Summary of Contents for TriangleTube Delta Elite F-25

Page 1 - Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. - If you cannot reach your gas supplier, call the fire department. Installation and service must be performed by a qualified installer, service agency or the gas supplier F-25/30/35/40 & 45 Combination Heaters CONFORMS TO...
Page 2: Table Of Contents
Table of Contents PRODUCT AND SAFETY INFORMATION Definitions ..........1 Product Warnings .
Page 3 Table of Contents U-Tube Assembly ......... . . 12-13 Domestic Drain Valve.
Page 4 Table of Contents Pipe Sizing - Propane Gas ........30 Propane Gas Supply Pressure Requirements .
Page 5 Table of Contents SECTION XII - TEMPERATURE LIMITS Setting Primary Thermostat Limit....... 42 Adjustment of Secondary Thermostat Limit .
Page 6: Product And Safety Information
Product & Safety Information The following terms are used throughout this manual to bring attention to the presence of potential hazards or to important information concerning the product. DANGER Indicates the presence of a hazardous situation which, if ignored, will result in death, serious injury or substantial property damage.
Page 7: Product Warnings
Product & Safety Information WARNING Bacteria can develop in the domestic water system if certain minimum water temperatures are not maintained. DANGER Water temperature over 125ºF can cause severe burns instantly or death from scalds. • Children, disabled and elderly are at highest risk of being scalded.
Page 8 Product & Safety Information DANGER Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system which has been under water. DANGER WHAT TO DO IF YOU SMELL GAS - Do not try to light any appliance...
Page 9: Product And Safety Information
Product & Safety Information OPERATING RESTRICTIONS • Maximum working pressure for inner (domestic water) tank is 150 psig. • Maximum working pressure for outer (primary water) tank is 45 psig. • Inner tank has factory installed Temperature & Pressure Relief Valve with an AGA rating of 100,000 Btu/hr for PG-25 and 200,000 Btu/hr for PG- 30/35/40/45.
Page 10: Section I - Pre-Installation Items
Pre-Installation Items SECTION I - Pre-Installation Items Code Compliance This product must be installed in accor- dance to the following: • All applicable local, state, national and provincial codes, ordinances, regula- tions and laws. • The National Fuel Gas Code NFPA54/ ANSI Z332.1 - Latest edition.
Page 11: Flooring And Foundation
Pre-Installation Items BEST PRACTICES To provide serviceability to the unit it is recommended that the following clear- ances be maintained: Top and vent hood area - 36 inches. Front and burner area - 24 inches. Rear and primary piping areas - 12 inches.
Page 12: Section Ii - Combustion Air And Venting
Combustion Air and Venting SECTION II - Providing Air for Combustion and Ventilation WARNING The installer must provide adequate combustion and ventilation to the area in which the ELITE is installed. Providing adequate air ensures proper combustion and reduces the potential risk of severe personal injury or death from carbon monoxide emissions if a flue gas leakage occurred.
Page 13: Removal Of An Existing Boiler From A Common Vent
Combustion Air and Venting The installer should compensate for any lou- vers, grilles or screens when determining the free air of the opening. The installer should refer the louver or grille manufacturer’s instruction for determining free area. absence of the manufacturer’s instructions the installer should use the following as a guide- line: Wood louvers will provide 20 to 25%...
Page 14: Section Iii - Unit Preparation
Unit Preparation SECTION III - Unit Preparation Handling Instructions The ELITE is generally easier to handle and maneuver once removed from the shipping car- ton and pallet. To remove the shipping carton and pallet: a. Remove the shipping straps and open the top of the shipping carton to remove the wood shipment insert.
Page 15: Completion Of Hydrostatic Test And Draining
Unit Preparation 7. Ensure constant gauge pressure has been maintained throughout the 10 minute test. Check for leaks at all fitting joints. Repair if found. WARNING Leaks must be repaired immediately when detected. Failure to repair leaks can damage the unit, resulting in sub- stantial property damage.
Page 16: Section Iv - Domestic Piping
Temperature / Pressure Relief Valve The ELITE has a factory installed Temperature / Pressure Relief valve. Ensure the rating of the T&P relief valve is correctly sized as follows per AGA: Model AGA Rating F-25 100,000 Btu/hr F-30 200,000 Btu/hr F-35 200,000 Btu/hr F-40...
Page 17: Thermostatic Mixing Valve
Domestic Piping The installer must install discharge piping onto the T&P relief valve. The discharge piping must be: • Made of material serviceable for tem- peratures of 250ºF or greater. • Directed so that any hot water dis- charge flows away from all persons. •...
