6.2.2 ノズル詰まりのクリーニング
メンテナンス画面の [How to deal with clogged extruder?] をクリックすると、清掃
方法が表示されます。画面の指示に従って操作してください。
通常、お客様が実施する必要はありません。各種キャリブレーションや自動レベリング
補正を行った装置の平坦度が適切でない場合、以前に設置したプラットフォームの平坦
度が損なわれている可能性があります。この場合は、プラットフォームの水平出しを行
う必要があります。
注意事項
以下のように操作してください。レベリングポイントは全部で4つあります。
1. 鋼板プラットフォームを取り外す。
2. プラットフォームにある4つの固定ネジを緩めてくだ
さい(ネジは緩めるだけで、取り外す必要はありません)
< How to deal with the clogged extruder?
Method 1: Preheat the extruder, and heat the extruder to the required temperature
of the material used. Pull out the filament
pull out the filament, and insert the unclogging pin tool into the nozzle
for unclogging.
Method 2: If Method 1 taken is invalid, replace the nozzle assembly according to
the disassembly and assembly method of the nozzle assembly.
6.3 プラットフォームの校正
この操作に関しては、当社の技術スタッフに連絡して頂くと、
キャリブレーション作業のサポートを行います。
guide tube, press the handle,
20
