transportation company for all damage and loss claims. The manufacturer is not responsible for damages in transit. Small parts, needed to install the softener, are in a parts box.

  • Page 10: Before Installation

    BEFORE INSTALLATION Make sure you have a copy of your most recent water test results. If your water has not been tested previously, your professional installer can obtain a water sample bottle to be sent to one of our facilities for a free analysis. It is important that this product not be installed until you have this information.

  • Page 11: Preparations

    PREPARATIONS MEDIA INSTALLATION (WHEN NECESSARY) When larger units cannot be loaded due to weight restrictions, media will be shipped pre-measured in separate containers. Follow the steps below for proper media loading. Plug the Riser Tube The riser Upper (distributor) Diffuser remains inside the tank seated in the depression at...
  • Page 12 PREPARATIONS (CONTINUED) MEDIA INSTALLATION (WHEN NECESSARY) TYPES OF MEDIA HTO/HTOK Media HEDP Media Carbon Conditioner Conditioner Conditioner Resin Resin Resin Support Bed Gravel Support Bed Gravel HNU Media SIMTAN / HIMTLC Media Conditioner Conditioner Neutralizer Tannins Resin Resin Filter A850 Resin A860 Resin Support Bed Gravel Support Bed Gravel...
  • Page 13 PREPARATIONS (CONTINUED) 4. Apply the supplied lubricant (part #92360) to the internal O-ring at the bottom of the control valve. Apply lubricant to the larger O-ring on the bottom of the valve that seals with the tank threads. Internal O-ring NOTICE Do NOT use petroleum-based Tank Seal O-ring...
  • Page 14 PREPARATIONS (CONTINUED) BRINE TANK ASSEMBLY To assemble the brine tank, (some tanks may be square) 4. Take the brine tube and insert the nut follow these steps: and plastic sleeve as shown below. Insert Sleeve 1. Attach the three brine grid legs to grid plate. The legs will snap on to the tabs of the salt plate making a “clicking”...

  • Page 15: Planning Your Installation

    PLANNING YOUR INSTALLATION WATER CONDITIONER INSTALLATION LAYOUT Select the location for your conditioner tank with care. Various conditions that contribute to proper location include: 1. All installation procedures must conform to local or regional plumbing codes. Canature is not liable for any non-compliance with local requirements 2.
  • Page 16 PLANNING YOUR INSTALLATION (CONTINUED) WATER CONDITIONER INSTALLATION Inlet Water Pipe Inlet Outlet Brine Elbow Water Pipe Outlet AC120V/10A Assembly Current Protect Socket Drain Elbow Assembly Bypass assembly Brine Tank Brine Valve Connector Detail Optional Over ow Assembly 5/8” Drain Line 5/8”...

  • Page 17: Installation Steps

    INSTALLATION STEPS TO BEGIN YOUR INSTALLATION: 1. Make sure the bypass is attached securely to the control valve. 2. Apply thread tape to threaded connections elbow plumbing adaptors 3. Apply the supplied lubricant (#92360) to the O-rings of the fittings. 4.
  • Page 18 INSTALLATION STEPS (CONTINUED) Brine tube Fig. 2. stiffener 7. Attach the brine line from brine tank to brine line fitting on control valve. install the tube stiffener into the end of the brine line before attaching it to the brine line fitting on the control valve See Fig.

  • Page 19: Understand The Screen & Keypad Configuration

    UNDERSTAND THE SCREEN & KEYPAD CONFIGURATION The control valve is controlled with simple, user-friendly electronics, displayed on an LCD screen CONNECT THE TRANSFORMER Connect the transformer to the unit by plugging the 12 volt transformer into a 120 VAC 60 Hz outlet WARNING if your power supply is subject to surges or frequent outages, surge protection...

  • Page 20: Start-Up Instructions

    START-UP INSTRUCTIONS Now that your water conditioner is plumbed into position it is time to start up and program the unit. STEP 1. ADD WATER TO BRINE TANK 1. Open the brine tank/cabinet salt lid and fill with water until there is approximately 1” [25.4 mm] of water above the grid plate.
  • Page 21 START-UP INSTRUCTIONS (CONTINUED) STEP 3. PROGRAM HOUSEHOLD SETTINGS This unit is factory set for the correct size. You are required to program the date, the time of day, the number of people living in the home and the correct hardness setting. Please review Compensated Hardness Calculation before entering the hardness number from your water analysis. Compensated Hardness Calculation: __ ppm Iron x 4 = __ grains of hardness __ ppm Manganese x 8 = __ grains of hardness...
  • Page 22 START-UP INSTRUCTIONS (CONTINUED) STEP 3. PROGRAM HOUSEHOLD SETTINGS PRESS SETTINGS KEY AUG/30/2019 TIME OF DAY 3 SEC TO UNLOCK 12:15AM 12:15AM 1. The display may read “PRESS SETTINGS 3. Press and hold button one (1) 4. Now press button three KEY”.
  • Page 23 START-UP INSTRUCTIONS (CONTINUED) STEP 3. PROGRAM HOUSEHOLD SETTINGS (CONTINUED) SET HARDNESS SET HARDNESS GRAINS GRAINS 14. Now press button three (3) 16. Now press button three (3) or four (4) 15. Press button one (1) once or four (4) to change the DAY to change HARDNESS value.
  • Page 24 START-UP INSTRUCTIONS (CONTINUED) STEP 4. ADD SALT TO BRINE CABINET Put 80 to 100 lbs [40 kg] of water conditioner salt into the brine tank. The unit will automatically fill the water to the correct level when it regenerates. Congratulations! Start-Up Instructions are now complete –...
  • Page 25 START-UP INSTRUCTIONS (CONTINUED) PROBLEM WATER INJECTOR KIT For use on HTO, HNU conditioners only. IMPORTANT!: If the water source this water conditioner is being applied on is not municipal water and contains up to 2.0 mg/l/ppm of ferrous (Clear Water) iron and/or up to .75 mg/l/ppm of manganese, the enclosed Problem Water Injector Kit needs to be installed into the control valve following these instructions.
  • Page 26 START-UP INSTRUCTIONS (CONTINUED) PROBLEM WATER INJECTOR KIT Once installed, you will need to make three (3) programming changes to the main user settings: 1. Change Iron & MN Grains Capacity PRESS SETTINGS KEY CODE: 100 IRON & MN 3 SEC TO UNLOCK 2100 GRAINS 1.