Page 18: U-Tube Assembly
Domestic Piping 3. Solder the U-Tube Assembly onto the adapter. (See Fig. 1) 4. Once the adapter has sufficiently cooled, re-insert the check valve assem- bly making sure of orientation and reconnect onto the mixing valve. If the installation of the ELITE requires domestic hot water for a commercial dish- washer, the installer may insert a tee con- nection between the unit and the mixing...
Page 19: Tr/Smart Series Application
Domestic Piping TR/SMART Series Application For applications requiring large volumes of domestic hot water over an extended period, the installer may include a Triangle Tube TR/SMART Indirect Water Heater in conjunc- tion with the ELITE. (See Fig. 6 page 16) The domestic system recirculation, if used, is directed to the TR/SMART Series Tank.
Page 20 Domestic Piping To dishwasher if permitted by codes Fig. 3: ELITE With Recirculation Fig. 4: Multiple Units Installation With Recirculation 1. Mixing valve with check valve 2. Flow check valve 3. Shut off valve 4. Backflow preventer or pressure reducing valve* * Optional devices may be required by local Codes Optional recirculation line 6.
Page 21 Domestic Piping Domestic Piping To dishwasher if permitted by codes Fig. 5 : ELITE with Storage Tank To dishwasher if permitted by codes Fig. 6: ELITE with TR/SMART Indirect Water Heater 1. Mixing valve with check valve 2. Flow check valve 3.
Page 22: Section V - Primary Piping
Primary Piping SECTION V - Primary Piping General Piping Requirements Low Water Cutoff Device The ELITE is equipped with a factory installed pressure switch style Low Water Cut Off device. The minimum operating system pressure allowable with this device is 10 psig. Check local codes which require a low water cutoff device for compliance of this device.
Page 23: Circulator
Primary Piping CAUTION DO NOT install automatic air vents on a closed-type expansion tank system. Air must remain in the system and be returned to the expansion tank to pro- vide an air cushion. An automatic air vent would cause air to be vented from the system resulting in a water-logged expansion tank.
Page 24: System Piping - Multiple Units Installation
Primary Piping NOTICE If the radiant system tubing contains no oxygen barrier, a stainless steel heat exchanger must be used. Failure to install a heat exchanger could lead to premature failure of the outer tank and void any warranty claim. WARNING Radiant heating system piping should include a means of regulating the boiler...
Page 25 Primary Piping 12" Max. system Supply flow Return flow Fig. 7 : Near Appliance Primary Piping with a Diaphragm Type Expansion Tank 12" Max. system Supply flow Return flow Fig. 7B : Near Appliance Primary Piping with Diaphragm - Type Expansion Tank (Alternate Circulator Location) 1.
Page 26 Primary Piping 12" max. Fig. 8: Primary piping - Zoning with Circulators 12" max. Fig. 9: Primary Piping - Zoning with Zone Valves 1. Appliance circulator 2. Shut-off valves 3. Flow check valve 4. Zone valve • • • 5. System purge valve 6.
Page 27 Primary Piping Fig. 10: Primary Piping - Low Temperature Radiant System 12" Max. 12" Max. 12" Max. Fig. 11: Primary Piping - Multi Temperature System 1. Circulator 2. Shut Off valves 3. Flow check valve 4. Zone valve LOAD Note: Adjust system temperature valve to establish maximum sup- ply/return temperature differen- tial of 30ºF and a minimum...
Page 28 Primary Piping...
Page 29: Section Vi - Venting
Repair any damaged chimney mor- tar or joints ELITE Flue Outlet Model Diameter F-25 F-30 F-35 F-40 F-45 The chimney must extend a minimum 3 feet above the highest point where it passes through the roof and 2 feet higher than any portion of the building within 10 feet.
Page 30: Oil Vent -Direct Vent Applications
Venting Install a barometric control device in the vent connector as shown in Fig. 13 and 13A and adjust per the manufacturer’s instruction when excess draft needs to be relieved or when applicable codes require a device. Install an induced draft fan in the chimney for applications in which: Excessive resistance to the flow of flue gases is excepted...
Page 31: Gas Venting -General Requirements
Venting Gas Venting -General Requirements The venting system must be installed in accor- dance with: NFPA 54 National Fuel Gas Code, ANSI Z223.1. NFPA 211 Standard for Chimneys, Vent and Solid Fuel Burning Appliances. For installations in Canada the venting system must be installed in accordance with: CGA / B149 Installation Code for Gas Burning Equipment.
