American Standard Champion 4 HET 241AA Series Installation Instructions

American Standard Champion 4 HET 241AA Series Installation Instructions

Advertisement

Quick Links

INSTALLATION INSTRUCTIONS
CARE AND MAINTENANCE
Champion
4 HET 2-piece Toilet
®
241AA Series Champion
241BA Series Champion
Thank you for selecting American Standard - the benchmark of fine quality for over 100 years. To ensure this product is installed properly, please read
these instructions carefully before you begin. (Certain installations may require professional help.) Also be sure your installation conforms to local codes.
CAUTION: PRODUCT IS FRAGILE. TO AVOID BREAKAGE AND POSSIBLE INJURY HANDLE WITH CARE!
!
NOTE: Pictures may not exactly define contour of china and components.
TANK 4149A
BOWL 3395A RIGHT HEIGHT
BOWL 3395B RIGHT HEIGHT
4 HET Right Height
®
4 HET Right Height
®
ELONGATED
®
ROUND FRONT
®
SOLD SEPARATELY
Water Supply Line
P r o d u c t n a m e s l i s t e d h e r e i n a r e t r a d e m a r k s o f A S A m e r i c a , I n c .
© A S A m e r i c a , I n c . 2 0 1 3
Elongated
®
Round Front
®
EZ-INSTALL KIT INCLUDED WITH TANK
Attachment Handles
Tank To Bowl Gasket
EZ-INSTALL KIT INCLUDED WITH BOWL
Wax Ring
T-Bolts with Retainer (2)
Plastic Washers (2)
with Nuts (2)
Bolt Caps (2)
Bowl-To-Floor
Knobs (2)
Slow Close
Toilet Seat
7301964 -10 0 Rev. A
