Installation, use and maintenance instructions Manuel d’entretien Installatie-, gebruiks- en onderhoudsvoorschriften Oil burners Brûleurs fioul Stookoliebranders One stage operation Fonctionnement à 1 allure Eentrapsbranders CODE MODEL - MODELE TYPE 8099020 SIME MACK 4SP 515 T3 8099040 SIME MACK 5SP 515 T5 2902686 (0)
3. INSTALLATION 3.1 BOILER FIXING Put on the flange (1) the screw and two nuts, (see fig. 2). Widen, if necessary, the insulating gasket holes (5). Fix the flange (1) to the boiler door (4) using screws (2) and (if necessary) the nuts (3) interposing the insulating gasket (5), (see fig.
3.2 HYDRAULIC SYSTEMS The burner is designed to allow entry of the flexible oil-lines on either side of the burner. WARNING: Fig. 4 It is necessary to install a filter on the fuel supply line. The standard filter code 6276200 and that one with recirculation code 6276201 are available on request.
3.3 ELECTRICAL WIRING NOTES: WARNING – Wires of 1 mm 2 section . DO NOT EXCHANGE NEUTRAL WITH PHASE – The electrical wiring carried out by the installer must be in compliance with the rules in force in the 50Hz 230V Country.
ADJUSTMENTS CARRIED OUT IN FACTORY FOR SIME BOILERS The values shown in the table are measured on a SIME boiler (as per EN 267). They refer to 12.5% CO 2 at sea level and with light oil and room temperature of 20 °C.
4.3 ELECTRODES SETTING IMPORTANT: Fig. 11 THESE DIMENSIONS ATTENTION 4 ± 0.3 mm MUST BE OBSERVED Before removing or assembling the nozzle, loosen the screw (B, fig. 11) and move the electrodes ahead. D5230 – 4.4 AIR DAMPER ADJUSTMENT, (see fig. 12) The mobile air damper (1) operated by the jack (2) assures the complete opening of the air intake.
5. MAINTENANCE Burner requires a periodic maintenance carried out by a qualified and authorized technicians. Maintenance is essential for the reliability of the burner, avoiding the excessive consumption of fuel and consequent pollution. Before carrying out any cleaning or control always first switch off the electrical supply to the burner acting on the main switch of the system.
6. FAULTS / SOLUTIONS Here below you can find some causes and the possible solutions for some problems that could cause a fail- ure to start or a bad working of the burner. A fault usually makes the lock-out lamp light which is situated inside the reset button of the control box (3, fig.