Page 32: Vent Connectors
Venting Vent Connectors When a vent connector must be located in or pass through an un-conditioned space, attic or crawl space, that portion of the vent connector must be listed as Type B or other approved material hav- ing equivalent insulation qualities. The minimum clearance to com- bustibles for single wall vent connec- tors shall be 6 inches.
Page 33: Section Vii - Fuel Piping
Fuel Piping SECTION VII - Fuel Piping Gas Supply Piping Connection NOTICE The gas supply piping must be installed in accordance to all applicable local, state and national codes and utility requirements. 1. Remove the burner jacket hood. Refer to Fig.
Page 34: Pipe Sizing -Natural Gas
Fuel Piping Pipe Sizing - Natural Gas 1. Refer to Table 1 for pipe length and diame- ter requirements. Based on rated ELITE input (divide by 1,000 to obtain cubic feet per hour). Table 1 is based on Natural Gas with a specific gravity of 0.60 and a pressure drop through the gas piping of 0.30”w.c..
Page 35: General Oil Piping Guidelines
Fuel Piping General Oil Piping Guidelines Location and installation of oil tanks, oil piping and burners must comply with: NFPA 31, Standard for the Installation of Oil-Burning Equipment Local codes and regulations Manufacturer’s information provided with the burner and oil pump. For installations in Canada, CSA B139, Installation of Oil-Burning Equipment If the fuel tank is installed or any part of the...
Page 36: Section Viii - Internal Wiring
Internal Wiring SECTION VIII - Internal Wiring WARNING ELECTRICAL SHOCK HAZARD. For your safety, disconnect electrical power supply to the unit before servicing or making any electrical connections to avoid possible electric shock hazard. Failure to do so can cause severe person- al injury or death.
Page 37 Internal Wiring Room T-Stat Snap-Set Relay R1 Relay R2 14 13 12 11 10 9 Secondary T-Stat Manual Reset Fig. 16: Factory Wiring Schematic LWCO Burner Circulator Transformer Auto Reset Primary T-Stat Safety Limit Safety Limit On-Off Switch Wire Color Code G 120V Incoming Supply Wiring 120V Field Wiring (by others)
Page 38: Section Ix - External Wiring
External Wiring SECTION IX - External Wiring Installation Compliance All field wiring made during installation must comply with: National Electrical Code NFPA 70 and any other national, state, provincial or local codes or requirements. In Canada, CSA C22.1 Canadian Electrical Code Part 1, and any other local codes.
Page 39: External Control Wiring Diagrams
External Wiring 4 Wire Zone Valve Zone 1 Zone 2 Additional zones 3 Wire Zone Valve Transformer (Power) Thermostat Zone 1 Thermostat Zone 2 Additional zones Fig. 18: Multiple Zone Field Wiring Using Zone Valves V.A.C. High Voltage Transformer (Power) V.A.C.
Page 40 External Wiring Fig. 19: Field wiring with zone circulators. Thermostat Honeywell zone 1 R845A Relay Circulator Zone 1 Thermostat zone 2 Circulator Zone 2 Additional zones may be added as shown above " Room Thermostat" To ELITE Snap Set...
Page 41 External Wiring L2 ZC 120V ELITE "Room Thermostat" Snap-Set Fig. 20: Typical Zone Relay Panel Wiring Fig. 21: Storage Tank Recirculation Wiring Thermostat Thermostat Zone 2 Zone 1 T1 T1 Zone 1 Zone 2 Circulator Circulator Storage Tank Thermostat Honeywell R845A Relay Bronze...
Page 42: Section X - Start-Up Preparation
Start-Up Preparation 4. Set the primary thermostat to the highest possible setting. SECTION X - Start Up Preparation Check System Domestic Chemistry WARNING Do not use petroleum-base cleaning or sealing compounds in the primary sys- tem. Damage to seals and gaskets in the system components could occur, result- ing in substantial property damage.
Page 43: Use Of Antifreeze In The Primary System
Start-Up Preparation NOTICE System water including additives must be practically non-toxic, having a toxicity rating or Class of 1, as listed in Clinical Toxicology of Commercial Products. Use of Antifreeze in the Primary System WARNING NEVER use automotive or ethylene gly- col antifreeze or undiluted antifreeze in the primary system as freeze protection.
Page 44: Check Low Water Cut-Off Device
Start-Up Preparation 3. Fill the outer tank to correct system pressure. Correct pressure will vary with each application. NOTICE Typical residential system fill pressure is 12 psi. System pressure will increase when system temperature increases. Operating pressure of the system should never exceed 25 psi.
