- Page 1 Installation, use and maintenance instructions Manuel d’entretien Installatie-, gebruiks- en onderhoudsvoorschriften Oil burner Brûleur fioul Stookoliebrander One stage operation Fonctionnement à 1 allure Eentrapsbranders CODE MODEL - MODELE TYPE 8099060 SIME MACK 7 440 T 2902685 (0)
-
Page 2: Table Of Contents
INDEX BURNER DESCRIPTION ... . . 1 4.2 Nozzles recomended....1.1 Burner equipment ....1 4.3 Electrode setting . -
Page 3: Technical Data
2. TECHNICAL DATA 2.1 TECHNICAL DATA Model MACK 7 – – Output - Thermal power 18 kg/h 213.5 kW Fuel Light oil, max. viscosity at 20°C: 6 mm ± Electrical supply Single phase, 50Hz 230 V Motor Run current 1.4 A – 2750 rpm – 288 rad/s Capacitor 6.3 µF Ignition transformer... -
Page 4: Installation
3. INSTALLATION 3.1 BOILER FIXING Fig. 2 Assemble the hinge and put on the flange (1) the ➤ screw and two nuts, (see fig. 2). Widen, if necessary, the insulating gasket holes (5). ➤ Fix the flange (1) to the boiler door (4) using screws (2) ➤... -
Page 5: Hydraulic Systems
3.2 HYDRAULIC SYSTEMS The burner is designed to allow entry of the flexible oil-lines on either side of the burner. WARNING: Fig. 5 It is necessary to install a filter on the fuel supply line. ■ The standard filter code 6276200 and that one with recirculation code 6276201 are available on request. -
Page 6: Electrical Wiring
3.3 ELECTRICAL WIRING NOTES: WARNING – Wires of 1 mm 2 section . DO NOT EXCHANGE NEUTRAL WITH PHASE – The electrical wiring carried out by the installer must be in compliance with the rules in force in the 50Hz 230V Country. -
Page 7: Working
■ ADJUSTMENTS FOR SIME BOILERS The values shown in the table are measured on a SIME boiler (as per EN 267). They refer to 12.5% CO 2 at sea level and with light oil and room temperature of 20 °C. -
Page 8: Fig
4.3 ELECTRODE SETTING MOVE THE ELECTRODE Fig. 11 ATTENTION HOLDER BACKWARDS TO THE END 4 ± 0.3 mm Before removing or assembling the nozzle, loosen the screw (B, fig. 11) and move the electrodes ahead. D5961 6.5 ± 0.5 mm 4.4 COMBUSTION HEAD SETTING Terminal plane of the blast tube Fig. -
Page 9: Pump Pressure
The settings, indicated in the table at page 6, refer to the Fig. 14 burner with its cover fitted and combustion chamber with depression zero. These regulations are purely indicative. Each installation however, has its own unpredictable working conditions: actual n o z z l e o u t p u t ;... -
Page 10: Maintenance
5. MAINTENANCE Burner requires a periodic maintenance carried out by a qualified and authorized technicians. Maintenance is essential for the reliability of the burner, avoiding the excessive consumption of fuel and consequent pollution. Before carrying out any cleaning or control always first switch off the electrical supply to the burner acting on the main switch of the system. -
Page 11: Faults / Solutions
6. FAULTS / SOLUTIONS Here below you can find some causes and the possible solutions for some problems that could cause a fail- ure to start or a bad working of the burner. A fault usually makes the lock-out lamp light which is situated inside the reset button of the control box (3, fig. - Page 12 Fonderie Sime S.p.A. - via Garbo, 27 - 37045 Legnago (Vr) - Italy Tel. +39 / 0442 631111 - Export Division fax number +39 / 0442 631293 - Sime Service fax number +39 / 0442 631292...