  • Page 27: Plumbing System Clean Up

    PLUMBING SYSTEM CLEAN UP The following procedures are guidelines only but have proven successful in most instances. Under no circumstances should any procedure outlined below be followed if contrary to any other household appliances manufacturer’s instruction(s). Should there be any questions concerning the advisability of performing a procedure, it is strongly recommended that the dealer be consulted prior to performing the procedure.

  • Page 28: Sanitization Procedure

    SANITIZATION PROCEDURE Care is taken at the factory to keep your water conditioner clean and sanitary. Materials used to make the conditioner will not infect or contaminate your water supply, and will not cause bacteria to form or grow. However, during shipping, storage, installing, and operating, bacteria could get into the conditioner.
  • Page 29 SYSTEM MAINTENANCE (CONTINUED) ADDING SALT TO THE BRINE TANK / CABINET Use only clean salt labeled for water conditioner use, such as crystal, pellet, nugget, or button. The use of natural rock salt is discouraged because it contains insoluble silt and sand which buildup in the brine tank and cause problems with the system’s operation. — Put 40 kg [80 to 100 lbs] of water conditioner salt into the brine tank.
  • Page 30 SYSTEM MAINTENANCE (CONTINUED) AUTOMATIC RESIN CLEANER SOLUTION EASY FEEDER INSTALLATION Optional ResCare Easy Feeders are devices that attach to your brine tank and automatically dispense the ResCare cleaner into the brine solution where it cleans the resin during the regeneration cycle. The Easy Feeder hooks onto the inside of your brine tank and feeds the cleaning solution into your brine well.

  • Page 31: Servicing Your Control Valve

    RESCARE® EASY FEEDER INSTALLATION INSTRUCTIONS SQUARE BRINE TANK - CONTINUED 6. Take off the cover of the ResCare bottle. 5. Take off the small hole cover on Insert the wick, making sure it touches the the brine well lid. bottom of the bottle. Insert the other end of the tube completely into the hole in the brine well cap.
  • Page 32 SERVICING YOUR CONTROL VALVE (CONTINUED) POWERHEAD REMOVAL To remove the powerhead: 2. Remove two (2) bolts securing powerhead to 3. Remove powerhead from body. body. 1. Remove screw & washer from piston rod link. INSPECTION & REPLACEMENT OF PISTON ASSEMBLY AND SEAL & SPACER KIT Piston Assembly Seal and...
  • Page 33 SERVICING YOUR CONTROL VALVE (CONTINUED) Sediment, salt, and silt will restrict or clog the injector. A clean water supply and pure salt will prevent this from happening. The injector assembly is located on the right side of the control valve when facing your conditioner. The assembly is easy to clean, start by: 1.

  • Page 34: Troubleshooting Guide

    TROUBLESHOOTING GUIDE NOTE Before attempting any troubleshooting, be sure to test the water. The tests should include; 1. Raw water 2. Hot treated water 3. Cold treated water. PROBLEM DELIVERS UNTREATED WATER Return the bypass valve to the open position to service the home. See Manual The bypass is closed, sending raw water past the unit.

  • Page 35: Common Spare Parts

    TROUBLESHOOTING GUIDE (CONTINUED) PROBLEM EXCESSIVE PRESSURE LOSS 1. Check unit specifications to ensure proper sizing for the application. Peak or continuous service flow rate may be exceeding capacity 2. Degradation of resin due to chlorine or chloramine. causing the unit to be restrictive due to size. Replace the resin bed.

  • Page 36: Warranty

    Warranty on Control Valve and Parts: Canature WaterGroup™ will replace or repair any part (except for Wear and Tear Items – Media, Piston, Seals and Brine Valve) which fails within seven (7) years from date of manufacture, as indicated by the serial number, provided the failure is due to a defect in material or workmanship. The only exception from the date of manufacture shall be proof of purchase or installation is provided and then the warranty period shall be from the date thereof.