Page 45: Section Xi - Start-Up Procedures
Start-Up Procedures SECTION XI - Start-Up Procedures Final Checks Before Start-up Verify the ELITE and the primary and domestic systems are full of water and all system components are correctly set for operation. Verify Start-up Preparation items outlined on pages 37 thru 39 have been completed. Verify all electrical connections are correct and securely fasten.
Page 46 Start-Up Procedures WARNING A combustion test must be performed after any burner adjustments are made. Allow the unit to operate for approxi- mately 10 minutes after adjustment before measuring any combustion levels. Failure to comply with these procedures could result in severe personal injury, death or substantial property damage.
Page 47: Section Xii - Temperature Limits
Temperature Limits SECTION XII - Temperature Limits DANGER Studies have indicated that dangerous bacteria can form in the potable water distribution system if certain minimum water temperatures are not maintained. For prevention of this, it is recommend- ed that the Secondary Thermostat be set as shown in Fig.
Page 48: Setting The Thermostatic Mixing Valve
Temperature Limits Setting the Thermostatic Mixing Valve NOTICE The thermostatic mixing valve controls the outlet hot water temperature deliv- ered to the faucets. WARNING POTENTIAL SCALD HAZARD The mixing valve must be installed on the ELITE. Removal of the mixing valve will create a potential scald hazard resulting in severe personal injury or death.
Page 49: Section Xiii - Check-Out Procedures
Check-Out Procedures SECTION XIII- Check-Out Procedures NOTICE Perform the following check-out proce- dures as outlined and check off items as completed. When procedures are com- pleted, the installer should complete the installation record on page 45. Check-out Procedures Both inner and outer tanks filled with water.
Page 50: Section Xiv - Installation Record
Installation Record SECTION XIV - Installation Record Measured Rate of Input: Thermostatic Mixing Valve Setting: Measured Domestic Outlet Temperature: Combustion Readings: The following items were completed during installation: Installation instructions have been followed and completed Check-out procedures have been followed and completed Information regarding the unit and installation received and left with owner / maintenance personal.
Page 51: Section Xvii - Replacement Parts
Replacements Parts SECTION XVII - Replacement Parts Replacement Parts WARNING Replacement parts can be ordered and purchased through a local Triangle Tube distributor. When ordering parts, spec- ify the Model Number and Serial Number. Include a description of the part and a replacement part number. Using modified or other manufacturer parts will not be covered by warranty and may damage or cause improper...
Page 52: Replacements Parts
Jacket, Left side Jacket, Right side Jacket, Right side Jacket , Back Jacket , Back Burner Jacket Panel Low Water Cut-Off Device LWCO Burner Mounting Plate Burner Plate Insulation Fig. 24: Jacket Components Quantity required by Model F-25/ 30/35/40 F-45...
Page 53 Replacements Parts Fig. 25: Control Panel Components Item Part No. Description Operating Thermostat PGRKIT21 Primary or Secondary Manual Reset Hight Limit PGRKIT 22 Pre-set at 205ºF HMCS01 Control Panel Auto Reset High Limit PGRKIT23 Pre-Set at 194ºF Temperature / Pressure HMGAU01 Gauge...
Page 54: Temperature / Pressure Relief Valve
Replacements Parts Fig. 26: Electrical Panel Components Item Part No. HMRLV01 P3AVT01 HMVLV07 HNSNP02 HMTPV01 HMTPV03 24V Circuit 120 V Circuit Part No. Description R1 Relay - Controls PGRKIT19 Burner Function R2 Relay - Controls PGRKIT 19 Domestic Priority & Circulator 120 V-24 V 40VA PGRKIT18 Transformer...
Page 55: Specifications
Specifications 13" Approx. 11" Fig. 27: Side view Primary circuit, ø 1” NPT Primary circuit drain valve connection, ø 1/2” NPT Domestic temperature/pressure relief valve (150 psi), ø 3/4” NPT Primary circuit & pressure relief valve (30 psi), ø 1” Domestic cold water inlet, ø...
Page 56: Specifications
Domestic water ø Primary connection ø Drain ø Empty weight Heat exchanger surface Sq. Ft. Model 10 Min. Peak F-25 F-30 F-35 F-40 F-45 Graph 1: ELITE Pressure Loss - Primary Side Table 3: Dimensional Data F-25 F-30 F-35 100,000...
Page 57 Additional quality water heating equipment available Phase III Indirect Fired Water Heaters TTP Brazed Plate Heat Exchangers Maxi-flo Pool and Spa Heat Exchangers from Triangle Tube/Phase III Exclusive “Tank-in-Tank” design Stainless steel construction Available in 8 sizes and 2 models Limited LIFETIME residential warranty 15 year limited commercial warranty Self cleaning/self descaling design...
